Page 1
1.0
GENERAL INFORMATION
1.1.
AREA OF USE
The transponder terminal is a combination between a wall-mounted reader and its
associated software application. This combination is used to re-programme trans-
ponders. It allows the administrator to prepare changes and updates to the trans-
ponder configuration which are implemented when the user activates the trans-
ponder, but the administrator does not need to present when the update actually
takes place.
1.2.
PREREQUISITES
The following components are required to use the transponder terminal:
LSM.BUSINESS
•
LSM.ONLINE
•
•
Installed and configured Comm Node server
Server network connection
•
Transponder terminal network connection
•
Communication between server and transponder terminal;
•
you will need to take router and firewall configuration into account!
Note:
Please note that the program and its associated configuration tool are only available
in English.
Contact your IT department in advance regarding questions about setting up the in-
ternal network connection. System administrator rights are required for software in-
stallation and configuration.
MANUAL LSM–TRANSPONDERTERMINAL
an installed LSM Business Edition as a minimum
online module
Version: Juli 2012 v1.6
Advertisement
Related Manuals for Simons Voss Technologies LSM
Summary of Contents for Simons Voss Technologies LSM
- Page 1 1.2. PREREQUISITES The following components are required to use the transponder terminal: LSM.BUSINESS an installed LSM Business Edition as a minimum • LSM.ONLINE online module • •...
-
Page 2: Hardware Configuration
MANUAL LSM–TRANSPONDERTERMINAL Page 2 INITIAL OPERATION OF TRANSPONDER TERMINAL PROCEDURE Hardware configuration • Software installation • • Configuration of software components 2.1. HARDWARE CONFIGURATION To put the transponder terminal into operation, you need to connect it to an accessi- ble IP network. We recommend using a DHCP server to ensure better availability. - Page 3 MANUAL LSM–TRANSPONDERTERMINAL Page 3 2.1.1 INSTALLATION OF THE XTADMINXXL APPLICATION The XTAdminXXL tool can be used to configure the transponder terminal. This pro- gram will enable you to look for the transponder terminal even if you do not know the IP address.
- Page 4 MANUAL LSM–TRANSPONDERTERMINAL Page 4 Confirm by pressing Next > to start installation. Installation has now been successfully completed. Finish the installation by pressing Close. 2.1.2 SETTING THE IP ADDRESS ON THE TRANSPONDER TERMINAL Launch the 'XTAdminXXL' application. Once the application is...
- Page 5 MANUAL LSM–TRANSPONDERTERMINAL Page 5 Select SetIP, then enter the required IP address and confirm by clicking on 2.1.3 SETTING UP THE STANDARD GATEWAY Launch the 'XTAdminXXL' application. Select Telnet and enter the password 'XT' to register the components. First change the login...
- Page 6 MANUAL LSM–TRANSPONDERTERMINAL Page 6 Select '6' for IP MENU and then confirm by pressing 'Enter' Please check the address in Row 3. If necessary, change the address by entering '3=XXX.XXX.XXX.XXX' in the prompt and then con- firm by pressing 'Enter'.
- Page 7 MANUAL LSM–TRANSPONDERTERMINAL Page 7 Select '1' for Smart CD Settings MENU and then confirm by pressing 'Enter' Select '1' for Config Menu and then confirm by press- ing 'Enter' Please check the value in Row 'b=Emceed'. If neces- sary, change the value in 'c000' by typing ‘b=c000’...
- Page 8 MANUAL LSM–TRANSPONDERTERMINAL Page 8 2.1.6 TESTING THE TRANSPONDER TERMINAL The transponder terminal functions and settings can be tested using the 'TestTran- sTerm.exe' software. You need to launch the software in the directory where the TestTransTerm.exe file is saved. This test enables you to check the readout from a G2 Lock (cylinder, Smart Relay re- quired) and the event button function (right-hand side of the housing).
- Page 9 MANUAL LSM–TRANSPONDERTERMINAL Page 9 Example: Example (everything written in a single row): \TestTransTerm>TestTransTerm.exe -h 192.168.1.17 -w 4000 -c 3000 -b 5 -r 1 D:\>TestTransTerm.exe -h 192.168.1.17 -w 4000 -c 3000 -b 5 -r 1 2012/06/30 12:02:40: Sent: <STI> 2012/06/30 12:02:40: Recv: <00000 41>...
-
Page 10: Software Installation
MANUAL LSM–TRANSPONDERTERMINAL Page 10 2.2. RESETTING TO ORIGINAL DELIVERY SETTINGS Important: Whenever you press this button, you will always need to re-configure the de- vice. This may not be possible on site during installation. The blue factory default reset button on the rear of the transponder terminal resets the settings to their initial state. - Page 11 MANUAL LSM–TRANSPONDERTERMINAL Page 11 Confirm by pressing Next to start the installation Read the licence condi- tions and accept. Then select Next. Enter the user details and then select Next. Then confirm by pressing Next. Version: Juli 2012 v1.6...
- Page 12 MANUAL LSM–TRANSPONDERTERMINAL Page 12 Select complete installa- tion by pressing Complete and confirm by pressing Next. Then confirm by pressing Install. Finish the installation by pressing on Finish. The programs are installed in the following folders by default: Service C:\Program Files (x86)\SimonsVoss\TransponderTerminalService...
-
Page 13: Software Configuration
You can check this is the case as described below. If it has not yet been installed, please do so now. You will find the installation instructions in the 'Communi- cation node' section in the 'LSM – IT Administration' manual. Checking the Comm Node server Launch LSM •... - Page 14 MANUAL LSM–TRANSPONDERTERMINAL Page 14 Edit Connection can be edited Connection can be added Remove Connection can be removed You can verify availability and, consequently, the correct functioning of the Comm Node by using the PING function. The Comm Node will re-...
- Page 15 MANUAL LSM–TRANSPONDERTERMINAL Page 15 'IP port' IP port used for communication 'Description' Blank field to describe the connection 2.4.3 GENERATE CONFIGURATION FILES GENERAL INFORMATION The configuration files are needed to inform a communication node (Comm Node) which devices are connected and how it can access the database.
- Page 16 MANUAL LSM–TRANSPONDERTERMINAL Page 16 Network • • Communication node • Add configuration data (see below) • Generate and save Config files • • Copy files (netcfg.xml, appcfg.xml, msgcfg.xml) into the 'TransTerm console' installation directory 'Name' Name of the connection in the software...
-
Page 17: Setting Up Ip Addresses
MANUAL LSM–TRANSPONDERTERMINAL Page 17 Re-start 'SimonsVoss Comm Node server' • NOTE: • The files can also be created on any computer with a GUI and then saved via the network. The config files must be generated again each time that you change a Comm •... - Page 18 Launch the "Transponder Terminal 3.1" software in the start menu. Once the software has been launched, you will see the login mask shown here on the left-hand side. Log on using the LSM user name which is authorised to programme the trans- ponders. 'Database'...
- Page 19 MANUAL LSM–TRANSPONDERTERMINAL Page 19 3.2. OPERATING THE TRANSPONDER TERMINAL CONSOLE The console can be used to display the status of the individual transponder terminals. Other options can also be selected. 'Counter' Overview of the different status messages 'State' Overview of the current operating time...
- Page 20 MANUAL LSM–TRANSPONDERTERMINAL Page 20 Additional data can be retrieved in the overview for the individual trans- ponder terminals. The programming device integrated into the trans- ponder terminal can also be checked using the Check CD. 'Hosts' Overview of the integrated transponder ter- minals (from nodes.csv)
