- Page 1 UNI-335 LCD Display 2-Way Alarm & Starter INSTALLATION MANUAL UNI4:Main Control UNI3:Antenna Receiver...
- Page 2 UNI-335 manual INSTALLATION DIAGRAM Color Function Brown/Black Ground Output While Running(Engine Run output) Gray/Black Second Starter Output Pink 2-Step Unlock/Factory Disarm/Sensor By-pass White/Blue Instant Start And Turn Off /Input White Dome Light Control Output Brown/White Horn Output (Programmable) Black/Green Channel 4 Programmable Output...
- Page 3 6PIN HEAVY GAUGE WIRE HARNESS 5 PIN WIRE HARNESS 3 PIN,DOOR LOCK CONNECTOR...
- Page 4 WIRING Keep wiring away from moving engine parts, exhaust pipes and high-tension cable. Be sure to tape wires that pass through holes on the firewall to prevent fraying. CAUTION: Do not connect the wire harness to the control module until all wiring to vehicle is complete H1:6 PIN HEAVY GAUGE WIRING CONNECTIONS: Remember that what the system does to start a vehicle is to duplicate the functions we will explain the...
- Page 5 Yellow Wire 一 Ignition 1 Output Connect the YELLOW wire to the ignition 1 wire from the ignition switch. The ignition wire should receive “12 volts” when the ignition key is in the "ON" or "RUN" and "START" or "CRANK" position. When the ignition is turned "OFF", the ignition wire should receive "0"...
- Page 6 Do not connect this wire to any existing ground wires supplied by the factory wire loom, make the connection to the vehicle's frame directly. BROWN WIRE—(+)2A SIREN OUTPUT This wire is provides power to the supplied siren. Connect the Brown wire to the Red wire of the siren.
- Page 7 into place. Route the LED wires to the control module. H9. 4 PIN ORANGE CONNECTOR 2 STAGE SHOCK SENSOR, ZONE-4, (Under door on main unit) H-6: 20 PIN WIRE CONNECTORS: Color Function Brown/Black Ground Output While Running Second Starter Output Gray/Black Pink 2-Step Unlock/Factory Disarm/Sensor...
- Page 8 H6/3 PINK WIRE—(-)200mA Programmable Output 2 Steps Unlock Output (Factory default setting) (See Alarm Feature C—1 Programming) The 2 steps unlock feature will work for the most fully electronic door lock circuit. The vehicle must have an electronic door lock switch (not the lock knob or key switch), which locks and unlocks all of vehicle's doors.
- Page 9 H6/6 BROWN / WHI7E WIRE—(-)200mA Programmable Output Horn Output— (Factory default setting) This wire is provided to use the existing vehicle’s horn as the alarm system’s optional's warning audible device It's a transistorized low current output, and should only be connected to the low current ground output from the vehicle's horn switch.When the system is triggered, the horn will sound.
- Page 10 H6/9 ORANGENVHITE WIRE—200mA Grounded Output when Disarmed—N.O. Disable This wire will become grounded when the alarm is disarmed. The current capacity of this wire is 200mA. It can be connected to optional Ignition disable relay / ECU disable relay / Fuel Pump disable relay. H6/10 WHITE/RED WIRE—Tachometer Signal Connection—...
- Page 11 H6/12 WHITE/GREEN WIRE—(-)Diesel Wait To Start Input (See Start Feature D-1 Programming) In diesel vehicles it is necessary to interface with the wire that on the WAIT-TO-START light in the dashboard. This wire illuminates the bulb until the vehicle's glow plugs are properly heated.
- Page 12 Transponder interfacing using relay: If the vehicle has a transponder system installed, you will need to by-pass the system while the vehicle is operating under the control of the Remote Start Unit. To do this: 1.You will need a transponder key that's already programmed to the vehicle. 2.Remove the trim around the ignition switch.
- Page 13 connection for "grounding" type factory door pins locate the "common wire' that connects the door pin switches. Make the connection of the GREEN Wire here. H6/15 GRAY WIRE—(-)200mA Channel 3 Output— This will become a 1 second pulse ground by activate (button 3) on transmitter for two seconds, the current capacity of this wire is 200 mA.
- Page 14 light circuit switches ground to the brake lights. An isolation diode must be used for ground switched brake light circuits and must be connected to the output of the brake switch. H6/20 ORANGE WIRE—(-)200mA Grounded Output When Armed- This wire will become grounded when the alarm is armed. The current capacity of this wire is 200mA.
- Page 15 PROGRANMMING Code learning: Note: This mode will only retain the 4 remote transmitters programmed. If the transmitter memory is exceeded, the security system will start deleting transmitters from memory in chronological order. 1. Turn the Ignition 'switch 'OFF/ON' 3 TIMES and stay in ON position "Within 15 seconds".
- Page 16 Panic with Panic with Panic with Ignition Without Panic 5、 Ignition on & off on & off Panic function. Ignition off with No time limit. Without Car—jack made Active Car-jack mode Passive Car-jack 6、 mode With Dome light turns on With Dome light turns on Without this 7、...
- Page 17 “off” upon an unlock signal& 10-second upon a lock signal signal. Ignition controlled Ignition controlled Ignition controlled door Without ignition door lock & unlock door locks only unlocks only controlled door locks & unlocks 0.8 second door 3.5 second door 0.8 second Lock 0.35 second 0.8 second lock &...
- Page 18 Comfort Feature: Some Vehicles have a special "COMFORT feature". When you lock the door with the key, you can keep turning the key in the door for about 5 to 7 seconds and the window will close directly. If your vehicle has the "COMFORT feature' and you wish for the door to be locked and the window to be closed automatically at the same time by remote control, you can set the alarm feature "B-3”...
- Page 19 H6/7 Black / H6/7 Black / Green Wire H6/7 Black /Green H6/7 Black / Green Wire Channel 4 Wire Channel 4 Green Wire Channel 4 Output Output = Timer Output = Channel 4 Output = Latched output programming (set Momentary output = Latched output and reset with to any interval...
- Page 20 programming mode. You can program or delete the password pin code as below: Program: 1. Press and release the transmitter button twice, [2] LED flash, [2] siren/horn chirp to indicate that you are in features "Password Pin Code Programming mode". 2.
- Page 21 programming mode. 3. Press and release the transmitter button corresponding to the feature you want to program. One Chirp / LED Press Transmitter Two Chirps / LED Three Chirps / Four Chirps / LED one pulse Factory Button two pulse LED three pulse four pulse Default Setting...
- Page 22 2. The user presses the transmitter buttons at the "same time" to start the vehicle. START FEATURE: "E" PROGRAMMING: 1. Turn the lgnition 'switch 'ON/OFF' 3 TIMES and stay in OFF position. 2. Push the Valet switch 11times (holding in on the 11 push) until five chirps &five parking flashes then release the valet switch.
- Page 23 signal). <4>Start engine with key, LED will fast flash when the lines are properly connected <5>Shut down the engine when the engine speed to stabilize. <6>when use UNI2 or remote control module will auto exit the learning mode. <7> To re-learn the engine speed (RPM), it can learn again after Disarm the host power and then send power.
- Page 24 vibration sensor does not detect automatically. Note: Attention! start the engine by remote, the system must be arm status base on security. TEST MODE In this test made, this system can test the Zone 2 (Instant ground trigger), the Zone 3 (Door trigger), and the Zone1&Zone 4 (2 stage shock sensor) sensitivity.
- Page 25 1. Turn the ignition ON then OFF 3 TIMES and stay in OFF position. 2. Push the Valet switch 12 times (holding in on the 12 push) until ten chirps then release the valet switch. You are now in the "Return To Factory Default Setting" programming mode.
- Page 26 4. Step on the brake pedal and shift the gear selector into "DRIVE (D). 5. Put your foot over the brake pedal but do not press down on it. Be ready to step on the brake to shut down the Remote Start Device. 6.
- Page 27 Remote Start Unit KEY IN SENSOR CIRCUITS If the vehicle you are working on does not have or you cannot locate the ECM reference wire, there are two alternatives available Although not preferred, the vehicle Key In Sensor may be reconfigured to allow a margin of safety and will prevent the vehicle with a Mechanical Neutral Start Switch from starting in gear.
- Page 28 B. Cut this wire and connect the ignition cylinder side to chassis ground C. Locate the key in sensor switch wire that connects the chime module to the ignition cylinder D. Cut this wire and connect the ignition cylinder side to terminal 30 of a P&B VF45F11 or equivalent relay E.
- Page 29 This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.
