- Page 1 Transponder (MobileKey) Manual 03.08.2021...
-
Page 2: Table Of Contents
Contents Transponder (MobileKey) (Manual) 2 / 13 Contents General safety instructions........................ 3 How it works .............................. 6 Battery replacement .......................... 7 Technical data ............................ 9 Dimensions................................ 10 EU/UK Declaration of conformity...................... 11 Help and other information ........................ 12... -
Page 3: General Safety Instructions
1. General safety instructions Transponder (MobileKey) (Manual) 3 / 13 1 General safety instructions Signal word (ANSI Possible immediate effects of non-compliance Z535.6) DANGER Death or serious injury (likely) WARNING Death or serious injury (possible, but unlikely) CAUTION Minor injury... - Page 4 1. General safety instructions Transponder (MobileKey) (Manual) 4 / 13 CAUTION Fire hazard posed by batteries The batteries used may pose a fire or burn hazard if handled incorrectly. 1. Do not try to charge, open, heat or burn the batteries.
- Page 5 1. General safety instructions Transponder (MobileKey) (Manual) 5 / 13 Communication interference due to metallic surfaces This product communicates wirelessly. Metallic surfaces can greatly reduce the range of the product. Do not mount or place the product on or near metallic surfaces.
-
Page 6: How It Works
2. How it works Transponder (MobileKey) (Manual) 6 / 13 2 How it works To carry out an action, the user holds the transponder close to the digital lock and presses the transponder button. The transponder may be held at a distance of up to 40 cm for locking cylinders and SmartHandles and up to 120 cm for SmartRelays. -
Page 7: Battery Replacement
3. Battery replacement Transponder (MobileKey) (Manual) 7 / 13 3 Battery replacement The transponder battery can be replaced at any time. 1. Carefully open the casing at the notches, so that you can see the bat- tery. 2. Open the battery holder. - Page 8 3. Battery replacement Transponder (MobileKey) (Manual) 8 / 13 CAUTION Lack of power supply on battery replacement The transponder may lose data due to the interruption in power supply. Do not interrupt the power supply for longer than two minutes. Do not press...
-
Page 9: Technical Data
4. Technical data Transponder (MobileKey) (Manual) 9 / 13 4 Technical data Weatherproof plastic Material (polyamide) Casing: black Colours Housing Buttons: different col- ours Diameter 42.0 mm Height 13.7 mm Temperature range -20 °C to 60 °C IP65 Standard protection Ambient conditions rating IP66 (.SPEZ version) -
Page 10: Dimensions
4. Technical data Transponder (MobileKey) (Manual) 10 / 13 4.1 Dimensions... -
Page 11: Eu/Uk Declaration Of Conformity
5. EU/UK Declaration of conformity Transponder (MobileKey) (Manual) 11 / 13 5 EU/UK Declaration of conformity The company SimonsVoss Technologies GmbH hereby declares that article MK.TRA2.G2 complies with the following guidelines: 2014/53/EU "Radio equipment" as well as the corresponding UK statutory 2017 No. 1206 "Radio equipment"... -
Page 12: Help And Other Information
6. Help and other information Transponder (MobileKey) (Manual) 12 / 13 6 Help and other information Information material/documents You will find detailed information on operation and configuration and other documents on the website: www.simons-voss.com/en/documents.html Declarations of conformity You will find declarations of conformity and other certificates on the website: www.simons-voss.com/en/certificates.html... - Page 13 The content of this document must not be copied, distributed or modified. More informa- tion about this product can be found on the SimonsVoss website. Subject to technical changes. SimonsVoss and MobileKey are registered brands belonging to SimonsVoss Technologies GmbH.
