progressive automations TY-01 Assembly Instructions Manual page 10

cont.
10
(3) Reset the system: if there has some problem of the system,
for example, the cable connection problem, the tV lift can not
move when you press the uP/DoWn buttons, you should try to
Reset the system as following procedure:
warning: the tv lift will move to the zero position when reset.
Be sure there is no obstruction under the tv set.
Reconnect the cables again. turn off the power of the control box
and turn on the power again. Be sure the green leD on the control
box is light on.
Press the Reset button on handset and hold it. after 5 seconds,
tV lift will move down slowly and then to the zero position and
then move up 7 mm and stop. You finish the Reset procedure.
During the Reset procedure, you should hold the Reset
button and the leD light on the handset will blink during the
Reset procedure. the leD on the handset will turn off after
finish the Reset. You can operate the system now.
tv Lift (tY-01)
AsseMBLY
iNstrUCtioNs
feAtUres:
Adjustable height:
39"
Lifting column speed:
0.98" per second (no load)
duty Cycle:
10%
remote distance:
5m
HOW TO ORDER
1.800.676.6123
sales@progressiveautomations.com
www.progressiveautomations.com
page 9
