JRC JMA-9133-SA Simplified Manual

Marine radar equipment
Hide thumbs Also See for JMA-9133-SA:
Table of Contents

Advertisement

Quick Links

See also: Instruction Manual , Installation Manual
JMA-9133-SA
JMA-9132-SA
JMA-9123-7XA/9XA
JMA-9122-6XA/9XA/6XAH
JMA-9110-6XA/6XAH
JMA-7133-SA
JMA-7132-SA
JMA-7123-7XA/9XA
JMA-7122-6XA/9XA/6XAH
JMA-7110-6XA/6XAH
1
INTRODUCTION ............................................................................................... 1
1.1
READ ME ................................................................................................. 1
2
BASIC OPERATION ......................................................................................... 2
2.1
OWER ON AND START THE SYSTEM................................................. 2
2.2
END THE OPERATION AND POWER OFF............................................. 3
2.3
DJUST MONITOR BRILLIANCE [BRILL]............................................. 3
2.4
HANGE OBSERVATION RANGE [RANGE + / - ] ................................. 4
2.5
ADJUST GAIN [GAIN] ............................................................................. 4
2.6
UPPRESS SEA CLUTTER [SEA] ......................................................... 4
2.7
UPPRESS RAIN / SNOW CLUTTER [RAIN] ........................................ 6
2.8
USING ELECTRONIC BEARING LINE (EBL1 / EBL2)........................... 7
2.9
USING VARIABLE RANGE MARKER (VRM1 / VRM2) .......................... 9
2.10
SWITCH TRANSMITTER PULSE LENGTH [GAIN] .............................. 10
2.11
SWITCH AZIMUTH DISPLAY MODE (AZI MODE) ................................ 10
2.12
2.13
DISPLAY RADAR TRAILS (TRAILS) .................................................... 12
3
TARGET TRACKING OPERATION ................................................................ 13
3.1
CQUIRING TARGET [ACQ MANUAL] ............................................... 13
3.2
DISPLAY TRACKED TARGET DATA [TGT DATA] ............................... 13
3.3
CANCELING TRACKED TARGETS [ACQ CNCL]................................ 14
4
ERATION............................................................................................. 15
4.1
SETTING AIS DISPLAY FUNCTION [AIS / TT] ..................................... 15
4.2
ACTIVATE AIS TARGETS (ACT AIS) .................................................... 15
4.3
4.4
DEACTIVATE AIS TARGETS (DEACT AIS) .......................................... 17
5
T TRACKING / AIS COMMON OPERATION...................................... 18
5.1
ETTING VECTORS (VECTOR)............................................................ 18
5.2
6
OTHER CONTENTS ....................................................................................... 20
6.1
ESET ALARM BUZZER [ALARM ACK] ............................................. 20
6.2
OPERATION ON NUMERIC VALUE INPUT MENU .............................. 20
MARINE RADAR
EQUIPMENT
SIMPLIFIED MANUAL

Advertisement

Table of Contents
loading

Related Manuals for JRC JMA-9133-SA

Summary of Contents for JRC JMA-9133-SA

  • Page 1: Table Of Contents

    JMA-9133-SA JMA-9132-SA JMA-9123-7XA/9XA JMA-9122-6XA/9XA/6XAH JMA-9110-6XA/6XAH JMA-7133-SA JMA-7132-SA JMA-7123-7XA/9XA JMA-7122-6XA/9XA/6XAH JMA-7110-6XA/6XAH MARINE RADAR EQUIPMENT SIMPLIFIED MANUAL INTRODUCTION ....................1 READ ME ....................1 BASIC OPERATION ..................2 OWER ON AND START THE SYSTEM..........2 END THE OPERATION AND POWER OFF..........3 DJUST MONITOR BRILLIANCE [BRILL]..........

  • Page 3: Introduction

    INTRODUCTION Read Me About this manual See the INSTRUCTION MANUAL for details. Maintain this SIMPLIFIED MANUAL so that operators can refer to it at anytime. About radar equipment Use the radar only as a navigation aid. The final navigation decision must always be made by the operator him/herself.

  • Page 4: Basic Operation

    BASIC OPERATION Power ON and Start the System Procedures 1 Check that the ship’s mains are turned on. 2 Press the [POWER] key. The system is turned on, and the preheating time is displayed. Preheat is indicated upper left of the display. 3 Wait until the preheating time is over.

  • Page 5: End The Operation And Power Off

    End the Operation and Power Off Exit 1 Press the [TX / STBY] key. The radar will stop transmission and the antenna will stop rotating. Transmit upper left of the display changes to Standby . 2 Press the [POWER] key. The system will be turned off.

  • Page 6: Change Observation Range [Range + / - ]

    Change Observation Range [RANGE + / - ] Procedures 1 When increasing the observation range, press the [RANGE+] key. Increasing the observation range will enable a wider range to be observed. 2 When decreasing the observation range, press the [RANGE-] key. Decreasing the observation range will enable a narrower range to be observed.
  • Page 7 Using the automatic sea clutter suppression mode Procedures 1 Press the [SEA] dial. The automatic sea clutter suppression mode is selected, and AUTO is displayed in sea clutter suppression (Sea) mode switching. 2 Make adjustments by turning the [SEA] dial. Even when the automatic sea clutter suppression mode is selected, turning the [SEA] dial can make fine adjustments manually.

  • Page 8: Suppress Rain / Snow Clutter [Rain]

    Suppress Rain / Snow Clutter [RAIN] Using the manual rain / snow clutter suppression mode Procedures 1 Turning the [RAIN] dial. The rain / snow clutter suppression function suppress rain / snow clutter returns by decreasing the receiving gain. Since the rain / snow clutter suppression function also has the effect of suppressing sea clutter, the suppression efficiency improves when the [RAIN] dial is used with the [SEA] dial.

  • Page 9: Using Electronic Bearing Line (Ebl1 / Ebl2)

    Cancellation 1 Press the [RAIN] dial. The automatic rain / snow clutter suppression mode is cancelled, and AUTO is changed to in the sea clutter suppression (Sea) mode field and the rain / snow clutter suppression (Rain) mode field. Using Electronic Bearing Line (EBL1 / EBL2) [I] Operating EBL (EBL) Procedures 1 Press the [EBL1] or [EBL2] key.
  • Page 10 Cancellation 1 Press the [EBL1] or [EBL2] key again. The selected EBL display will disappear. [II] Moving the Starting Point of EBL The system provides three types of EBL starting points. Select one of them in accordance with purpose. :The EBL starting point is defined as the own ship's position. C :The EBL starting point is moved and fixed on the radar display.

  • Page 11: Using Variable Range Marker (Vrm1 / Vrm2)

    To return the EBL starting point to own ship's position Procedures 1 Make EBL1 or EBL2 operable. 2 Press the [EBL] dial to set for the EBL1 / EBL2 starting point mode switching. The selected EBL starting point will be set as the own ship's position. Using Variable Range Marker (VRM1 / VRM2) To operate VRM Procedures...

  • Page 12: Switch Transmitter Pulse Length [Gain]

    Cancellation 1 Press the [VRM1] or [VRM2] key again. The selected VRM display will disappear. 2.10 Switch Transmitter Pulse Length [GAIN] Procedures 1 Press the [GAIN] dial. The selected pulse length will be displayed in the pulse length indication. 2.11 Switch Azimuth Display Mode (AZI Mode) Procedures 1 Put the cursor on the azimuth display mode switching, left-click.

  • Page 13: Switch True / Relative Motion Display Mode (Tm / Rm)

    2.12 Switch True / Relative Motion Display Mode (TM / RM) Switching Motion Display Mode Procedures 1 Put the cursor on the motion mode true TM / relative RM switching, left-click. The motion display mode are switched. Resetting Own Ship to its Initial Position in True Motion (TM) Mode Procedures 1 Hold down the motion mode true / relative switching TM for 2 seconds.

  • Page 14: Display Radar Trails (Trails)

    2.13 Display Radar Trails (TRAILS) Changing the length of the trail Procedures 1 Put the cursor on the radar trails display time switching, left-click. Values of the length of the radar trail are switched. Erasing Trails Data Procedures 1 Hold down the radar trails display time switching for 5 seconds. All the saved trails data will be erased.

  • Page 15: Target Tracking Operation

    TARGET TRACKING OPERATION Acquiring Target [ACQ MANUAL] Procedures 1 Put the cursor on the target to be acquired, and press the [ACQ MANUAL] key. The target will be acquired and the initial acquisition symbol will be displayed. The vector will be displayed within one minute.

  • Page 16: Canceling Tracked Targets [Acq Cncl]

    Canceling Tracked Targets [ACQ CNCL] Canceling targets one by one [ACQ CNCL] Procedures 1 Put the cursor on the tracked target to the desired for canceling target, and press the [ACQ CNCL] key. The vectors and symbols of the tracked targets will disappear, and only the radar video remain. Canceling all targets collectively [ACQ CNCL] Procedures 1 Press the [ACQ CNCL] key for 5 seconds.

  • Page 17: Ais Operation

    AIS OPERATION Setting AIS Display Function [AIS / TT] Procedures 1 Press the [AIS / TT] key. The received AIS information will be shown on the radar display. Activate AIS Targets (ACT AIS) Procedures 1 Put the cursor on the sleeping AIS target to be activated, and right-click. The setting items for cursor modes will be displayed.

  • Page 18: Display Activated Ais Target Data [Tgt Data]

    2 Left-click 2. ACT AIS . The selected AIS target will be activated. Display Activated AIS Target Data [TGT DATA] Procedures 1 Put the cursor on the AIS target of which data is to be displayed, and press the [TGT DATA] key. The data of the selected AIS target will be displayed.

  • Page 19: Deactivate Ais Targets (Deact Ais)

    Deactivate AIS Targets (DEACT AIS) Procedures 1 Put the cursor on the activated AIS target to be deactivated, and right-click. The setting items for cursor modes will be displayed. 2 Left-click 5. DEACT AIS . The selected AIS target will be deactivated.

  • Page 20: Target Tracking / Ais Common Operation

    TARGET TRACKING / AIS COMMON OPERATION Setting Vectors (Vector) Setting vector mode [T / R / VECT] Procedures 1 Press the [T / R / VECT] key. The current vector mode T (true vector) or R (relative vector) will be displayed in the target vector display true / relative switching.

  • Page 21: Setting Collision Decision Criteria (Cpa / Tcpa Limit)

    Setting Collision Decision Criteria (CPA / TCPA Limit) Input of CPA Limit Procedures 1 Put the cursor on the CPA limit setting, left-click. The CPA Limit value input screen will appear. 2 Enter the value to be set as a CPA limit. For how to input numeric data on the numeric value input menu, see Section 6.2.

  • Page 22: Other Contents

    OTHER CONTENTS Reset Alarm Buzzer [ALARM ACK] Procedures 1 Press the [ALARM ACK] key. The alarm will stop buzzing. Operation on Numeric Value Input menu Entered value Numeric button Enter button Procedures 1 Put the cursor on the numeric button to the desired value, left-click.
  • Page 24 For further information,contact: Not use the asbestos http://www.jrc.co.jp Marine Service Department Telephone : +81-3-3492-1305 Facsimile : +81-3-3779-1420 e-mail : tmsc@jrc.co.jp AMSTERDAM Branch Telephone : +31-20-658-0750 Facsimile : +31-20-658-0755 e-mail : service@jrcams.nl SEATTLE Branch Telephone : +1-206-654-5644 Facsimile : +1-206-654-7030 e-mail : service@jrcamerica.com...
