17 . 1.1.3 Load safety information NOTICE! The Z5455 AL Flying frame is designed to suspend a total of 4 x AL60/AL90 or ALi60/ALi90 cabinets which corresponds to a total system weight of 100 kg (220 lb) – SWL.
A-Series rigging components A-Series rigging components In addition the Z5455 AL Flying frame is equipped with the following items: Pos. Description Two safety points in the tie bar for the attachment of the Z5454 AL Safety chain (also refer to Þ Chapter 2.3 "Secondary safety"...
The Z5454 AL Safety chain is supplied with the Flying frame. Specification Lifting chain (DIN EN 818) 2-leg, 6 mm Grade Nominal length per leg incl. hooks 534 mm (21") Load rating 1.4 t (WLL) d&b Z5455 AL Flying frame Rigging manual 1.1 en...
4. Release the button to lock the pin ( [l]). 5. Recheck the Locking pin is securely locked by briefly pulling the Locking pin towards you. d&b Z5455 AL Flying frame Rigging manual 1.1 en...
3. Refit and lock Refit the ring cotter by pushing the straight wire shaft through the hole and pressing the front wire loop underneath the straight wire shaft. d&b Z5455 AL Flying frame Rigging manual 1.1 en...
2. To park the Splay link, proceed in reverse order and ensure the extension tube is fully pushed in and the head is aligned correspondingly, as shown in the graphic opposite. d&b Z5455 AL Flying frame Rigging manual 1.1 en...
1. Fold out the Splay link as previously described. 2. Pull out the extension tube to its stop position. 3. Turn the extension tube head counter clockwise by 90° to fix the extended length of the Splay link. d&b Z5455 AL Flying frame Rigging manual 1.1 en...
2. At the rear, release the Locking pin of the Splay link. 3. Fold out the Splay link. 4. Pull out the link to the "Extended" length and turn the extension tube head counter clockwise by 90°. d&b Z5455 AL Flying frame Rigging manual 1.1 en...
Page 14
2. At the rear, release the Locking pin of the Splay link. 3. Fold out the Splay link. 4. Set the link to the required length (Standard or Extended) and turn the extension tube head counter clockwise by 90°. d&b Z5455 AL Flying frame Rigging manual 1.1 en...
Page 15
4. Slightly lower the cabinet until the Front links are engaged. 5. On the rear rigging strand, release the corresponding Locking pins on the top and bottom cabinets. d&b Z5455 AL Flying frame Rigging manual 1.1 en...
Þ Chapter 2.3 "Secondary safety" on page 7). 3.4 Derigging To dismantle any of the assemblies, follow the corresponding rigging and setup instructions in reverse order. The same safety instructions apply! d&b Z5455 AL Flying frame Rigging manual 1.1 en...
® ▪ Regularly lubricate the Locking pins using WD-40 or a similar product. Z5455 AL Flying frame Visual inspection regarding deformation and damage (e.g. cracks and corrosion) including all drilled holes of the component. d&b Z5455 AL Flying frame Rigging manual 1.1 en...
