US Robotics Wireless Nd1 Router User Manual page 51

Wireless Nd1 Router User Guide
3. Select Advanced and select or enter the values shown below:
Device: Internet Printing Protocol using HTTP
Device Name: HP Deskjet 990c (example only, select your printer)
Device URI: http://192.168.2.1:1631/printers/My_Printer
Note: The Device URI information is case-sensitive and must be entered exactly
as it is listed on the Printer location section on the router's
have modified the IP address of your router, then use your router's IP address in
place of 192.168.2.1.
9. Select the make and model of your printer in the Printer Model field. Click Add.
file:///G|/CSO/Documentation/Documentation%20-%20Draf...Mach-1%20Router/User%20Guide/English/mac_printer.html (4 of 7)9/14/2006 2:44:21 PM
Status page. If you
