2.3 Foundation Fieldbus

Foundation Fieldbus
1 2
FB-P FB-N FB-P
2.3.1 Terminals
Foundation 1 (FB-P)
Fieldbus 2 (FB-N)
3 (FB-P)
4 (FB-N)
2.3.2 Electrical specifications
FF-Fieldbus
Interface
Termination
Val Controls A/S • Limfjordsvej 3 • DK-6715 Esbjerg N • Tel. +45 7547 0600
DHW-UM-002
Revision: 3
3 4
FB-N
FF-Fieldbus - H1 Device Class – Basic Device
No internal termination
