YOKOGAWA FLXA402 Technical Information
  1. Manuals
  2. Brands
  3. YOKOGAWA Manuals
  4. Media Converter
  5. FLXA402
  6. Technical information

YOKOGAWA FLXA402 Technical Information

4-wire converter, hart communication
Hide thumbs Also See for FLXA402:
Table of Contents

Advertisement

Quick Links

See also: Technical Information , User Manual
Technical
Information
TI 12A01F01-61EN
Contents
1.
Outline...................................................................................................... 2
1.1
1.2
1.3
2.
2.1
2.2
Revision Information .....................................................................................37
FLEXA, FLXA, SENCOM and FieldMate are registered trademarks of Yokogawa Electric Corporation.
FLXA402 4-Wire Converter
HART Communication
Downloading and installing DD files ...............................................................2
Functions Available via HART Communication .............................................3
1.2.1
Multi-drop mode .................................................................................................4
1.2.2
Write protection ..................................................................................................4
1.2.3
Device Variable Code .........................................................................................5
1.2.4
Diagnostics Command (Command 48)..............................................................6
Precaution ........................................................................................................10
Online menu .....................................................................................................11
2.1.1
process_variables_root_menu ........................................................................ 12
2.1.2
diagnostic_root_menu ..................................................................................... 16
2.1.3
maintenance_root_menu ................................................................................ 17
2.1.4
device_root_menu ........................................................................................... 23
Offline ...............................................................................................................35
2-9-32, Nakacho, Musashino-shi, Tokyo, 180-8750 Japan
TI 12A01F01-61EN
©Copyright Nov. 2018
1st Edition Nov. 2018

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FLXA402 and is the answer not in the manual?

Questions and answers

Related Manuals for YOKOGAWA FLXA402

Summary of Contents for YOKOGAWA FLXA402

  • Page 1: Table Of Contents

    2.1.4 device_root_menu ................... 23 2.2 Offline .......................35 Revision Information ..................37 FLEXA, FLXA, SENCOM and FieldMate are registered trademarks of Yokogawa Electric Corporation. TI 12A01F01-61EN Yokogawa Electric Corporation ©Copyright Nov. 2018 2-9-32, Nakacho, Musashino-shi, Tokyo, 180-8750 Japan 1st Edition Nov. 2018...

  • Page 2: Outline

    To enable HART communication between a FLXA402 and setup tool, the device description (DD) file of the FLXA402 needs to be installed in the setup tool. The DD file contains the HART communication details and menu configurations specific to the FLXA402.

  • Page 3: Functions Available Via Hart Communication

    Functions Available via HART Communication FLXA402 via Hart communication enables the following settings: Error settings (4.7), mA output settings (4.3), Contact input settings (4.2), HART setting (4.6.2). Information on the sensor settings or calibration are available as Read only. The numbers in the parentheses correspond the section number in the User’s Manual...

  • Page 4: Multi-Drop Mode

    Reboot switch (Do not use it) Front view with the front panel opened Figure 2 FLXA402 CAUTION Slide switch 1 is for HART. DO NOT turn ON the Slide switch 2. CAUTION DO NOT push the button switch next to the Slide switches, when they are set to ON/OFF.

  • Page 5: Device Variable Code

    HART Communication 1.2.3 Device Variable Code Use Device Variable Code for FLXA402 to set device variables from SV to QV.or to Read process values on Command 9. Code Name PV SV TV QV Code Name PV SV TV QV AO1 current*1...

  • Page 6: Diagnostics Command (Command 48)

    HART Communication FLXA402 use the following extended Units code for each unit Unit Unit Code µS/m S/cm Ohm m MOhm m %SAT 1.2.4 Diagnostics Command (Command 48) CMD48 Alarm HART Status Group HART Alarm Name NE107 byte Number Device Status...
  • Page 7 HART Communication CMD48 Alarm HART Status Group HART Alarm Name NE107 byte Number Device Specific Status 4 Simulated mA value 1 Simulated mA value 2 Simulated mA value 3 Simulated mA value 4 Outputs in HOLD1 Outputs in HOLD2 Outputs in HOLD3 Outputs in HOLD4 Device Specific Status 5 Output configuration error...
  • Page 8 HART Communication CMD48 Alarm HART Status Group HART Alarm Name NE107 byte Number Standardized Status2 Sub-Device List Changed Duplicate master Detected. Reserved Reserved Reserved Reserved Reserved Reserved Standardized Status2 Reserved for Wireless HART Reserved Reserved Reserved Reserved Reserved Reserved Reserved Analog Channel Fixed Analog Channel 1 Analog Channel 2...
  • Page 9 HART Communication CMD48 Alarm HART Status Group HART Alarm Name NE107 byte Number Device Specific Status 10 Sensor 1-1 measurement warning Sensor 1-2 measurement warning Sensor 1-3 measurement warning Sensor 1-4 measurement warning Sensor 2-1 measurement warning Reserved Reserved Reserved Device Specific Status 11 Sensor 1-1 out of spec.

  • Page 10: Precaution

    IM 12A01F01-03EN Operation of Converter. Access to parameters (Printout, Up/Download of parameters) The large number of parameters are configured in FLXA402. Therefore, it may take several minutes to carry our operation by using a lot of parameters. Note on Display Update the menu display whenever the setting of FLXA402 is revised.

  • Page 11: Dd Menu Structure (Device Revision 1, Dd Revision 1)

    HART Communication DD Menu Structure (Device revision 1, DD revision 1) Online menu process_variables_root_menu device_root_menu diagnostic_root_menu maintenance_root_menu TI 12A01F01-61EN Nov. 20, 2018-00...

  • Page 12: Process_Variables_Root_Menu

    HART Communication 2.1.1 process_variables_root_menu Process variables Dynamic variables root menu PV % rnge PV is SV is TV is QV is Device variables CH1-1 Sensor type PH sensor pH 1-1 ORP 1-1 rH 1-1 Temp 1-1 Sensor mV1 1-1 Sensor mV2 1-1 Sensor mV3 1-1 SC sensor Conduct1 1-1...

  • Page 13: Temp

    HART Communication Average Conduct Average Resist Average DO Ratio Passage Rejection Deviation pH calc Script 1 Script 2 Script 3 Script 4 Script 5 Script 6 Script 7 Script 8 Dynamic variables status PV quality PV limit SV quality SV limit TV quality TV limit QV quality...

  • Page 14: Sensor Ohms

    HART Communication USP 1-1 limit Sensor Ohms 1-1 quality Sensor Ohms 1-1 limit ISC sensor Conduct1 1-1 quality Conduct1 1-1 limit Conduct2 1-1 quality Conduct2 1-1 limit Temp 1-1 quality Temp 1-1 limit Sensor Ohms 1-1 quality Sensor Ohms 1-1 limit DO sensor Oxygen 1-1 quality Oxygen 1-1 limit...
  • Page 15 HART Communication Passage limit Rejection quality Rejection limit Deviation quality Deviation limit pH calc quality pH calc limit Script 1 quality Script 1 limit Script 2 quality Script 2 limit Script 3 quality Script 3 limit Script 4 quality Script 4 limit Script 5 quality Script 5 limit Script 6 quality...

  • Page 16: Diagnostic_Root_Menu

    HART Communication [selected device variavle name] [selected device variavle name] [selected device variavle name] [selected device variavle name] [selected device variavle name] User select codes User select code 1 User select code 2 User select code 3 User select code 4 User select code 5 User select code 6 User select code 7...

  • Page 17: Maintenance_Root_Menu

    HART Communication 2.1.3 maintenance_root_menu Maintenance root menu Test Simulation all clear Test auto release time Loop current(AO1) test AO2 test AO3 test AO4 test Status simulation Display Squawk Adjust touch panel Luminance select Error configuration Converter Measurement alarm VGB calc. error Ratio calc.
  • Page 18 HART Communication Contact config. error 2 Contact config. error 3 Contact config. error 4 PH sensor Sensor status Sensor not detect Temp element not detect ID chip failure LE detect calibration due imp1 glasbreak detect imp2 glasbreak detect Measurement warning temp too high temp too low pH too high...
  • Page 19 HART Communication Sensor not detect Temp element not detect ID chip failure calibration due Measurement warning temp too high temp too low conductivity too high conductivity too low temp comp1 warning temp comp2 warning matrix1 error matrix2 error conc table error SSA temp out.
  • Page 20 HART Communication Device diagnostic status 0 Device configuration locked Device diagnostic status 1 Status simulation active Discrete Variable Simulation active Device Specific Status 0 Hardware failure Internal com. error IO mod. param. read error Com. mod. param. read error CPU param. read error Device Specific Status 1 VGB calc.
  • Page 21 HART Communication Device Specific Status 5 Output configuration error Other configuration error Device Specific Status 6 Sensor 1-1 device failure Sensor 1-2 device failure Sensor 1-3 device failure Sensor 1-4 device failure Sensor 2-1 device failure Sensor 2-2 device failure Sensor 2-3 device failure Sensor 2-4 device failure Device Specific...
  • Page 22 HART Communication Process 1-4 exceeds user limit Process 2-1 exceeds user limit Process 2-2 exceeds user limit Process 2-3 exceeds user limit Process 2-4 exceeds user limit Device Specific Status 10 Sensor 1-1 measurement warning Sensor 1-2 measurement warning Sensor 1-3 measurement warning Sensor 1-4 measurement warning...

  • Page 23: Device_Root_Menu

    HART Communication Reset condensed status map Device reset 2.1.4 device_root_menu Device root menu Basic setup Analog output AO1 is AO1 target AO1 parameter AO1 linear limit value AO1 LRV AO1 URV AO1 sub LRV AO1 sub URV AO1 table limit value AO1 LRV AO1 URV...
  • Page 24 HART Communication AO4 linear limit value AO4 LRV AO4 URV AO4 sub LRV AO4 sub URV AO4 table limit value AO4 LRV AO4 URV HART basic setup PV is SV is TV is QV is Tag setting Long tag Detailed setup AO hold for setup Analog output/...
  • Page 25 HART Communication Analog input AI type AI damping time AI upper Limit AI lower limit AI temperature AI temp unit AI Temp LRV AI Temp URV AI pressure AI press unit AI Press LRV AI Press URV Pressure comp. (DO70G) Contact input Contact input 1 DI1 type...
  • Page 26 HART Communication QV is Loop current mode Poll addr HART identification Long tag Num req preams Num resp preams Descriptor Message Date Final asembly num Distributor Model Write protect STX Count ACK Count HART sub unit setup Sub unit select Sensor 1-1 subunit enable Sensor 1-2 subunit...
  • Page 27 HART Communication The rest of the Sensor information Sensor information CH1-1 Sensor type Serial No. PH sensor Sensor wellness Progress time Heat cycle Zero Slope Impedance1 Impedance2 Predict maintenance Projected maintenance time Projected maintenance status Projected replacement time Projected replacement status Setting information Configure sensor...
  • Page 28 HART Communication ORP low limit rH high limit rH low limit Calibration settings Temp offset Stabilization time Calibr. Interval Cal. set pH Unit Zero unit Slope unit Limits and timing zero high limit zero low limit slope high limit slope low limit Step Range Buffers (select...
  • Page 29 HART Communication Impedance 2 Impedance 2 High limit Low limit Sensor diag. settings Impedance 1 FINE Impedance 2 FINE Progress time BAD Limit Define heat cycle Heat cycle BAD Limit Heat cycle temperature Heat cycle time Define SENCOM status Sterilized temp. Sterilized time High temp.1 High temp.2...
  • Page 30 HART Communication Concent1 sel./ comp. Temperature settings Unit Temp. compensation Compensation Manual temp. Reference temp Temp coef Temp coef1 Temp coef2 Matrix Select matrix1 Select matrix2 High/Low alarm setting Temperature High Limit Temperature Low Limit Conductivity High Limit Conductivity Low Limit Resistance High Limit Resistance Low...
  • Page 31 HART Communication Others Polarization High Limit Define SENCOM status Sterilized temp. Sterilized time High temp.1 High temp.2 ISC sensor Sensor wellness Progress time Heat cycle Cell constant Predict maintenance Projected calibration time Projected calibration status Setting information Configure sensor Measuring unit Temperature settings Temp.
  • Page 32 HART Communication Temperature High Limit Temperature Low Limit Conductivity High Limit Conductivity Low Limit Calibration settings Temp offset Limits Air calibration c.c. high c.c. low Timing Step Range Stabilization time Calibr. interval Wellness settings Sensor diag. settings Progress time BAD Limit Define heat cycle Heat cycle BAD Limit...
  • Page 33 HART Communication Temp. element Modbus address Measure setting DO settings Unit Temperature settings Unit Temp. compensation Compensation Manual temp. Salinity comp. Compensation Salinity Pressure comp. (Measure) Compensation Pressure level (process) Pressure unit High/Low alarm setting Temp. high limit Temp. low limit DO (mgl) high limit DO (mgl) low...
  • Page 34 HART Communication Step Range (mgl) zero point span point Step Range (ppm) zero point span point Step Range (ppb) zero point span point Step Range (%SAT) zero point span point Calibr. interval zero/slope (Galvanic) Zero Current Slope zero/slope (Polarographic) Zero Current Slope Pressure Comp.

  • Page 35: Offline

    HART Communication 2.2 Offline offline_root_menu Long tag Descriptor Message Date Final asmbly num Poll addr Loop current mode Num resp preams Test auto release time SV is TV is QV is AO1 target AO1 parameter AO1 mode AO1 function select AO1 burnout AO1 damping time AO1 simulation value...
  • Page 36 HART Communication AI upper Limit AI lower limit AI Temp. LRV AI Temp. URV AI Press. LRV AI Press. URV Pressure comp.(DO70G) DI1 type DI1 wash target DI1 change range target DI2 type DI2 wash target DI2 change range target Sub unit select Auto return time select Luminance select...

  • Page 37: Revision Information

    Revision Information Title : FLXA402 4-Wire Converter HART Communication Manual number : TI 12A01F01-61EN Nov. 2018/1st Edition Newly published Yokogawa Electric Corporation 2-9-32 Nakacho, Musashino-shi, Tokyo 180-8750, JAPAN http://www.yokogawa.com/an/ TI 12A01F01-61EN Nov. 20, 2018-00 Nov. 20, 2018-00...
