- Page 1 Wireless Starter Kit 802.11g 54Mbps Router 802.11g 54Mbps USB Adapter Installation Guide Guide d'installation Installationsanleitung Guida all'installazione rapida Guía breve de instalación Beknopte installatiegids R24.0496.00...
- Page 3 English 802.11g 54Mbps Router Installation ... 1 802.11g 54Mbps USB Adapter Installation... 5 Troubleshooting and Support... 9...
- Page 5 USR5470 Package Contents USR5462 802.11g 54Mbps Router 19VAC Power Supply Installation Guide 802.11g 54Mbps Router Installation Prepare for Installation Note: It is important that you have your serial number written down before you install the 802.11g 54Mbps Router. You can find your serial number on the bottom label of the 802.11g 54Mbps Router.
- Page 6 Step Two: Connect your 802.11g 54Mbps Router to your computer and con- nect the power supply Connect one end of the supplied Ethernet cable to your computer’s Ethernet adapter. Connect the other end to one of the LAN ports on the 802.11g 54Mbps Router. Turn on your cable or DSL modem.
- Page 7 Launch a Web browser. In the location or address line of your Web browser, type http://192.168.2.1 to access the Web User Interface. After the connection is established, you will see the Web User Interface. The default pass- word is admin. Click Login. When you access the Web User Interface, click the Setup Wizard.
- Page 8 Note: Refer to the “Configuring the 802.11g 54Mbps Router” section in the User Guide on the Installation CD-ROM for more detailed configuration information. Contact your ISP if you have any questions about your WAN type or your connection information. The installation procedure for the 802.11g 54Mbps Router is now complete. Proceed to the Instal- lation procedure for the 802.11g 54Mbps USB Adapter.
-
Page 9: Prepare For Installation
802.11g 54Mbps USB Adapter Installation Prepare for Installation ATTENTION: You must install your software and drivers before you physically connect the 802.11g 54Mbps USB Adapter. Model Number USR5422 Note: For the most updated information, visit: http://www.usr.com/support Turn on your desktop or laptop computer. Type your password if you are prompted to do so. Note: Be sure to find out what letter your CD-ROM drive uses before you begin installing your new product. - Page 10 your preferred language. Read the license agreement and click Yes. Select the 802.11g 54Mbps USB Adapter and then click Software. Click Wireless USB Adapter Utility and Drivers. Follow the on-screen instructions to finish the installation procedure. If you are prompted, restart your computer and continue to follow the on-screen instructions. Step Two: Install the 802.11g 54Mbps USB Adapter to your computer.
-
Page 11: Wireless Router
To scan for a Wireless Router, click the Site Survey tab. Locate the Wireless Router you want to connect to in the list and double-click it. If you do not see the Wireless Router in the list, click Scan to search for the Wireless Router. The default SSID of the 802.11g 54Mbps Router is USR5562. - Page 12 Congratulations! You have finished installing the 802.11g 54Mbps USB Adapter and the 802.11g 54Mbps Router. You should now have shared Internet access through the 802.11g 54Mbps Router. For troubleshooting and technical support information, refer to the Troubleshooting section in this Guide or to the User Guide on the U.S. Robotics Installation CD-ROM. Register your products •...
-
Page 13: Troubleshooting And Support
Troubleshooting and Support If you have any difficulties connecting to the 802.11g 54Mbps Router, check the following top three issues and see if they apply to your situation. • If you are attempting to create a wireless connection but cannot connect to the 802.11g 54Mbps Router, make sure each wireless card is set to Infrastructure mode. - Page 14 Direct connection to the Internet and click OK. I am no longer able to access the Internet through the 802.11g 54Mbps Router. Possible Solution: Make sure that the power cord and all the Ethernet cables are connected correctly. This includes the cables connecting the 802.11g 54Mbps Router, the modem, and all the computers.
- Page 15 Check the Configuration Utility icon for the 802.11g 54Mbps USB Adapter in the system tray to confirm the connection status. If you are connected to your Wireless Router, the icon will be green or yellow. If the icon is red, open the Configuration Utility and scan the area so that you can con- nect to the correct wireless network.
- Page 16 The default gateway address is the IP address of your wireless router. Check your wireless router to verify this address. This will ensure that you can connect to the wireless network. If you cannot complete this ping, make sure your wireless settings are correct and that the 802.11g 54Mbps USB Adapter is fully inserted into a USB port on your com-...
- Page 17 different letter, type that letter in place of “D”) and click OK. I accidentally clicked Cancel during the installation procedure. Possible Solution: Remove and reinsert the U.S. Robotics Installation CD-ROM into your CD-ROM drive. Repeat the installation procedure of the software before you install any hardware. My computer does not recognise the 802.11g 54Mbps USB Adapter.
- Page 18 Are You Still Having Problems? Go to the User Guide on the Installation CD-ROM. More configuration and troubleshooting information is available in the User Guide on the Installa- tion CD-ROM. Go to the Support section of the U.S. Robotics Web site at www.usr.com Many of the most common difficulties users experience have been addressed in the FAQ and Troubleshooting Web pages for your specific product.
- Page 20 Printed in China...
