Annex II

Switch Configuration According to the Rotation Angle of the Control Axle
≤ 24° and
≤30° and
< 30°
< 36°
• 87/88
strokes
½" to
0,8"
• 37/38
strokes
½" to ¾"
• Sigma F
stroke ¾"
26 | BHGE
≤36° and
≤42° and
< 42°
<48°
Concerned Apparatus
• Varimax
• 67/68
stroke 5"
≤48° and
≤54° and
< 54°
< 62°
• Camflex
• Varipak
• 3100
• 87/88
strokes
1" to 2,5"
• 37/38
strokes
1" to 4"
• Sigma F
strokes
1,5" to 2"
• 67/68
stroke 6"
© 2018 Baker Hughes, a GE company. All rights reserved.
≤62° and
≤70° and
<70°
< 80°
• 67/68
• Minitork • Ball
stroke 8:
≤80° and
≤90°
