- Page 1 Range Hood User Manual Model: H342.6 TC H342.7 TC H342.9 TC H365.7 H365.7B...
-
Page 2: Table Of Contents
Content 1…………………………………..………………………………Safety instructions 2…………………………………..………………………………Installation 3…………………………………..………………………………Start using your cooker hood 4…………………………………..………………………………Troubleshooting 5…………………………………..………………………………Maintenance and cleaning 6…………………………………..………………………………Environment protection... -
Page 3: Safety Instructions
SAFETY INSTRUCTIONS his manual explains the proper installation and use of your cooker hood, please read it carefully before using even if you are familiar with the product. The manual should be kept in a safe place for future reference. These instructions shall also be available in an alternative format, e.g. - Page 4 hob and the lowest part of the cooker maintenance shall not be made by hood that distance must be: children without supervision. Gas cookers: 75 cm Electric cookers: 65 cm Coal or oil cookers: 75 cm ● ake sure the ducting has no bends sharper than 90 degrees as this will reduce the efficiency of the cooker hood.
- Page 5 ● ● leaning and user maintenance shall ARNING: Danger of fire: do not not be made by children without store items on the cooking surfaces. supervision. ● steam cleaner is not to be used. ● hen the cooker hood and ●...
- Page 6 3. To install onto the wall, drill 4 holes of Ø 8mm on a suitable place according with the centre distance of hole in the back of the cooker hood.See Pic 2 4. Insert the nut into the holes. 5. Insert the screws into the nuts and tight. 6.
-
Page 7: Installation
Pic 3 Noice: There are 2 methods for ventilation, including ' horizontal ventilation' and ' vertical ventilation'. Please pay attention to the ventilation method when installation. Horizontal ventilation: See Pic 4A, please use the cover to seal the outlet on the top, then the air can be vented from back. -
Page 8: Start Using Your Cooker Hood
For safety reason, please use only the same WARNING: size of fixing or mounting screw which are recommended in this instruction manual. Failure to install the screws or fixing device in accordance with these instructions may result in electrical hazards. Start Using Your Cooker Hood 1. -
Page 9: Troubleshooting
2. Touch control with LED display 1. Press the “Power” button, the button control the “on” & “off ” of the hood. 2. Keep pressing the button “Speed”, the motor runs as low / mid / high / low / mid…, the speed runs circularly;... -
Page 10: Maintenance And Cleaning
opening the unit. MAINTENANCE AND CLEANING Caution: • Before maintenance or cleaning is carried out, the cooker hood should be disconnected from the main power supply. Ensure that the cooker hood is switched off at the wall socket and the plug removed. - Page 11 INSTALLING GREASE MESH FILTERS • To install filters for the following four steps . - Angle the filter into slots at the back of the hood. - Push the button on handle of the filter. - Release the handle once the filter fits into a resting position. - Repeat to install all filters.
-
Page 12: Environment Protection
carrying out any operations on the appliance. When handling bulb, make sure it is completely cool down before any direct contact to hands. When handling globes hold with a cloth or gloves to ensure perspiration does not come in contact with the globe as this can reduce the life of the globe. - Page 13 INFORMATION FOR DISMANTLING Do not dismantle the appliance in a way which is not shown in the user manual. The appliance could not be dismantled by user. At the end of life, the appliance should not be disposed of with household waste. Check with you Local Authority or retainer for recycling advice.
- Page 14 MALLOCA VIETNAM COMPANY LIMITED Showroom: 279 Nguyen Van Troi Street, Ward 10, Phu Nhuan District, HCM City Tel: (84) 28 39975 893 / 94 Fax: (84) 28 38447 102 - (84) 28 38633 882 Email: info@malloca.com Customer Care: Hotline: 1800 12 12...
