Z
Z5409/11
Mounting instructions 1.1 en

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Z5409 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for d&b audiotechnik Z5409

Summary of Contents for d&b audiotechnik Z5409

  • Page 1 Z5409/11 Mounting instructions 1.1 en...
  • Page 2 General information Z5409/11 Mounting instructions Version: 1.1 en, / , D2960.EN .01 Copyright © by d&b audiotechnik GmbH; all rights reserved. Keep these mountings instructions with the product or in a safe place so that they are available for future reference.

  • Page 3: Table Of Contents

    1.1. Scope of supply................. 4 1.2. Safety precautions..............4 1.3. Intended use................5 1.4. Mounting options and angle settings........5 1.5. Assembly..................6 Fixing templates..............8 Built-in dimensions............10 Declarations............... 12 4.1. Manufacturer's declaration............. 12 4.2. Disposal................... 12 d&b Z5409/11 Mounting instructions 1.1 en...

  • Page 4: Z5409/11 Horizontal Bracket 10S/12S

    Load safety information The maximum permitted working load of the Z5409 Horizontal bracket 10S is 13 kg (29 lb) (according to BGV C1) which corresponds to the weight of one 10S or 10S-D loudspeaker, respectively.

  • Page 5: Intended Use

    1.3. Intended use The d&b Z5409/Z5411 Horizontal bracket 10S/12S must only be used in conjunction with the d&b xS-Series loudspeakers 10S/ 10S-D (Z5409) and 12S/12S-D (Z5411) as described in these mounting instructions. The bracket can be: ▪ directly mounted to walls.

  • Page 6: Assembly

    To remove the caps, proceed as follows: 1. Cut out the caps along the recessed spline using an appropriate cutting knife. 2. Carefully take off the caps and ensure the cabinet coating is not peeled off. d&b Z5409/11 Mounting instructions 1.1 en...
  • Page 7 2. Insert the screws together with the spring and U washers. 3. Align the cabinet and tighten the screws. 4. If you want to fix the set angle, use the supplied spax screw [5]. d&b Z5409/11 Mounting instructions 1.1 en...

  • Page 8: Fixing Templates

    2. Fixing templates Fig. 4: Z5409 Horizontal bracket 10S, fixing template d&b Z5409/11 Mounting instructions 1.1 en...
  • Page 9 Fig. 5: Z5411 Horizontal bracket 12S, fixing template d&b Z5409/11 Mounting instructions 1.1 en...

  • Page 10: Built-In Dimensions

    3. Built-in dimensions Fig. 6: Z5409 Horizontal bracket 10S, dimensions in mm [inch] Fig. 7: Z5411 Horizontal bracket 12S, dimensions in mm [inch] d&b Z5409/11 Mounting instructions 1.1 en...
  • Page 11 Fig. 8: Z5409 Horizontal bracket 10S, mounting options 1,2 and 3 and built-in dimensions in mm [inch] Fig. 9: Z5411 Horizontal bracket 12S, mounting options 1,2 and 3 an built-in dimensions in mm [inch] Fig. 10: Built-in dimensions Z5010/Z5012 Assembly...

  • Page 12: Declarations

    4. Declarations 4.1. Manufacturer's declaration This declaration covers: ▪ d&b Z5409 Horizontal bracket 10S ▪ d&b Z5411 Horizontal bracket 12S. National standards and technical specifications applied: DIN 18 800, DIN 1055, DGUV Vorschrift 17, BGI 810-3. Backnang, 2011-03-25 Frank Bothe, Head of R&D...
  • Page 14 www.dbaudio.com...
