- Page 1 PROGRAMMING TRANSPONDER 3067 PRODUCT MANUAL Version: Draft 2012 v02 based on April 2007_V05.04.2007 Date: Oct 2019...
-
Page 2: Table Of Contents
PROGRAMMING TRANSPONDER 3067 PRODUCT MANUAL Contents 1 SAFETY INSTRUCTIONS....................3 2 INTRODUCTION ......................3 3 SECURITY CARD ......................4 4 PROGRAMMING INSTRUCTIONS................4 4.1 Initial programming....................4 4.2 Adding a new transponder ................5 4.3 Reading transponders..................5 4.4 Blocking lost transponders ................6 4.5 Emergency opening ..................6 ... -
Page 3: Safety Instructions
German version applies in cases of doubt. INTRODUCTION Programming Transponder 3067 is suitable for small locking systems which the sys- tem administrator does not wish to manage using a software application or for which they do not wish to buy an additional programming device (Smart CD). -
Page 4: Security Card
The whole system is protected by a password, which has already been saved onto the Programming Transponder 3067 in the factory. The locking system password is provided on the security card. The password is concealed by a scratch-off panel and must NOT be scratched to reveal the password when programming. -
Page 5: Adding A New Transponder
PROGRAMMING TRANSPONDER 3067 PRODUCT MANUAL Programme other locking cylinders as described above. Ensure that you observe the minimum distance of 1m between the locking cylin- der and the programming transponder when uploading transponder authorisa- tions (Steps 1 and 2). LED flickers and then flashes red four times:... -
Page 6: Blocking Lost Transponders
PROGRAMMING TRANSPONDER 3067 PRODUCT MANUAL Blocking lost transponders The procedure that you need to take depends on whether you know the ID number of the lost transponder or not. If you do not know, proceed as follows: Press the programming transponder button until the LED flashes red. -
Page 7: Error Signals
PROGRAMMING TRANSPONDER 3067 PRODUCT MANUAL Hold the programming transponder about 10 to 20 cm away from the locking cylinder and press the button briefly. Warning: you must press the button while the LED is flashing. Error signals If you receive the following signals out of sequence during the programming process,... -
Page 8: Battery Replacement
PROGRAMMING TRANSPONDER 3067 PRODUCT MANUAL Once you have authorised the new programming transponder for all cylinders, press its button until the LED stops flashing. The new programming transponder is now ready for use. BATTERY REPLACEMENT You cannot change the battery of the programming transponder yourself. Contact the sales department (if necessary via your specialist trade partner).
