progressive automations TY-01 User Manual
Tv lift
Hide thumbs
Also See for TY-01:
- Assembly instructions manual (10 pages) ,
- User manual (8 pages) ,
- User manual (6 pages)
Related Manuals for progressive automations TY-01
Summary of Contents for progressive automations TY-01
-
Page 1: Table Of Contents
TY-01 User Manual Contents Page 2 Caution/Liability Page 3 Parts Page 3 Dimensions In Inches Specifications Page 3 Page 4 Tools Required Page 4 Hardware Assembly Instructions Page 5-6 Reset Procedure Page 7 Pairing Wireless Remote Page 7... -
Page 2: Caution/Liability
Caution Make sure no obstacles are in the lift's path. Make sure the lift is not touching any walls. Make sure all cords are appropriate length to accommodate the change in height. Keep children away from electric TV lift, control units and remotes. There is a risk of injury and electric shock Keep all electrical components away from liquids. -
Page 3: Parts
Parts Wireless Remote Control Box Wired Handset Dimensions 28.98" 1.26" Retracted: 31.89” 1.97" Extended: 70.89” 0.39" 2.95" 1.18" 5.67" 2.95" 5.55" 7.09" Specifications Dynamic Load 130 lbs Static Load 150 lbs Speed at Full Load: 1.18"/sec Stroke Length: 39" Retracted Length 31.89"... -
Page 4: Tools Required
Tools Required Allen Wrenches Philips head screw M6 M8 Hardware Spring washers M6 Screws M5×50 Screws M6×16 Hex Bolts Hex Bolts Nuts M8 Washers M6 M6×14 M8×16 Type Mounting base Column Washers M6 Spring washers M6 Hex Bolts M6x14 Screws M5x50 TV mounting bracket Nuts M8 Mounting bracket... -
Page 5: Assembly Instructions
Assembly Instructions Use 4 Hex Bolts M6x16, each with Spring washer and Washer, Use 4 Screws M6x16, to assemble the TV mounting to attach Bases to the bottom of the Column. Tighten the 4 bracket as following. Screws (2 per side). Use 4 Hex Bolts M8x16, each with Spring washer and Use 4 Hex Bolts M6x16, each with Spring washer and Washer, Washer, to attach TV mounting bracket on to the Mounting... - Page 6 Assembly Instructions Secure another 2 parts of the TV mounting bracket onto the Operating: You can use the wireless remote or handset to backside of the TV set with 4 screws included with TV set. And operate the TV lift. then hang the TV set onto the TV mounting bracket as following.
-
Page 7: Reset Procedure
Reset Procedure The handset remote has two different modes which indicate Pairing the Wireless Remote the state of the TV lift Pairing the wireless remote is required before use There are • If the red LED is blinking at 0.5 second intervals, the device is two options for pairing the wireless remote in RESET mode.
