G8 Portable Fuel Transfer Pump
Owner's Manual
GENERAL INFORMATION
This pump is designed
for use only with gasoline
(up to 15% alcohol blends
such as E15), diesel fuel
(up to 20% biodiesel
blends such as B20) and
kerosene. Do not use
this pump for dispensing
any fluids other than
those for which it was
designed. To do so may damage
pump components and will void the
warranty.
This pump is designed to operate
on a typical 12-volt DC automotive
electrical system. The pump is
designed to operate with 12-volts DC
at the motor leads and the ratings
are determined at this voltage.
Performance may vary due to length
of power cord, battery condition or
output from vehicle charging system
that will affect system voltage.
NOTE: This pump is not intended for
use with an automatic nozzle.
WARNING: This product shall not be
used for pumping fuel or other liquids
into aircraft.
NOTE: An automatic bypass valve
prevents pressure build up when the
pump is on with the nozzle closed. To
avoid motor damage, do not run the
pump more than 5 minutes with the
nozzle closed.
04/2017
www.
The rated duty cycle of this pump
is 15 minutes ON and 30 minutes
OFF. Allow the pump to cool for 30
minutes.
Do not leave the system running
without fluids. "Dry running" can
damage the pump. If the system fails
to deliver fuel after 15 to 20 seconds,
turn the system off and refer to the
Troubleshooting Section.
Do not pump the tank completely
dry, as contaminants from the bottom
of the tank may enter the pump.
information@itm.com
.com
922130-01 Rev-

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the G8 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for GPI G8

  • Page 1 G8 Portable Fuel Transfer Pump Owner’s Manual GENERAL INFORMATION This pump is designed for use only with gasoline (up to 15% alcohol blends such as E15), diesel fuel (up to 20% biodiesel blends such as B20) and kerosene. Do not use...
  • Page 2: Safety Information

    SAFETY INFORMATION If using solvent to clean pump components or tank, observe Observe all safety precautions the solvent manufacturer’s concerning safe handling of recommendations for safe use and petroleum fuels. disposal. For your safety, please take a INSTALLATION & OPERATION moment to review the warnings throughout this manual.
  • Page 3: Ground Wire

    115-volt electrical system. Install Ground Wire WARNING: Carefully route the power An external ground wire is provided for use where required. GPI strongly cord to the battery, protecting the power cord from hot surfaces, sharp recommends grounding your pump edges or anything that could damage prior to use.
  • Page 4: Fuse & Holder

    To avoid this pump. To order replacement pump damage, do not run the pump kit, contact GPI and ask for part more than 5 minutes with the nozzle number #147500-01 Gears and Seals closed.
  • Page 5 Inspect and Service Bypass Inspect and Service Gears Poppet To clean and service gears (See Figure 5): To clean and service the Bypass Poppet (see Figure 4): • Remove the (4) 1/4-20 socket head screws, (2) hex nuts, handle • Remove the bypass plug with and gear coverplate.
  • Page 6: Troubleshooting

    TROUBLESHOOTING MOTOR DOES NOT RUN PROBABLE CAUSE SOLUTION Inpect for defective wiring or Electrical connection is faulty improper electrical connections. Repair as needed Inspect fuse in fuse holder. If blown, Fuse is blown replace Motor is burned out Inspect and replace as necessary MOTOR RUNS BUT DOES NOT PUMP FLUID PROBABLE CAUSE SOLUTION...
  • Page 7 UL APPLICATIONS program for Rebuilt Motors for Use in Hazardous Locations. The G8 Fuel Transfer Pump is designed to safely transfer low For warranty consideration, parts, viscosity petroleum fuels such as or other service information, please...
  • Page 8: Limited Warranty

    LIMITED WARRANTY Great Plains Industries, Inc. 5252 E. 36th Street North, Wichita, KS USA 67220-3205, hereby provides a limited warranty against defects in material and workmanship on all products manufactured by Great Plains Industries, Inc. This product includes a 2 year warranty from date of purchase as evidenced by the original sales receipt.
