4. Install Inside Chassis

Step 1: Confirm the position of Cam Link.
!
CAM LINK MUST
REMAIN IN
THE CORRECT
POSITION DURING
INSTALLATION.
Step 2: Feed the Wire Harness through Inside Chassis.
6
For Right Hand Locks:
Turn to right position.
For Left Hand Locks:
Turn to left position.
