SAFETY PRECAUTIONS NOT_COMBI_SW-00 TO PREVENT ANY RISK OF ELECTRIC SHOCK OR FIRE, READ THIS MANUAL CAREFULLY BEFORE INSTALLING THE EQUIPMENT. n the event of any problems or misunderstandings, please contact your dealer. This equipment is not designed for use by people (including children) with diminished physical, sensorial or mental capacities, or people without experience or knowledge of such equipment,...
SAFETY PRECAUTIONS NOT_COMBI_SW-00 This device must not be exposed to running water, water spray and dust of any kind. We recommend securing the device in a vertical position, with the cable outlet pointing downwards. You are formally prohibited from making mechanical alterations to the housing, including making additional holes, for example.
Page 4
SAFETY PRECAUTIONS NOT_COMBI_SW-00 terminal (PE “Protective Earth” terminal), must be connected to the system’s physical earth (yellow & green wire of the mains cable). Refer to the wiring diagram for more information. 4On the battery side, it is imperative to provide an external fuse on the positive polarity.
Page 5
SAFETY PRECAUTIONS NOT_COMBI_SW-00 Device serial number The serial number appears on the grey or white sticker on one side of the device. This number is aligned vertically and comprises a first number indicating the year of manufacture (e.g.: 17 for 2017), a letter indicating the month of manufacture (e.g.: C for the month of March), as well as a 4 or 5-figure number that is the product’s individual...
SAFETY PRECAUTIONS NOT_COMBI_SW-00 Maintenance precautions To prevent any risk of electric shock during maintenance operations, ensure that the following recommendations are scrupulously observed before performing any maintenance on the device: All maintenance operations must only be carried out by a suitably qualified technician. In the event of damage to AC wires and/or batteries cables, these may only be replaced by a qualified person, to avoid any danger.
(to be installed on the housing prior to connection). Installation introduction The combi SW is attached using 4 or 6 x 4mm Ø screws (not supplied), depending the model to a “robust” mounting or wall. Ideally, the product should be in a vertical position, with the cable outlet pointing downwards.
Page 8
CONNECTIONS NOT_COMBI_SW-00 Ventilation direction CONNECTIONS To gain access to the charger’s connections, the front hatch must be removed. To do this, simply unscrew the screw on the front hatch. The hatch is removed by rotating it. Prior to commencing connection, the mains cable gland must be positioned and attached to the housing in the hole designed for this purpose (hole on the left, when viewed from the front of the product).
Page 9
CONNECTIONS NOT_COMBI_SW-00 Combi SW 12V 1600VA Version +BAT -BAT Dipswitch Relay Remote Trigger Ext t° bat Ext com...
Page 10
CONNECTIONS NOT_COMBI_SW-00 Combi SW 24V 3800VA version Relay 2 Relay 1 Dipswitch Remote Trigger Ext t° bat Ext com +BAT AUX Reset...
Page 11
For mains power, preferably use a HO7RNF-type industrial cable. The AC mains power line must feature a cut-off device with differential protection, to specifically protect individuals against electric shocks. Combi SW Cable Cut-off model section device 12V 1600VA 2.5mm...
Page 12
SETTINGS NOT_COMBI_SW-00 DP SWITCH Local / external programming ON (external) = Not valid OFF (local) = Factory setup Fréquency inverter ON = 60Hz OFF = 50Hz (factory setup) Low battery protection ON = Protection enabled (factory setup) OFF = Protection disabled ASB mode ON = ASB enabled OFF = ASB disabled (factory setup)
Page 13
Reserved 24V 3800VA only ON = Remote desabled (factory setup) OFF = Remote enabled (front switch on ON position) On/Off & combi SW 12V 1600VA alarms TRIG Not valid Allows the Remote ON/OFF of the combi depen- REMOTE ding of the position of the DIP 8...
Page 14
DISPLAY NOT_COMBI_SW-00 LEDS Mode Inverter mode Output AC power Charger mode 100% Charge current No charge Green Charge in progress Charger disabled Battery default, high or low 1 alt red temperature default, ripple following Charger ON battery default 3 alt red Internal temperature default following 4 alt red...
Page 15
DISPLAY NOT_COMBI_SW-00 LEDS Mode No AC voltage & by-pass open AC voltage near the limits & Green alt synchronization of the combi AC voltage OK & by-pass AC in Green closed Red alt AC voltage out off limits By-pass desabled Charge in progress and level, 0%, 50%, 80% Battery logos and 100%...
WARRANTY NOT_COMBI_SW-00 Warranty TO PREVENT ANY RISK OF INCORRECT USE OF THE DEVICE, CAREFULLY READ THE LIST OF POTENTIAL EVENTS OR FAULTS NOT COVERED BY THE PRODUCT WARRANTY 4This device is not protected against battery polarity reversals. Risk of irreversible damage to the equipment. 4Should the device be dropped or fall this could cause irreversible distortion of the housing as well as a “crash”...
Page 21
WARRANTY NOT_COMBI_SW-00 Precautions for scrapping This device contains electronic components and materials that must be recycled at the end of the product’s usable life, for environmental reasons. At the end of their usable lives all devices must therefore be returned either to the local distributor or entrusted to a specialist electronic equipment recycling company.
