JRC JMA-7100 Brochure

Jma-7100 series arpa radar 19” high visibility lcd screen constaview digital signal processing tef multi-level target enhancement high speed version available wide dynamic range receiver

Advertisement

Quick Links

JMA-7100 series
ARPA radar
Complies with SOLAS carriage requirements for vessels
under 10.000 GT. and fully meets MSC 192(79) radar
performance standards eff ective from 1 July 2008.
– JRC's new and powerful radar greatly increases performance, but keeps operation simple
19" high visibility LCD screen
Constaview™ digital signal processing
TEF™ multi-level target enhancement
High speed version available
Wide dynamic range receiver

Advertisement

loading

Summary of Contents for JRC JMA-7100

  • Page 1 Complies with SOLAS carriage requirements for vessels under 10.000 GT. and fully meets MSC 192(79) radar performance standards eff ective from 1 July 2008. – JRC’s new and powerful radar greatly increases performance, but keeps operation simple 19” high visibility LCD screen Constaview™ digital signal processing TEF™...
  • Page 2: Unique Features

    JMA-7100 series – performance features Unique features JRC’s new JMA-7100 ARPA radar series integrates the latest leading technologies and represents a signifi cant step change in terms of reliable performance and cost-eff ectiveness, making it one of the most advanced radar products available today.
  • Page 3 The JMA-7100 incorporates three Tornado™ processors, which are exclusively developed and designed by JRC, bringing a new level of performance and reliability to radar operation. The new Tornado™ processors, which equal the power of twelve conventional processors, and advanced system architecture make the JMA-7100 series probably the most sophisticated radar available today.
  • Page 4 JRC StarNetwork™ JRC has been providing sales and support of products since 1915. Today, JRC off ers comprehensive assistance through its organisation, in partnership with a worldwide StarNetwork™ of over 270 fully trained and qualifi ed partners and agents, assisting you 24 hours a day, 7 days a week and 365 days a year.
  • Page 5 What’s standard in the box? JRC sets the highest standards for performance and fl exibility. With our new JMA-7100 series, you have six key choices to select from, allowing you to ‘confi gure’ your favoured radar system – from unit type to cabling – making it more than ideal for your preferred installation approach.
  • Page 6 JMA-7100 series – dimensions and mass Dimension drawings - Stand alone version NCD-4790 MASS 99 kg 325 mm 200 mm 1150 mm 575 mm 580 mm 333 mm 515 mm Dimension drawings - Desktop version NWZ-173 MASS 12,1 kg 425 mm 391 mm 450 mm NCE-5163...
  • Page 7 JMA-7100 series – dimensions and mass Dimension drawings - 10kW X-band scanner highspeed NKE-2103-6 NKE-2103-6HS MASS 40 kg MASS 40 kg Swing circle 1910 mm Swing circle 1910 mm 290 mm 290 mm 348 mm 348 mm Dimension drawings - 25kW X-band scanner highspeed NKE-1125-6 NKE-2254-6HS...
  • Page 8 JMA-7100 series – specifi cations Model JMA-7110-6XA JMA-7110-6XAH JMA-7122-6XA JMA-7122-9XA JMA-7122-6XAH JMA-7123-7XA JMA-7123-9XA JMA-7132-SA JMA-7133-SA IMO compliant Unit type 2-unit type 3-unit type 2-unit type 3-unit type Performance monitor NJU-85 NJU-84 Frequency X-band S-band Display colour raster scan PPI Scanners Model NKE-2103-6 NKE-2103-6HS...
