  • Page 1 User's Manual Model SE14 Magnetic Flow Converter IM 1E10C1-E IM 1E10C1-E 7th Edition Yokogawa Electric Corporation...

  • Page 2: Table Of Contents

    5.5.10 Alarm Output at Low Flow Limit (Flow Switch) ........5-15 5.5.11 Totalization Switch Output ..............5-16 5.5.12 Alarm Output ..................5-17 FD No. IM 1E10C1-E 7th Edition: Jan. 2002 (YK) All Rights Reserved. Copyright © 1998, Yokogawa Electric Corporation IM 1E10C1-E...
  • Page 3 CONTENTS 5.5.13 Data Settings Enable / Inhibit ..............5-17 5.5.14 Procedure of Selecting Special Application Items ......... 5-18 5.5.15 Rate Limit ....................5-18 OPERATION VIA BRAIN TERMINAL (BT200) ......... 6-1 BT200 Connections ..................6-1 BT200 Keypad Layout ..................6-2 BT200 Key Functions ..................6-3 Displaying Flow Rate Data ................
  • Page 4 CONTENTS 9.2.3 Disagreement of Indication with Actual Flow Rate ......... 9-7 OUTLINE ......................10-1 PARAMETER LIST ..................11-1 11.1 Parameters for ADMAG SE Indicator and BRAIN Terminal ..... 11-1 11.2 Parameters for HART Communicator ............11-7 EXPLOSION PROTECTED TYPE INSTRUMENT ........12-1 12.1 CENELEC ATEX(KEMA) ................

  • Page 5: Introduction

    A CAUTION sign denotes a hazard. It calls permission. attention to procedure, practice, condition or the • Yokogawa makes no warranty of any kind with like, which, if not correctly performed or adhered regard to this material, including, but not limited to,...
  • Page 6 C: Unsuitable location that ignore the description in procedures are needed, please contact to this manual. nearest YOKOGAWA office. D: Remaking or repair by a person except whom we • Care should be taken to prevent the build up of entrust.

  • Page 7: Handling Precautions

    If you have any problems or questions, please make 1) The location where it is not exposed to rain or contact with Yokogawa sales office. water. 2) The location where there is few vibration or 2.1 Checking Model and shock.

  • Page 8: Installation

    3. INSTALLATION INSTALLATION WARNING CAUTION Confirm that all connections are corrected before This instrument must be installed by expert applying power to the instrument. Improper engineer or skilled personnel. The procedures wiring may damage the flow tube or converter. described in this chapter are not permitted for operators.

  • Page 9: General Precautions

    3. INSTALLATION 3.2.2 General Precautions IMPORTANT Please give attention to the followings in wiring. If the cable is longer than required, cut off any CAUTION extra length, rather coiling it up, and terminate the conductors as shown in Figure 3.2.3. Avoid •...

  • Page 10: Dc Connections

    3. INSTALLATION (2) Power, Excitation, or Output Cable Supply Voltage and Cable Length 1000 (3300) Power Cable (2970) • Crimp-on Terminal (2640) • Green/Yellow covered conductors shall be used only (2310) Allowed for connection to PROTECTIVE CONDUCTOR cable (1980) length TERMINALS.

  • Page 11: Connecting To External Instruments

    3. INSTALLATION Please slope the conduit pipe down, and install a drain Protective diode ADMAG SE PLS/ALM+ valve at the low end of the vertical pipe. PULSE OUT Mechanical counter Please open the drain valve regularly. – PLS/ALM– 30 V DC, 0.2A. max* *In case of FM Nonincendive type, 0.135A max.

  • Page 12: Basic Operating Procedures

    4. BASIC OPERATING PROCEDURES BASIC OPERATING PROCEDURES All data settings can be performed with the three keys on the front panel (SET,SHIFT, and INC), or using a handheld Brain Terminal (BT) or using a HART communicator. The following sections describe basic data components and how to use the three panel keys.

  • Page 13: Types Of Display Data

    4. BASIC OPERATING PROCEDURES 4.2 Types of Display Data The Display Data is divided into 5 types as follows. Please refer to section 4.2.2 Flow Rate Display Mode Pass-Word Input Mode This mode indicates the instantaneous flow rate and totalization data. Display settings can be set in the Setting Mode and parameter No.“d01”...

  • Page 14: The Initial Procedure To Change The Display Mode

    4. BASIC OPERATING PROCEDURES 4.2.1 The Initial Procedure to Change the Display Mode • The procedure of changing the display from the Flow Rate Display Mode into the Setting Mode by using infrared switches on the converter is described as follows. (1) Procedure in General The Flow Rate The Pass-word...
  • Page 15 4. BASIC OPERATING PROCEDURES • The procedure of returning from the Setting Mode to the Flow Rate Display Mode by using infrared switch on the converter is described as follows. Switch Operation Display Description The number changing mode of the Setting Mode. SET SHIFT INC After all settings have been completed, touch the SET key (example)

  • Page 16: Flow Rate Display Mode

    4. BASIC OPERATING PROCEDURES 4.2.2 Flow Rate Display Mode • Flow Rate Display Mode indicates flow rates and totalization data. ADMAG SE can indicate 12 types as follows. INDICATOR HART DISPLAY ITEM CONTENTS BT200 SETTING Parameter Code Communicator Instantaneous flow rate is displayed D01: DISP SELECT Disp Select Flow Rate (%)

  • Page 17: Setting Mode

    4. BASIC OPERATING PROCEDURES 4.2.3 Setting Mode The Setting Mode confirms contents of parameter and rewrite data. • Detailed procedures of data setting are explained in “ Chapter 5. Function and Data Settings”. • Procedure of data setting * When the display is in the Setting Mode just after power Number ON, it always starts from “b02”.

  • Page 18: Alarm Display Mode

    4. BASIC OPERATING PROCEDURES 4.2.4 Alarm Display Mode • When an alarm occurs, a content of the alarm is shown as an alarm code number. However, this mode is available during the Flow Rate Display Mode. In this mode, alarm number and flow rate are shown alternately. For example;...

  • Page 19: Auto Zero Mode

    4. BASIC OPERATING PROCEDURES 4.2.5 Auto Zero Mode • Three ways of the auto zero adjustment can be done by using the infrared switches on the converter, BT Terminal, or HART communicator. Please refer to “8.1 Pre-Operation Zero Adjustment” in detail. •...

  • Page 20: Function And Data Settings

    5. FUNCTION AND DATA SETTINGS FUNCTION AND DATA SETTINGS A Magnetic flowmeter calculates volume flow rate from a minute voltage that corre- sponds to the flow velocity of a fluid an outputs as a 4 to 20mA signal. The three parameters must be set to obtain a correct signal. NOTE Nominal size, flow span and meter factor must be set.

  • Page 21: Setting Nominal Size

    5. FUNCTION AND DATA SETTINGS 5.1 Setting Nominal Size Switch Operation Display Description (See 4.2.1 The initial procedure to change the display) Change the display into the setting mode through the password input mode. (Please refer to Chapter 4 “BASIC OPERATION PROCEDURES.”) SET SHIFT INC SET SHIFT INC...

  • Page 22: Setting Flow Span

    5. FUNCTION AND DATA SETTINGS 5.2 Setting Flow Span (1) Determing the Flow Span The flow rate span is the instantaneous flow rate value at which the output current is to be 20mA. Please determine the span under considering the followings. •...
  • Page 23 5. FUNCTION AND DATA SETTINGS (2) Span Settings by Infrared Switches on the Converter (Example: Flow Span 30.0m Span Value Setting Switch Operation Display Description (See 4.2.1 The initial procedure to change the Change the display into the setting mode through the password display) input mode.
  • Page 24 5. FUNCTION AND DATA SETTINGS Setting Volume Measurement (m ) and Time Unit (/h) Switch Operation Display Description Change the display into the number changing mode through the (Select m setting mode. SET SHIFT INC By touching the SHIFT and INC key, please select the parameter No.“b04”.

  • Page 25: Setting Meter Factor

    5. FUNCTION AND DATA SETTINGS 5.3 Setting Meter Factor The meter factor is engraved on the data plate of the combined flow tube. Switch Operation Display Description (See 4.2.1 The initial procedure to change the Change the display into the setting mode through the password display) input mode.

  • Page 26: Power Frequency (For Dc Version Only)

    5. FUNCTION AND DATA SETTINGS 5.4 Power Frequency (For DC version only) In case of DC power supply version, setting power frequency is required in areas where IMPORTANT the frequency differs. The meter is set to 50.00Hz at the factory. Display Description Set the value in areas where the frequency differs in...
  • Page 27 5. FUNCTION AND DATA SETTINGS Display Description After setting the number changing mode, the unit of pulse weight is set in parameter No. “F01”. Code Volume Unit Default : 06 Volume unit in that for the flow rate span ×10 Volume unit in that for the flow rate span ×10 Volume unit in that for the flow rate span ×10 Volume unit in that for the flow rate span ×1...

  • Page 28: Display Of Internal Totalization Values

    5. FUNCTION AND DATA SETTINGS 5.5.2 Display of Internal Totalization Values • By setting a weight per a pulse, flow rate totalized value is shown on the display of the converter. (1) Setting Totalization Pulse Weight Example: To output 10 liter per pulse in flow rate span of Display Description Set the pulse weight unit in parameter No.

  • Page 29: Resetting For Totalization Display

    5. FUNCTION AND DATA SETTINGS 5.5.3 Resetting for Totalization Display (1) Presetting for Forward Totalization Display • E04, E05 are used for reset or preset the totalization values of the display. Display Description The totalization value presetting enable can be selected at parameter No.

  • Page 30: Damping Time Constant

    5. FUNCTION AND DATA SETTINGS 5.5.4 Damping Time Constant • The time constant can be changed by setting the parameter No. “b02” to suppress a fluctuation or change a response time. • The time constant influences to flow rate, pulse output and internal totalization. However, in case “00”...

  • Page 31: Limiting Current Output

    5. FUNCTION AND DATA SETTINGS 5.5.7 Limiting Current Output (1) 4 to 20mA Low Cut Output (Current output nearby 0% range) • This function makes it possible to reduce fluctuations in the 0% region to reduce it to Display Description Output 5.6mA(10%) Default : 00...

  • Page 32: Forward And Reverse Flow Measurement

    5. FUNCTION AND DATA SETTINGS 5.5.8 Forward and Reverse Flow Measurement • This function enables to measure forward and reverse flow rate without change the detector direction. • By setting reverse range, in case fluids flow to reverse direction the flowmeter measures it as reverse direction range automatically.

  • Page 33: Automatic Two Range Switching

    5. FUNCTION AND DATA SETTINGS 5.5.9 Automatic Two Range Switching • When an input exceeds 100% of the first range, the range is automatically transferred to the second range and the status output changes state. • PLS/ALM+, PLS/ALM–terminals are used for output connection. PLS/ALM+, PLS/ALM–terminals are for common use with pulse, alarm and other status output functions.

  • Page 34: Alarm Output At Low Flow Limit (Flow Switch)

    5. FUNCTION AND DATA SETTINGS 5.5.10 Alarm Output at Low Flow Limit (Flow Switch) • In case flow rate decrease under set level, an status signal is output. PLS/ALM+, PLS/ALM– terminals are for common use with pulse, alarm and other status output functions.

  • Page 35: Totalization Switch Output

    5. FUNCTION AND DATA SETTINGS 5.5.11 Totalization Switch Output • In case the Internal Totalization Value increase over set level, an alarm signal is output. PLS/ALM+, PLS/ALM– terminals are for common use with pulse, alarm and other status output functions. Therefore, in case this function is used, other functions are not NOTE available to use.

  • Page 36: Alarm Output

    5. FUNCTION AND DATA SETTINGS 5.5.12 Alarm Output • This function is for status output from PLS/ALM+, PLS/ALM– terminals, when an alarm occurs. PLS/ALM+, PLS/ALM–terminals are for common use with pulse, alarm and other status output functions. NOTE Therefore, in case this function is used, other functions are not available to use. •...

  • Page 37: Procedure Of Selecting Special Application Items

    5. FUNCTION AND DATA SETTINGS 5.5.14 Procedure of Selecting Special Application Items • Only the special application (“n” items) shipped being unpublished. In case the “n” items should be used, it can be set “55” in parameter No. “L02”. Displayed Description The “n”...
  • Page 38 5. FUNCTION AND DATA SETTINGS Example 1: Step Input Input: 0 to 10% Step Signal Damping time constant: 3 sec. Dead time: 3 sec. Rate limit value: 1% 63.2% Flow rate value after rate limiting Flow rate value after damping Dead time: 3 sec.

  • Page 39: Operation Via Brain Terminal (Bt200)

    6. OPERATION VIA BRAIN TERMINAL 6. OPERATION VIA BRAIN TERMINAL (BT200) Products come equipped with a BRAIN communication function communicate with dedicated BRAIN terminals (BT200) or computer system. In the BRAIN Series commu- nications system, modulated signal is superimposed onto the 4 to 20 mA DC analog signal for data transmission.

  • Page 40: Bt200 Keypad Layout

    6. OPERATION VIA BRAIN TERMINAL 6.2 BT200 Keypad Layout Figure 6.2 shows the key pad layout of BT200. 8 lines with 21 characters each Function keys Executes the commands displayed at the bottom of the screen. Arrow keys • Selects an item. •...

  • Page 41: Bt200 Key Functions

    6. OPERATION VIA BRAIN TERMINAL 6.3 BT200 Key Functions (1) Entry of Alphanumeric Characters Numbers, codes and letters can be entered in combinations of the alphanumeric keys and the SHIFT key. • Entry of numbers, codes and a space (0 to 9, ., -, Entering of them is possible by using the alphanumeric keys.

  • Page 42: Displaying Flow Rate Data

    6. OPERATION VIA BRAIN TERMINAL (2) Function Keys The functions of the function keys vary with the commands being displayed on the display panel. Command Description Calls up the zero-adjustment menu. MENU CAPS/caps Changes the capital/small letter mode. A: DISPLAY Clears entered data/deletes all data.

  • Page 43: Setting Parameters

    6. OPERATION VIA BRAIN TERMINAL 6.5 Setting Parameters The three parameters must be set to obtain a correct signal. NOTE Nominal size, flow span and meter factor must be set. 6.5.1 Setting Nominal Size Example: Nominal Size 2.00 inch Display Description ON/OFF Turn the power on and the panel as shown on the left appears after...
  • Page 44 6. OPERATION VIA BRAIN TERMINAL Display Description B06:SIZE UNIT < > < inch > ENTER ×2 Press ENTER key twice at an interval of a few seconds. The display as shown on the left appears. B03:SIZE UNIT inch If the data is correct, press F4 key [OK]. PARAM The parameter panel is displayed again.

  • Page 45: Setting Flow Span

    6. OPERATION VIA BRAIN TERMINAL 6.5.2 Setting Flow Span Example: Flow span 30.0 m Display Description ON/OFF Turn the power on and the panel as shown on the left appears after “Please wait...” is displayed for a few seconds. --WELCOME-- BRAIN TERMINAL ID:BT200 CHECK CABLE CONNECTION...
  • Page 46 6. OPERATION VIA BRAIN TERMINAL Display Description B03:FLOW SPAN 1.00 30.0 ENTER ×2 Press ENTER key twice at an interval of a few seconds. The display as shown on the left appears. B03:FLOW SPAN 30.0 If the data is correct, press F4 key [OK]. PARAM The parameter panel is displayed again.
  • Page 47 6. OPERATION VIA BRAIN TERMINAL Display Description The parameter panel appears again. PARAM B02: DAMPING B03: FLOW SPAN 30.0 m3/s B04: FLOW UNIT DATA DIAG Select “B05:TIME UNIT” by feeding the page with the arrow key. PARAM B03: FLOW SPAN 30.0 m3/s B04: FLOW UNIT...

  • Page 48: Setting Meter Factor

    6. OPERATION VIA BRAIN TERMINAL 6.5.3 Setting Meter Factor The meter factor is engraved on the data plate of the combined flow tube. Example: set “1.1200” as meter factor. Display Description ON/OFF Turn the power on and the panel as shown on the left appears after “Please wait...”...

  • Page 49: Power Frequency (For Dc Version Only)

    6. OPERATION VIA BRAIN TERMINAL Display Description B08: MF 1.0000 1.1200 ENTER ×2 Press ENTER key twice at an interval of a few seconds. The display as shown on the left appears. B08: MF 1.1200 If the data is correct, press F4 key [OK]. PARAM The parameter panel is displayed again.

  • Page 50: Other Important Points

    6. OPERATION VIA BRAIN TERMINAL Display Description Select “PROVIDED” in “D02:FL USER SEL.” PARAM D02:FL USER SEL Default:NOT PROVIDED PROVIDED D03:FL USER SPAN In “D03:FL USER SPAN” set the value of 100% flow rate to be 20000.0 displayed in “A20:FLOW RATE” The user-defined unit is set in D10:FL USER UNIT kg/h “D10:FL USER UNIT”...

  • Page 51: Operation Via Hart Communicator

    2) Call “Utility” from main menu and press [→]. 3) Call “Simulation” and press [→]. “The communicator DD 4) Select “YOKOGAWA” from manufacturers list by supports Version 1 and 2.” pressing [↓] and press [→] . 5) Select the model name of the instrument (i.e. ADMAG SE) by pressing [↓] and press [→] to show the DD of the communicator.

  • Page 52: Communication Line Requirements

    7. OPERATION VIA HART COMMUNICATOR 7.1.2 Communication Line Requirements Specifications for Communication Line: Load resistance: 230 to 600Ω (including cable resistance) When multidrop mode, see Figure 7.1.2. Minimum cable size: 24 AWG, (0.51 mm diameter) Cable type: Single pair shielded or multiple pair with overall shield Maximum twisted-pair length: 6,500 ft (2,000 m) Maximum multiple twisted-pair length:...

  • Page 53: Basic Operation Of The Hart Communicator (Model 275)

    7. OPERATION VIA HART COMMUNICATOR 7.2 Basic Operation of the HART Communicator (Model 275) 7.2.1 Keys and Functions Communication Cable LCD (Liquid crystal display) (21 characters×8 lines) Function keys Functions of the keys are indicated on the display. Move the inverse video bar (cursor) on the display for selecting the desired item.

  • Page 54: Display

    7. OPERATION VIA HART COMMUNICATOR 7.2.2 Display The HART Communicator automatically searches for ADMAG SE on the 4 to 20 mA loop when it is turned on. When the HART Communicator is connected to the ADMAG SE, it displays “Online” menu as shown below. (If ADMAG SE is not found, the communicator displays the message “No Device Found.
  • Page 55 7. OPERATION VIA HART COMMUNICATOR Key operation There are two choices to select the desired menu item. 1. Use the key to select the desired item, and then press the key. 2. Press the number key displayed for the desired item. •...

  • Page 56: Entering, Setting And Sending Data

    7. OPERATION VIA HART COMMUNICATOR 7.2.4 Entering, Setting and Sending Data The data which are input with the keys are set in the HART Communicator by pressing ENTER (F4). Then, by pressing SEND (F2), the data are sent to the ADMAG SE. Note that the data are not set in the ADMAG SE if SEND (F2) is not pressed.
  • Page 57 7. OPERATION VIA HART COMMUNICATOR Display Operation ADMAG SE : Press ENTER (F4) to set the data in the HART Communicator after entering the data. FIC-1A (ENTER) HELP ENTER Press SEND (F2) to send the data to the ADMAG SE. ADMAG SE : Basic setup is flashing during communication.

  • Page 58: Parameters

    7. OPERATION VIA HART COMMUNICATOR 7.3 Parameters 7.3.1 Parameters Configuration Parameters of HART Communicator is constructed hierarchically. The menu tree for Online menu is shown in 7.3.3 Menu Tree. See “Chapter 11. Parameter List” about the usage of each parameter. Note the differ- ences between parameters on ADMAG SE display and those on HART Communicator.

  • Page 59: Menu Tree

    7. OPERATION VIA HART COMMUNICATOR 7.3.3 Menu Tree 1 Process 1 PV [r] variables 2 Totl [w] Status group 1 Status group 2 1 Status [r] Status group 3 1 Test/Status 2 Self test [exe] 1 Test device 2 Diag/Service 2 Auto zero [exe] 3 Zero tuning [sel] Inhibits, Enable...
  • Page 60 7. OPERATION VIA HART COMMUNICATOR 1 Totl [w] n UNIT/P, u UNIT/P, m UNIT/P, UNIT/P, 3 Totalizer 2 Total unit [sel] k UNIT/P, M UNIT/P, PULSE/s 3 Total scale [w] 4 Total low cut [w] 5 TI set value [w] 6 Total set [sel] Inhibit, Enable 7 Total switch [w]...
  • Page 61 7. OPERATION VIA HART COMMUNICATOR PV % rnge Online Menu Totl 4 Detailed 4 Outputs 6 Disp output 1 Disp select [sel] 1 Device setup Rev.totl setup Diff.totl 2 PV [r] PV % rnge/Totl 3 PV AO [r] PV/Totl 4 Span [r] PV % rnge/PV PV % rnge/Rev.totl PV/Rev.totl...

  • Page 62: Setting Parameters

    7. OPERATION VIA HART COMMUNICATOR 7.3.4 Setting Parameters The three parameters must be set to obtain a correct signal. NOTE Nominal size, flow span and meter factor must be set. (1) Nominal Size The nominal size is engraved on the data plate of the combined flow tube. Example: Set “2 inch”.
  • Page 63 7. OPERATION VIA HART COMMUNICATOR (2) Span Example: Set “20.0 Cum /h”. 1. Base vol unit 2. Base time unit 1. Span Call up “Base vol unit” setting display. 1. Device setup 4. Detailed setup 1. Sensor 2. Flow units 1.
  • Page 64 7. OPERATION VIA HART COMMUNICATOR Call up “Span” setting display. Hot key 1. Span ADMAG SE : Press Hot key. Flow units 1 Flow unit 2 Time unit SAVE HOME ENTER Select “Span”. ADMAG SE : Hot key 1 Span 1 Cum/h 2 Enable write 3 New password...
  • Page 65 7. OPERATION VIA HART COMMUNICATOR (3) Flow Units For actual flow unit setting, the following parameters are provided. <1> “PV Unit” This parameter can be set only with HART Communicator. The selectable units are shown below. gal/min, Cum/h, L/min, m/s, ft/s <2>...
  • Page 66 7. OPERATION VIA HART COMMUNICATOR (5) Power Frequency (For DC version only) In case of DC power supply version, setting power frequency is required in area where IMPORTANT the frequency differs. The meter is set to 50.00Hz at the factory. Example: Set “60.00”.
  • Page 67 7. OPERATION VIA HART COMMUNICATOR (6) Trim Analog Output Fine output adjustment is carried out with “D/A trim” or “Scaled D/A trim”. • D/A Trim “D/A trim” is to be carried out if the calibration digital ammeter does not read 4.000 mA and 20.000 mA exactly with the output signal of 0% and 100%.
  • Page 68 7. OPERATION VIA HART COMMUNICATOR ADMAG SE : Ammeter reading: 4.000 Fld dev output 4.000 mA equal to reference meter? Because the reading on the ammeter is 4.000 mA, select “Yes” (ENTER) 1 Yes 2 No and press ENTER (F4). If the reading is not 4.000 mA, select “No”.
  • Page 69 7. OPERATION VIA HART COMMUNICATOR ADMAG SE : Select “Change”, and press ENTER (F4). Trim will be scaled The same operations as for “D/A trim” are required when from 4.000 to 20.000 1 Proceed selecting “Proceed”. 2 Change HELP SAVE ABORT ENTER ‘1’...
  • Page 70 7. OPERATION VIA HART COMMUNICATOR ADMAG SE : Press OK (F4). The output signal of 100% is output. Settting fld dev output to 20mA (OK) HELP SAVE ABORT ‘5.21’ ADMAG SE : Voltmeter reading: 5.210 Enter meter value 5.000000 5.000000 Enter the reading of the voltmeter (5.210), and press ENTER (ENTER) (F4).
  • Page 71 7. OPERATION VIA HART COMMUNICATOR (7) Burst Mode The ADMAG SE continuously sends the data stored in it when the burst mode is set “On”. Either one of instantaneous flow rate, output in %, totalization values and current output can be selected and sent. The data is sent intermittently as a digital signal when the ADMAG SE is set in the burst mode.
  • Page 72 7. OPERATION VIA HART COMMUNICATOR (8) Multidrop Mode Field devices in multidrop mode refer to the connection of several field devices on a communication single line. Up to 15 field devices can be connected when set in the multidrop mode. To activate multidrop communication, the field device address must be changed to a number from 1 to 15.
  • Page 73 7. OPERATION VIA HART COMMUNICATOR HART Communicator Select “Digital Poll” and press ENTER (F4). ×3 Polling Never Poll Never Poll Ask Before Polling Always Poll Digital Poll HELP SAVE ENTER (ENTER) 1. If “Never Poll” is set in “Polling” when the address is set, “Online Menu” cannot be called up and displayed.
  • Page 74 7. OPERATION VIA HART COMMUNICATOR (9) Write Protection Write protection function is used to prevent unauthorized data being written into the device, ADMAG SE. This function becomes active by entering a password in “New password”. Write protection status is released for 10 minutes by entering the password in “Enable wrt 10min”.
  • Page 75 7. OPERATION VIA HART COMMUNICATOR Changing Password Example: Change the password from “1 2 3 4” to “6 7 8 9 A”. Call up “Wrt protect menu” in Hot key menu. Hot key 2. Wrt protect menu 2. Wrt protect menu 2.
  • Page 76 When you forget the password that has been registered, it is possible to release the mode for 10 minutes by using a joker password. Enter YOKOGAWA to release “Write protect” status for 10 minutes. If this joker password is used, the status shown in the parameter “Software seal”...

  • Page 77: Actual Operation

    8. ACTUAL OPERATON ACTUAL OPERATION After you have installed the flow tube into the process piping, wired the input / output terminals, set up the required parameters and performed the pre-operation zero adjust- ment, the magnetic flowmeter should output an accurate flow signal from its terminals as soon as the measured fluid begins to flow.

  • Page 78: Zero Adjustment Using Bt200

    8. ACTUAL OPERATON 8.1.2 Zero Adjustment Using BT200 Display Description Call up the menu panel and select “C:ADJUST” with the arrow key. MENU A: DISPLAY B: SET C: ADJUST D: DISP SEL E: TOTAL SET F: PULSE SET HOME ENTER PARAM Press ENTER key to call up the panel displaying the parameter C01: ZERO TUNING...

  • Page 79: Zero Adjustment Using Hart Communicator

    8. ACTUAL OPERATON 8.1.3 Zero Adjustment Using HART Communicator Call up “Zero tuning” display. 1. Device setup 2. Diag/Service 1. Test device 3. Zero tuning ADMAG SE : Select “Enable” and press ENTER (F4) and SEND (F2). Zero tuning Enable Inhibit (ENTER) Enable...

  • Page 80: Self-Diagnostics Functions

    8. ACTUAL OPERATON 8.2 Self-diagnostics Functions The self-diagnostics function displays instrument internal errors, input/output signal abnormalities, setting errors, and other problems. When an alarm occurs, the alarm number that the error has occurred and normal data are alternately indicated on the indicator of ADMAG SE. However, alarms are only displayed during flow rate data display mode and when parameter numbers are being changed in the setting mode.

  • Page 81: Self-Diagnostics Using Hart Communicator

    8. ACTUAL OPERATON 8.2.2 Self-diagnostics Using HART Communicator Self-diagnostics of the ADMAG SE and check of incorrect data setting can be carried out with the HART Communicator. There are two methods for self-diagnostics of the ADMAG SE, self-diagnostics for every transmission and manually executing the “Self test”...

  • Page 82: Error Description And Countermeasure

    — (At occurrence of error group 1 No.2 to 25) Microprocessor failure Err-02 uP FAULT uP fault Contact the nearest Yokogawa office or EEPROM failure Err-03 EEPROM FAULT EEPROM fault service center. A/D converter failure Err-05 A/D FAULT A/D fault...

  • Page 83: Maintenance

    9. MAINTENANCE MAINTENANCE 9.1 Loop Test (Test output) This function enables you to set up any desired value, and to output it from the con- verter for test. Since this function corresponds to flow rate totalization display and pulse output, this makes it possible to check operation of individual function. The test functions of status output are also provided.

  • Page 84: Setting For Test Output Using Bt200

    9. MAINTENANCE (2) Status Output (For status output, alarm output or pulse output ) Display Description Call up “H01” (TEST MODE) on the setting mode and touch SET key to make the data display. Set “01” and touch SET key twice. Code Content Normal operation...

  • Page 85: Setting For Test Output Using Hart Communicator

    9. MAINTENANCE 9.1.3 Setting for Test Output Using HART Communicator (1) Loop Test This feature can be used to output a fixed current from 2.72 mA to 21.28 mA for loop check. Setting of Loop Test Example: Set “12mA (50%)” as test output. 2.
  • Page 86 9. MAINTENANCE Releasing from Loop Test: There are four methods which cause the simulated output to return to a normal flow reading. 1. Wait 10 minutes to automatically release from the test mode. 2. Turn the power off to the ADMAG SE. 3.

  • Page 87: Trouble Shooting

    The following trouble shooting are described from the viewpoint of receiving instrument indication. Please avoid removing the converter unit from the case, replacing fuse and alter LCD orientation. When these procedures are needed, please contact the nearest Yokogawa CAUTION offce.

  • Page 88: Unstable Zero

    Sufficiently shield the flow Is the flowmeter tube. located near motors, Locate the flow tube as far transformers, or other as possible from these electric equipmets. equipments. Insulation deterioration is suspected. Contact the nearest Yokogawa office or service center. IM 1E10C1-E...

  • Page 89: Disagreement Of Indication With Actual Flow Rate

    Check the operation with the open. AM012/SE calibrator, and you will be able to confirm the error of the converter or of Flow Tube. Contact the nearest Yokogawa office or service center. IM 1E10C1-E...

  • Page 90: Outline

    10. OUTLINE 10. OUTLINE Pulse Output Function: STANDARD SPECIFICATIONS Scaled pulse can be output by setting a pulse Note •For models with no setting switches, a hand- factor. held terminal is necessary to set parameters. •Pulse output, status output and alarm output Pulse Width: Duty 50% or fixed pulse width (0.5, use commom terminals, therefore, these 1, 20, 33, 50, or 100ms) - user selectable.
  • Page 91 10. OUTLINE Maximum Power Consumption: Altitude at installation side: 11W for SE***DJ/EJ+SE14 Max.2000m above sea level Insulation Resistance: Installation category based on IEC1010: • 100MΩ between power terminals and ground II (See Note) terminal at 500V DC. Pollution level based on IEC1010: 2(See Note) Note: •...
  • Page 92 Explosion proof ExdIICT6 (only for size 15 to 200mm) /SF1 GOST Certificate Calibration Certificate for GOST (Only for products produced at YMF) /GOS Note : In case of requirement of EN10204 3.1B for Material Certificate, contact YOKOGAWA office. T09 EPS EXTERNAL DIMENSION Magnetic Flow Converter 170 (6.7) 230 (9.1)

  • Page 93: Parameter List

    11. PARAMETER LIST 11. PARAMETER LIST 11.1 Parameters for ADMAG SE Indicator and BRAIN Terminal This chapter describes ADMAG SE parameters for its indicator and BRAIN Terminal. Description of Items BRAIN Data Range, Decimal Default R/W Description Indicator Name Terminal Units Point Value...
  • Page 94 11. PARAMETER LIST List of Parameters for ADMAG SE Indicator and BRAIN Terminal BRAIN Decimal Default Indicator Name Data Range, Units Description Terminal Point Value — DISPLAY Major outputs display functions. Displays instantaneous flow rate in %. FLOW RATE(%) –10.0 to 110.0% ±300.0 Displays instantaneous flow rate in FLOW RATE...
  • Page 95 11. PARAMETER LIST BRAIN Decimal Default Indicator Name Data Range, Units Description Terminal Point Value — Major parameter setting. — TAG NO ASC II 16 characters Sets tag no. up to 16 characters. Sets damping time constant of output. DAMPING 0.5 to 200 sec Sets flow span in selected unit.
  • Page 96 11. PARAMETER LIST BRAIN Decimal Default Indicator Name Data Range, Units Description Terminal Point Value VELOCITY CHK 0 to 32.767 m/s Displays span in m/s. FLOW DIR (00) FORWARD FORWARD Selects flow direction. (01) REVERSE REV.SPAN 1 to 3.0000 0 to 4 1.0000 Sets span for reverse direction.
  • Page 97 11. PARAMETER LIST BRAIN Decimal Default Indicator Name Data Range, Units Description Terminal Point Value — TOTAL SET Totalization functions. Selects totalization rate unit. (“UNIT” TOTAL UNIT (00) n UNIT / P PULSE/s (01) µ UNIT / P in the selection on the left represents the “Base vol unit”...
  • Page 98 11. PARAMETER LIST BRAIN Decimal Default Indicator Name Data Range, Units Description Terminal Point Value — 4 - 20 SET Current output functions. Sets low cut width of current output. 4 - 20 LOW CUT 0 to 10% Sets low limit of current output. 4 - 20 LOW LMT –20 to 100% –20 Sets high limit of current output.

  • Page 99: Parameters For Hart Communicator

    11. PARAMETER LIST 11.2 Parameters for HART Communicator This chapter describes ADMAG SE parameters for HART Communicator. Note the differences between parameters on ADMAG SE indicator and those on HART Commu- nicator. Description of Items Data Range, Default Indicator Name Description Units Value...
  • Page 100 11. PARAMETER LIST List of Parameters for HART Communicator Default Indicator Name Data Range, Units Description Value of SE –32400 to 32400 Displays instantaneous flow rate in engineering unit. Totl 0 to 999999 Displays and presets forward direction totalized flow rate. PV AO 2.40 to 21.6 mA Displays current output.
  • Page 101 11. PARAMETER LIST Default Indicator Name Data Range, Units Description Value of SE Line size 0.01 to 300.0 mm/inch 100.0 Sets flow tube nominal size in selected unit. PV Damp 0.05 to 200.0 sec. Sets damping time constant of output. Enter characters —...
  • Page 102 11. PARAMETER LIST Default Indicator Name Data Range, Units Description Value of SE Tl set value 0 to 999999 Sets forward direction totalization preset value. Total set (00) Inhibit Inhibit Inhibits or enables forward direction totalization and reverse (01) Enable direction totalization from being preset and reset, respectively.
  • Page 103 Empty pipe (00) Alarm No alarm Selects alarm effectiveness when flow tube is not filled with (01) No alarm fluid. Manufacturer Yokogawa Yokogawa Displays “Yokogawa’. — Dev id — Its own Displays device ID. — ID No. Write protect Displays status of “Write Protect”.

  • Page 104: Explosion Protected Type Instrument

    Only trained persons use this instrument in The instrument modification or parts replacement industrial locations. by other than authorized representative of Yokogawa Electric Corporation is prohibited and will void the certification. (1) Technical Data No. KEMA 98ATEX3230 (6) Data Plate Type of Protection : EEx dIIC T6;...

  • Page 105: Fm Explosionproof (Optional Code /Ff1)

    • In order to avoid confusion, unneccessary Yokogawa Electric Corporation is prohibited and marking is crossed out on the label other than will void the approval of Factory Mutual the selected type of protection when the flow Research Corporation.

  • Page 106: Csa

    Voc Vmax, Isc Imax, Ca Ci+C cable, La Li+L cable Yokogawa Electric Corporation is prohibited and will void the approval of Factory Mutual Reseach Signal name Vmax...

  • Page 107: Saa

    The instrument modification or parts replacement Warning : OPEN CIRCUIT BEFORE REMOV- by other than authorized representative of ING COVER. Yokogawa Electric Corporation is prohibited and OUVRIR LE CIRCUIT AVANT D’EN will void the certification. LEVER LE COUVERCLE. Take care not to generate mechanical spark when access to the instrument and peripheral devices in hazardous locations.
