6.
Position Transmitter 496-8../. Electrical data
• Power supply:
Voltage Supply U (V)
Flameproof
Intrinsic Safety
• Lightning protection (in standard) : 1500W 10/1000µs
• Output current 4-20mA (two wires)
• Zero range adjustment : ±0.5mA
• Span range adjustment : ±2.5mA
• Protected against polarity inversion
(Ω)
• Maximum load Zc
This means for 20mA:
Zc = 950 Ohm max with for an intrinsically safe loop
and
Zc = 1350 Ohm for Flameproof.
© 2018 Baker Hughes, a GE company. All rights reserved.
Mini
Maxi
9.0V
36V
9.0V
28V
(
)
Supply Voltage
V
– 9.0
=
(
)
Imaxi
A
U
(
)
V
496 Series Masoneilan Position Transmitter ATEX Instruction Manual | 11
Zc
