- Page 1 Transponder 3064 Manual 29.07.2019...
-
Page 2: Table Of Contents
Additional functions.......................... 10 Time zone control............................ 10 Date of validity .............................. 10 Activation transponder.......................... 10 Battery replacement .......................... 11 Battery Replacement 3064........................ 11 Loss of the transponder .......................... 12 Emergency opening ............................ 12 Replacement transponder [G1]....................... 12 Overview of differences between G1 and G2 Protocols ............... 13 Technical data ............................ -
Page 3: Safety Instructions
1. Safety instructions Transponder 3064 (Manual) 3 / 18 1 Safety instructions The transponder casing is protected against splash water. However, it is not watertight! Only use batteries which have been approved by SimonsVoss (see Technical data [ 14] The batteries used may pose a fire or burn hazard if handled incorrectly. -
Page 4: General
(Manual) 4 / 18 2 General Transponder 3064 is a digital "key" which is programmed with locking plan software and functions using contactless, wireless communication. All functions are activated by pressing a button. These include authorisation identification and the opening and locking of doors, gates, barriers, furniture locks and similar items. -
Page 5: Higher-Ranking Locking Level
2. General Transponder 3064 (Manual) 5 / 18 The following screen shows an example of use. Firma: Eigenheim: Filiale: Schließungen Schließungen Schließungen Schließanlage 1 Schließanlage 2 Schließanlage 3 Fig. 1: A transponder for several separate locking systems 2.3 Higher-ranking locking level Transponders can be authorised for more than three [G1] or four [G2] locking systems. - Page 6 2. General Transponder 3064 (Manual) 6 / 18 200 [G1] or 1024 [G2] transponder IDs (TIDs) are reserved for each level in LSM. Authorisations for different transponders in the higher-ranking locking levels may be different. The following screen shows an example of use.
-
Page 7: Special Models
Remote activation of a digital locking cylinder or SmartRelay 3.3 Explosion protection transponder (EX protection) This transponder has the same functions as a Transponder 3064, but it is also approved for use in Explosion Protection Zone 1 (see Explosion protection transponder [ 9]... -
Page 8: Fire Service Key Tube Transponder
3. Special models Transponder 3064 (Manual) 8 / 18 LEGIC® advant 128 3.6 Fire service key tube transponder Almost identical to the standard transponder, but has a narrower casing (33 mm) and can be kept in a standardised fire service key tube. -
Page 9: Explosion Protection Transponder
The following aspects must be taken into account: The casing must not be opened. Unlike with Standard Transponders 3064, only SimonsVoss may change the battery in this transponder. As a general rule, users must comply with explosion protection ... -
Page 10: Additional Functions
5. Additional functions Transponder 3064 (Manual) 10 / 18 5 Additional functions The functions described below can be activated in the LSM software. 5.1 Time zone control Transponders can be programmed to have locking authorisation for digital access control locking devices at certain times only (time zones). Such time zones are added to the LSM software and the transponders are then allocated to the relevant time zone group. -
Page 11: Battery Replacement
(Manual) 11 / 18 6 Battery replacement 6.1 Battery Replacement 3064 The transponder battery can be replaced at any time when the battery warning is active (see Locking Cylinder 3061 manual – Battery warning). 1. Carefully open the casing at the notches, so that you can see the bat- tery. -
Page 12: Loss Of The Transponder
7. Loss of the transponder Transponder 3064 (Manual) 12 / 18 7 Loss of the transponder 7.1 Emergency opening You may carry out an emergency opening with the SmartCD and PDA and by entering the locking system password. 7.2 Replacement transponder [G1] If a transponder is lost, it can be blocked in the locking plan and a replacement transponder added. -
Page 13: Overview Of Differences Between G1 And G2 Protocols
8. Overview of differences between G1 and G2 Protocols Transponder 3064 (Manual) 13 / 18 8 Overview of differences between G1 and G2 Protocols Locks per locking cylin- 16,000 64,000 der on a transponder Number of locking sys- 4 [G2] + 3 [G1] tems Max. -
Page 14: Technical Data
9. Technical data Transponder 3064 (Manual) 14 / 18 9 Technical data Weatherproof plastic Material (polyamide) Casing: black Colours Housing Buttons: different col- ours Diameter 42.0 mm Height 13.7 mm Temperature range -20 °C to 60 °C IP65 Standard protection Ambient conditions rating IP66 (.SPEZ version) -
Page 15: Declaration Of Conformity
10. Declaration of conformity Transponder 3064 (Manual) 15 / 18 10 Declaration of conformity The company SimonsVoss Technologies GmbH hereby declares that article TRA2 complies with the following guidelines: 2014/53/EU "Radio equipment" 2014/30/EU "EMC" 2011/65/EU "RoHS" 2012/19/EU "WEEE"... -
Page 16: Help And Other Information
11. Help and other information Transponder 3064 (Manual) 16 / 18 11 Help and other information Information material/documents You will find detailed information on operation and configuration and other documents under Informative material/Documents in the Download https://www.simons-voss.com/en/ section on the SimonsVoss website ( downloads/documents.html... - Page 17 11. Help and other information Transponder 3064 (Manual) 17 / 18 SimonsVoss Technologies GmbH Feringastrasse 4 85774 Unterföhring Germany...
- Page 18 This is SimonsVoss SimonsVoss is a technology leader in digital locking systems. The pioneer in wirelessly controlled, cable-free locking technology delivers system solutions with an extensive product range for SOHOs, SMEs, major companies and public institutions. SimonsVoss locking systems unite intelligent functions, optimum quality and award-winning German-made design.
