Data Sheet
Dimensions: H x W x D
Weight
Color
Operating distance, RF Locks
Operating distance,
SmartRelay
Protection category
Operating temperature range
Battery type
Transponder:
TRA, TRA.ROT, TRA.SCHALT, TRA.PWD
1.7 in diameter x 0.5 in thick
(42 mm diameter x 13 mm thick)
0.5 oz (15 g)
Dark Grey, with blue button
approx. 16 inches (40 cm) if the transponder,
lengthways, is held parallel with the RF Lock
antenna
approx. 47 inches (120 cm) if the transponder is
parallel with the antenna of the SmartRelay
IP 54 (NEMA 3S)
-4°F to 104°F (-20°C to 40°C)
Noncondensing
3 V DC lithium battery type CR2032
