- Page 1 LaneHawk Intelligent Lighting and Camera Unit Quick Reference Guide...
- Page 2 U.S.A. and the E.U. All other brand and product names may be trademarks of their respective owners. LaneHawk is a registered trademark of Datalogic ADC, Inc. in the U.S.A. and the E.U. Patents for patent list.
-
Page 3: Nomenclature And Labeling
Quick Reference Guide Introduction These instructions provide basic connection and usage information for the LaneHawk intelligent lighting and camera unit that operates as a Bottom of Basket (BoB) loss prevention unit. Nomenclature and Labeling Figure 1 shows the unit, its cables and the position of the labels and connector bulkhead on its back side. - Page 4 LaneHawk, then to the appropriate ethernet wall jack. Next, plug the power connector from the AC adapter (#2 in Figure 2) into LaneHawk, then finish by plugging the IEC Power Cable (#8 Figure 1) into the adapter (#7 in...
- Page 5 Amber Ethernet Link status light (#3) should flash. After a few seconds, the first Green LaneHawk Server Status Light (#4), next to the Amber Ethernet Link Light, should flash, then remain on steadily.
-
Page 6: Communication With The Pos
Communication with the POS When boot-up has completed, the POS monitor should display an indication that LaneHawk is connected. The examples in Figure Figure Figure 6 Figure 7 show evidence that the LaneHawk function is active. Your POS screen may not resemble the samples below, since POS equipment and software will vary from site to site. - Page 7 Communication with the POS Figure 5. Example 2 Monitor Screen S o d a 1 CONN = Connected 2 *LH* = LaneHawk has detected a BoB (Bottom of Basket) item Figure 6. Example 3 Monitor Screen 1 Bottom of Basket = LaneHawk...
- Page 8 Figure 7. Example 4 Monitor Screen 1 LaneHawk is not connected 3 LaneHawk has recognized a BoB (Bottom of Basket) item 2 LaneHawk is connected LaneHawk...
-
Page 9: Maintenance
Maintenance Maintenance The LaneHawk unit requires only routine cleaning of its window using a soft, lint-free cloth dampened with an ammonia-based window cleaner. The window should also be periodically inspected for cracks, scratches or other damage which could inhibit performance. -
Page 10: Status Lights
= Data is transferring on the network. (ie, Link Status the network connection is active) Light 3 Green Connection to the LaneHawk server: Flashing LaneHawk = has connected to the network (has an IP Server address and can communicate on the network) -
Page 11: Troubleshooting
No network After checking that ethernet communication connections are secure, cycle power to the LaneHawk unit. Verify that the network switch is powered on. Confirm that the port on the network switch is working. Green... - Page 12 Warranty Datalogic warrants to Customer that this product will be free from defects in materials and workmanship for a period of 30 days from product shipment. Datalogic ADC Limited Factory Warranty Warranty Coverage Datalogic ADC (“Datalogic”) hardware products are warranted against defects in material and workmanship under normal and proper use.
- Page 13 Troubleshooting to Customer if the shipment is to a location within the country in which the Datalogic service center is located. Customer shall be responsible for paying all shipping charges, duties, taxes, and any other charges for products returned to any other locations.
- Page 14 POSSIBILITY OF SUCH DAMAGES. Risk of Loss Customer shall bear risk of loss or damage for product in transit to Datalogic. Datalogic shall assume risk of loss or damage for product in Datalogic’s possession. In the absence of specific written instructions for the return of product to Customer, Datalogic will select the carrier, but Datalogic shall not thereby assume any liability in connection with the return shipment.
- Page 16 © 2013 - 2015 Datalogic ADC, Inc. All rights reserved. Datalogic and the Datalogic logo are registered trademarks of Datalogic S.p.A. in many countries, including the U.S.A. and the E.U. Datalogic ADC, Inc. 959 Terry Street Eugene |OR 97402...
