Instruction for Use
021754/05/14
Wind Direction Transmitter „First Class"
- Device with digital output, RS 485
- Wind velocity signal acquisition
4.3151.x0.400
ADOLF THIES GmbH & Co. KG
Hauptstraße 76
37083 Göttingen Germany
Box 3536 + 3541
37025 Göttingen
Phone +49 551 79001-0
Fax +49 551 79001-65
www.thiesclima.com
info@thiesclima.com
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Thies CLIMA 4.3151.x0.400 Series
Summary of Contents for Thies CLIMA 4.3151.x0.400 Series
- Page 1 Instruction for Use 021754/05/14 Wind Direction Transmitter „First Class“ - Device with digital output, RS 485 - Wind velocity signal acquisition 4.3151.x0.400 ADOLF THIES GmbH & Co. KG Hauptstraße 76 37083 Göttingen Germany Box 3536 + 3541 37025 Göttingen Phone +49 551 79001-0 Fax +49 551 79001-65 www.thiesclima.com info@thiesclima.com...
-
Page 2: Table Of Contents
Contents Models available ........................4 Application ..........................4 Mode of Operation ........................5 Recommendation Site Selection / Standard Installation ............5 Installation ..........................6 Wind Vane Mounting ......................6 Mechanical Mounting ......................7 5.2.1 North Alignment ......................8 Electrical Mounting ......................9 5.3.1 Cable ........................... - Page 3 Safety Instructions • Before operating with or at the device / product, read through the operating instructions. This manual contains instructions which should be followed on mounting, start-up, and operation. A non-observance might cause: - failure of important functions - Endangering of persons by electrical or mechanic effect - Damages at objects •...
-
Page 4: Models Available
1 Models available Order - No. Wind direction Wind velocity Electrical Supply Heating Meas. range Input [Hz] Output 4.3151.00.400 0...360° 1082 Hz @ 50m/s RS 485 3,3V…42V DC with (24 V AC / DC) 4.3151.10.400 0...360° 1082 Hz @ 50m/s RS 485 3,3V…42V DC without... -
Page 5: Mode Of Operation
3 Mode of Operation Wind direction The dynamic characteristics of the wind vane is achieved by the aluminum lightweight construction. The co-action of wind vane and balance weight results in a high damping ratio with small delay distance as excellent characteristic of the complete vane. The axis of the wind vane is running in ball bearings and carries a diametrically magnetized magnet at the inner end. -
Page 6: Installation
5 Installation Attention: Storing, mounting and operation under weather conditions is permis- sible only in vertical position, as otherwise water can get into the in- strument. Remark: When using fastening adapters (angle, traverses, etc.) please take a possible ef- fect on the measurements by turbulences into consideration. Caution: The device may only be supplied with a power supply of the "Class 2, limited power”. -
Page 7: Mechanical Mounting
5.2 Mechanical Mounting The wind direction transmitter must be mounted on an instrument carrier, which is suited for the measurement. For dimensions of wind direction transmitter please refer to chapter 10. Tools: Hexagon socket wrench SW3 (Allen key) Procedure: 1. Push cable/ plug connector of the wind direction transmitter through the borehole of the mast, tube, arm etc. -
Page 8: North Alignment
5.2.1 North Alignment For the precise determination of the wind direction the wind direction transmitter must be aligned northwards (geographical north). Tools: Hexagon socket wrench SW3 (Allen key) Procedure: 1. Rotate north marking (I) at the housing and wind vane axially one above the other, acc. -
Page 9: Electrical Mounting
5.3 Electrical Mounting 5.3.1 Cable Solder a shielded cable with diameter 7-8 mm and a core cross-section of 0,5...0,75 mm² to the enclosed coupling socket. • The number of necessary wires is given in the connection diagram (chapter 7). 5.3.1.1 Cable Recommendation No. -
Page 10: Plug And Cable Mounting
5.3.3 Plug and Cable Mounting Coupling socket, Type: Binder, Serial 423, EMC with cable clamp Cable connection: with cable shield 1. Stringing parts on cable acc. to plan given Cable mounting 1 above. View X 2. Stripping cable sheath 20 mm Cutting uncovered shield 15 mm Stripping wire 5mm. -
Page 11: Connecting Diagram
6 Connecting Diagram Connection diagram acc. to chapter 5.3.2.1 no. 1, 3 and 4: Order-No. View on the soldered joint of 4.3151.00.400 the counter plug Heizung 4.3151.10.400* Heating 25 W C P U 8 pol. Binder Steckverb. / Plug 5 6 7 Schirm Shield •... -
Page 12: Example Connection Diagram
6.1 Example Connection Diagram Wind - Geber / - Transmitter Windrichtungsgeber / - Direction Transmitter 4. 3351 . x0 . 000 4. 3150. x0. 400 8 pol. Binder Steckverb. / Plug 8 pol. Binder Steckverb. / Plug Power Power Power Power 3,3...42VDC RS485... -
Page 13: Placing Into Operation
8 Placing into operation The wind direction transmitter is to be connected to a voltage source and a RS485 interface, as given in the connection diagram. With the connection of the supply voltage, and after a delay of 5 sec, the output of serial data starts automatically with the following setting: Setting of interface: Baud rate 9600 baud... -
Page 14: List Of Commands
Example: modification of baud rate 00KY00001<CR> Key-secured command released 00BR00006<CR> baud rate set to 19200 Attention: The key-secured commands are released until the supply volt- age is activated, or the command 00KY00000<CR> is transmit- ted. 10 List of Commands For the wind direction transmitter the following commands are available Command Description Command KY... -
Page 15: Command Tr
Command TR <id>TR<param> Telegram on request <id>TR Query is not relevant (!xxTR00000) Command echo no Echo Description: The TR command with parameter 0003 starts a measurement and the transmission of the current measuring values,. Response telegram (<STX>xx.x xxx.x*HL<CR><ETX>) Parameter description: Parameter Description 00003... -
Page 16: Command Or
Command OR <id>OR<param> Set output interval for ATG. <id>OR Query of the current OR-parameter Command echo !xxORxxxxx Description: By the command OR and the parameter xxxxx the output interval is set for the telegram output. The parameter is specified in ms. The interval range is 100ms ... -
Page 17: Data Telegram
12 Data Telegram Telegram construction <STX>xx.x xxx.x*HL<CR><ETX> z.B. <STX>12.3 345.6*14<CR><ETX> Characters Description STX (HEX 02) wind velocity wind velocity (HEX 2E) decimal point wind velocity space (HEX 20) wind direction wind direction wind direction (HEX 2E) decimal point wind direction (HEX 2E) '*' H = high nibble check sum L = low nibble check sum... -
Page 18: Technical Data
14 Technical Data Characteristic Description Measuring range 0 ... 360 ° Measuring Accuracy 1° Resolution of measuring value 0.1° Output telegram <STX>xx.x xxx.x*HL<CR><ETX> z.B. 15.3(m/s) 347.1(°) Measuring time approx. 10ms / WD-measurement Survival speed 85 m/s up to 0.5 h Electric input of wind velocity 0..1082Hz @ 0...50m/s = 0...15V, U... -
Page 19: Dimensional Drawing
Electrical supply for heating Voltage: 24 V AC/DC, 54…65Hz (galvanically isolated from housing) Power: 25 W Connection 8-pole plug connection for shielded cable in the shaft (see connecting diagram) Mounting Mounting on mast 1“(DIN EN 10255; 1“= Ø 33.4 mm), Remark: mounting on mast 1½... -
Page 20: Accessories
16 Accessories Traverse 0,6 m 4.3174.00.000 Horizontal sensor distance: 0,6 m Vertical sensor distance: 0,2 m For mounting the wind speed Mast receptacle: 48 - 50 mm and wind direction transmitter Material: Aluminum, anodized jointly onto a mast Dimensions: tube Ø 34x4mm, 668 mm long, 756 mm high Hanger 4.3184.01.000... -
Page 21: Ec-Declaration Of Conformity
17 EC-Declaration of Conformity Document-No.: 001585 Month: 05 Year: 14 A D O L F T H I E S G m b H & C o. K G Manufacturer: Hauptstr. 76 D-37083 Göttingen Tel.: (0551) 79001-0 Fax: (0551) 79001-65 email: Info@ThiesClima.com Description of Product: Wind Direction Transmitter FIRST CLASS Article No. - Page 22 ADOLF THIES GmbH & Co. KG Hauptstraße 76 37083 Göttingen Germany P.O. Box 3536 + 3541 37025 Göttingen Phone +49 551 79001-0 Fax +49 551 79001-65 www.thiesclima.com info@thiesclima.com 22 - 22 021754/05/14...
