Drive Technology \ Drive Automation \ System Integration \ Services
Manual
Mechatronic Drive System
®
MOVIGEAR
B
Functional Safety
Edition 10/2012
19374410 / EN

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MOVIGEAR B and is the answer not in the manual?

Questions and answers

Related Manuals for SEW-Eurodrive MOVIGEAR B

Summary of Contents for SEW-Eurodrive MOVIGEAR B

  • Page 1 Drive Technology \ Drive Automation \ System Integration \ Services Manual Mechatronic Drive System ® MOVIGEAR Functional Safety Edition 10/2012 19374410 / EN...
  • Page 2 SEW-EURODRIVE—Driving the world...

  • Page 3: Table Of Contents

    Contents Contents General Information .................... 4 How to use this documentation ..............4 Underlying standards .................. 4 Structure of the safety notes ............... 4 Rights to claim under limited warranty ............5 Exclusion of liability..................5 Content of the documentation ..............5 Other applicable documentation ..............

  • Page 4: General Information

    General Information How to use this documentation General Information How to use this documentation This documentation is an integral part of the product and contains important information on operation and service. The documentation is intended for all employees who perform assembly, installation, startup and service work on the product.

  • Page 5: Rights To Claim Under Limited Warranty

    General Information Rights to claim under limited warranty 1.3.3 Structure of the embedded safety notes Embedded safety notes are directly integrated in the instructions just before the descrip- tion of the dangerous action. This is the formal structure of an embedded safety note: •...

  • Page 6: Integrated Safety Technology

    Integrated Safety Technology Safe condition Integrated Safety Technology ® The safety technology of MOVIGEAR described below has been developed and tested in accordance with the following safety requirements: • SIL 3 according to EN 61800-5-2:2007 • PL e according to EN ISO 13849-1:2008 This was certified by TÜV Nord.
  • Page 7 Integrated Safety Technology Safety concept ® 2.2.1 Schematic representation "Safety concept for MOVIGEAR " The following figure shows a schematic representation of the safety concept for ® MOVIGEAR Safety μC 2463070859 Safety controller/safety relay external Connection "STO+" Connection "STO-" Motor phase Motor Manual –...

  • Page 8: Safety Functions

    Integrated Safety Technology Safety functions Safety functions The following drive-related safety functions can be used: • STO (safe torque off according to IEC 61800-5-2) by disconnecting the STO input. If the STO function is activated, the frequency inverter no longer supplies power to the motor for generating torque.
  • Page 9 Integrated Safety Technology Safety functions • SS1(c) (safe stop 1, function variant c according to IEC 61800-5-2) by means of suit- able external control (e.g. safety relay with delayed disconnection) The following sequence is mandatory: – Decelerate the drive using an appropriate brake ramp specified via setpoints. –...

  • Page 10: Restrictions

    Integrated Safety Technology Restrictions Restrictions WARNING The safety concept is only suitable for performing mechanical work on the system/ma- chine components. If the STO signal is disconnected, the supply system voltage is still present at the ® MOVIGEAR DC link. Severe or fatal injuries from electric shock.

  • Page 11: Safety Conditions

    Safety Conditions Approved units Safety Conditions ® The requirement for safe operation is that the safety functions of MOVIGEAR are prop- erly integrated into an application-specific higher-level safety function. A system/ma- chine-specific risk assessment must be carried out through the system/machine manu- ®...

  • Page 12: Installation Requirements

    Safety Conditions Installation requirements Installation requirements • Power lines and STO control lines have to be routed in separate cables. ® • The length of the cable from the safety controller to MOVIGEAR must not exceed 100 m. • The wiring technology used must comply with EN60204-1. •...
  • Page 13 Safety Conditions Installation requirements WARNING ® No safe disconnection of the MOVIGEAR drive unit. Severe or fatal injuries. ® • Do not use the 24 V output for safety-related applications with MOVIGEAR drive units. ® • You may only jumper the STO input with 24 V when the MOVIGEAR drive unit need not fulfill any safety function.

  • Page 14: External Safety Controller Requirements

    Safety Conditions External safety controller requirements External safety controller requirements A safety relay can be used as an alternative to a safety controller. The following require- ments apply analogously. • The safety controller and all other safety-related subsystems must be approved and tested for at least that safety class which is required in the overall system for the re- spective, application-related safety function.
  • Page 15 Safety Conditions External safety controller requirements ® • Note the following for two-pole disconnection of MOVIGEAR with tested, safe out- puts: – When disconnected, the switch-on test pulses may never occur at the plus and minus output at the same time. –...

  • Page 16: Startup Requirements

    Safety Conditions Startup requirements Startup requirements • To validate the implemented safety functions, they must be documented and checked after successful startup (validation). Observe the limitations for safety functions in chapter "Limitations" for the validation of the safety functions. Non-safety-relevant parts and components that affect the re- sult of the validation test must be deactivated, if necessary.

  • Page 17: Technical Data

    Technical Data Technical Data ® The table below shows the technical data for MOVIGEAR relating to the integrated ® safety technology. The technical data and approvals in the respective MOVIGEAR erating instructions must be observed in addition. Technical data of the STO input Min.

  • Page 18: Appendix

    Appendix ® Unit variants with DynaStop Appendix ® Unit variants with DynaStop WARNING ® The electrodynamic deceleration function DynaStop does not allow for a definite stop at a position. Severe or fatal injuries. • Do not use the electrodynamic deceleration function for hoists. ®...
  • Page 19 Appendix ® Unit variants with DynaStop ® The following figure shows the use of the DynaStop function in connection with the STO function: Deceleration ramp Speed Drive enable signal Control signal active ® DynaStop inactive 9007201718955403 Parameter setting "8584.0 – Brake function": 1 = ON (All variants) Factory setting of parameter "8584.0 –...
  • Page 20 Appendix ® Unit variants with DynaStop 5.1.2 Behavior when STO is activated before standstill NOTICE ® Depending on the setting in parameter "9833.20", the DynaStop function can be ac- tivated outside the permitted operating range. This can cause a high torque load / high motor currents, which may damage the drive unit and the application.
  • Page 21 Appendix ® Unit variants with DynaStop The following figure shows the behavior when STO is activated before the motor is at standstill in connection with the following parameter setting: ® Parameter "9833.20 – Activation of DynaStop for STO": 0 = NO (Factory setting / recommended settings): Speed Deceleration...

  • Page 22: Connection Variants

    Appendix Connection variants Connection variants 5.2.1 Position of the terminals for safe torque off (STO) The following figure shows an example of the terminal positions at MGF..-DSC-B for ® safe torque off (STO) of MOVIGEAR 11 12 2552708747 5.2.2 Assignment of the terminals for safe torque off (STO) The following figure shows the terminal assignment for safe torque off (STO) of ®...
  • Page 23 Appendix Connection variants 5.2.3 Position of the optional plug connectors for safe torque off (STO) The STO plug connectors X5502 "STO–IN" and X5503 "STO–OUT" are always in "po- sition 3" as shown in the following figure: Plug connector Color Location Position X5502: STO –...
  • Page 24 Appendix Connection variants 5.2.4 Assignment of the optional plug connectors for safe torque off (STO) X5502: STO – IN WARNING ® No safe disconnection of the MOVIGEAR drive unit. Severe or fatal injuries. • Do not use the 24 V output (pins 1 and 3) for safety-related applications with ®...
  • Page 25 Appendix Connection variants The following table provides an overview of the cables available for this connection: Length/ Operating voltage Connection cable Installation type Part number 1 812 496 8 Variable DC 60 V M12, 5-pole, A-coded M12, 5-pole, A-coded Part number 1 812 497 6 Variable DC 60 V Open...
  • Page 26 Appendix Connection variants X5503: STO – The following table provides information about this connection: Function Connection for safe torque off (STO) for looping through Connection type M12, 5-pole, male, A-coded Wiring diagram 2264818187 Assignment Name Function res. Reserved STO − Output STO –...
  • Page 27 Appendix Connection variants Connection cable INFORMATION Use only shielded cables for this connection and only suitable plug connectors that connect the shield with the unit in an HF-capable manner. The following table provides an overview of the cables available for this connection: Length/ Operating voltage...

  • Page 28: Connection Of An External Safety Relay For Sto

    Appendix Connection of an external safety relay for STO Connection of an external safety relay for STO 5.3.1 Connection via terminals The following figure shows a connection example with a safety relay and disconnection of all poles: DC +24 V 1 STO + IN 2 STO ̶...
  • Page 29 Appendix Connection of an external safety relay for STO 5.3.3 Connection via terminals – group disconnection The following figure shows a connection example for disconnection of group drives with a safety relay: DC +24 V 1 STO + IN 2 STO ̶ 11 STO + OUT 12 STO ̶...
  • Page 30 Appendix Connection of an external safety relay for STO 5.3.4 Connection via M12 plug connector – group disconnection The following figure shows a connection example for disconnection of group drives with a safety relay: DC +24 V X5502 X5503 X5502 X5503 2468653451 ®...
  • Page 31 Appendix Connection of an external safety relay for STO 5.3.5 STO signal for group disconnection ® Requirements For group drives, the STO signal for several MOVIGEAR drives can be provided by a single safety relay. The following requirements must be met: •...

  • Page 32: Connection Of An External Safety Controller For Sto

    Appendix Connection of an external safety controller for STO Connection of an external safety controller for STO 5.4.1 Connection via terminals The following figure shows a connection example with a safety controller and disconnec- tion of all poles for STO: DOn_P 1 STO + IN 2 STO ̶...
  • Page 33 Appendix Connection of an external safety controller for STO 5.4.3 Connection via terminals – group disconnection The following figure shows a connection example for disconnection of group drives with a safety controller: DOn_P 1 STO + IN 2 STO ̶ DOn_M 11 STO + OUT 12 STO ̶...
  • Page 34 Appendix Connection of an external safety controller for STO 5.4.4 Connection via M12 plug connector – group disconnection The following figure shows a connection example for disconnection of group drives with a safety controller: X5502 DOn_P DOn_M X5503 X5502 X5503 2808077707 ®...
  • Page 35 Appendix Connection of an external safety controller for STO 5.4.5 STO signal for group disconnection ® Requirements For group drives, the STO signal for several MOVIGEAR drives can be provided by a single safety controller. The following requirements must be met: •...

  • Page 36: Index

    Index Index Application options, approved ........11 Group disconnection Area of application ...........4 Connection via M12 plug connector ....30, 34 Connection via terminals ......29, 33 STO signal for group disconnection.....31, 35 Cable length .............31, 35 Checking the disconnection device......16 Conditions, safety ..........11 Installation instructions ..........12 Approved units ...........11 External safety controller requirements .....14...
  • Page 37 Index Safety notes Structure of the embedded ........5 Technical data Structure of the section-related......4 Safety characteristics.........17 Safety notes STO input............17 Designation in the documentation......4 Terminals for STO ..........22 Safety relay Assignment ............22 Requirements.............14 Position ..............22 Sample circuit ............15 Test setup ..............16 Safety technology Trademarks..............5 Restrictions ............10...
  • Page 40 SEW-EURODRIVE—Driving the world SEW-EURODRIVE Driving the world SEW-EURODRIVE GmbH & Co KG P.O. Box 3023 D-76642 Bruchsal/Germany Phone +49 7251 75-0 Fax +49 7251 75-1970 sew@sew-eurodrive.com www.sew-eurodrive.com...
