Scope of Delivery

• EW447-452 Series mechanical meter consisting of energy calculator and flow sensor
• Supply and return temperature sensors installed to energy calculator
• One or two installation kits EWA3001305 for pipe installation of temperature sensors:
• DN15...20: one kit included (one sensor is already installed in meter housing)
• DN25...50: two kits included
• DN65 and larger: no kits included as immersion pockets are to be used
• Two paper sealings
• Operating and setup instructions
• M-Bus cable (only types with M-Bus)
• Pulse cable (only types with pulse output)

Accessories

Unless stated otherwise accessories are sold in single packs. Table 6 below shows which connection set and ball valve can be
used for which meter size. The meter size is given in the top line and refers to the last four characters of the OS number.
Example: Items listed in the column headed '2000' can be used for 'EW447A2000', EW447P2000' or 'EW450M2000' and so on.
EW4xxX...
DN size
Connection size
Connection sets
Connection set with
externally threaded
tailpiece
Connection set with
internally
threaded tailpiece
Connection set with
Sanpress crimp fitting
Connection set with
Mapress crimp fitting
Ball valves
Ball valve with additional
port
Honeywell All rights reserved
Table 6. Cross reference: connection sets and ballvalves / meter
0100, 1200
DN15
G 3/4"
1 x EWA1500035
1 x EWA1500042
2 x VA7405A015
2 x VA7405A020
2 x VA7404A015
2 x VA7404A020
2 x VA7403A015
2 x VA7403A020
EWA087HY003
EW447-EW452 SERIES MECHANICAL HEATMETERS
2000
DN20
G 1"
1 x EWA1500062
2 x VA7405A025
2 x VA7404A025
2 x VA7403A025
EWA087HY004
EWA087HY005
9
2800, 3600
DN25
G 1 1/4"
1 x EWA1500072
EN0H-2601GE25 R0413
4600
DN40
G 2"
n.a.
n.a.
n.a.
n.a.
