  • Page 1: Table Of Contents

    TY-01 User Manual Contents Page 2 Parts Page 2 Dimensions In Inches Specifications Page 2 Tools Required Page 3 Page 3 Hardware Page 4-6 Assembly Instructions...

  • Page 2: Parts

    Parts Control box Wireless remote Dimensions In Inches 28.98 1.26 1.97 Retracted: 31.89” extended: 70.89” 0.39 1.18 5.67 5.55 7.09 Specifications Dynamic Load 130 lbs Static Load 150 lbs Speed at Full Load: 0.98"/sec Stroke Length: 39" Retracted Length 31.89" Weight: 42 lbs Input Voltage:...

  • Page 3: Tools Required

    Tools Required philips head screw allen Wrenches M6 M8 Hardware Spring washers M6 Screws M5×50 Screws M6×16 Hex Bolts Hex Bolts Nuts M8 Washers M6 M6×14 M8×16 type mounting base column Washers m6 spring washers m6 Hex Bolts m6x14 screws m5x50 tV mounting bracket nuts m8 mounting bracket...

  • Page 4: Assembly Instructions

    Assembly Instructions use 4 Hex Bolts m6x16, each with spring washer and Washer, to attach use 4 screws m6x16, to assemble the tV mounting Bases to the bottom of the column. tighten the 4 screws (2 per side). bracket as following. use 4 Hex Bolts m8x16, each with spring washer and Washer, to attach tV use 4 Hex Bolts m6x16, each with spring washer and Washer, mounting bracket on to the mounting bracket.
  • Page 5 Assembly Instructions secure another 2 parts of the tV mounting bracket onto operating: You can use the remote or handset operate the backside of the tV set with 4 screws included with the tV lift. tV set. and then hang the tV set onto the tV mounting (1) Remote: Press S1+S3, TV lift move up, press S2+S3, TV bracket as following.
  • Page 6 Assembly Instructions Reset the TOP and BOTTOM position: You may want to reset Cont. the TOP position higher than the original TOP position and BOTTOM position lower than the original BOTTOM position. To reset the UPPER and LOWER limits, please follow step 8. Some other information: (1) Frequency study: If you lose the wireless remote and buy a new remote from your local distributor, the frequency of the...
