5.4.2 Electrical specifications
Power supply
Power dissipation, no position sensor/loop or
output lamps are connected.
Power dissipation, with maximum load on all
inputs and outputs
Max load per DO11 and DO12
If PS2 is not used, total load that can be drawn
from all DO/DI/AI ports (except DO11/12)
Val Controls A/S • Limfjordsvej 3 • DK-6715 Esbjerg N • Tel. +45 7547 0600
DHW-UM-002
Revision: 3 vc@valcontrols.com • www.valcontrols.com
20.4 – 27.6VDC
< 2W
< 5W, the load not included
up to 48W @24VDC
2W
