4.2 Digital input – DI12
DI12 substitutes AI0
DI12
5
+
Switch
The external resistor and connection between terminal 2 and 6 must be mounted to get the correct
functionality.
4.2.1 Terminals
DI12 1 (+)
5 (-)
4.2.2 Electrical specifications
DI12
Type
Cable length
Val Controls A/S • Limfjordsvej 3 • DK-6715 Esbjerg N • Tel. +45 7547 0600
DHW-UM-002
Revision: 3
1 2 6
-
vc@valcontrols.com • www.valcontrols.com
Switch
1000 meters
13/20
