- Page 1 Ultra-Rugged Tablet R08IH8M-RTU1GP R10IH8M-RTT2GP Intel ® Core™ i5-5250U Broadwell User Guide Version 1.1 Please read this instructions before operating the device and retain them for future reference.
-
Page 2: Table Of Contents
Ultra-Rugged Tablet User Guide Contents Chapter 1: Read Me First ............................3 1.1 Advisory Conventions ............................3 1.2 Safety Information .............................. 4 1.3 Handling and Maintenance ..........................6 1.4 Declaration of Conformity (DoC) ........................7 Chapter 2: Getting Started ............................8 2.1 Overview ................................ -
Page 3: Chapter 1: Read Me First
Chapter 1: Read Me First Chapter 1: Read Me First 1.1 Advisory Conventions Four types of advisories are used throughout the user manual to provide helpful information or to alert you to the potential for hardware damage or personal injury. These are Notes, Important, Cautions, and Warnings. -
Page 4: Safety Information
Ultra-Rugged Tablet User Guide 1.2 Safety Information Precaution on Battery Pack When the Battery Pack Has Deteriorated, Précaution avec le bloc-pile Replace It with a New Battery. Continued use of a damaged battery pack may result in heat generation, ignition or battery rupture. [FR] Lorsque la pile est détériorée, la Do Not Disassemble, Modify, or Insert Sharp remplacer par une nouvelle pile. - Page 5 Chapter 1: Read Me First General Product Safety Use only accessories specified by the Sécurité générale des manufacturer. [FR] Utiliser uniquement les accessoires produits spécifiés par le fabricant. Do not block any ventilation openings. Do not This product should not be used near water place the product against a wall or in an such as bathtubs, sinks, swimming pools, wet enclosed space as doing so might impede the...
-
Page 6: Handling And Maintenance
Ultra-Rugged Tablet User Guide 1.3 Handling and Maintenance Gently wipe the display with a soft, lint-free cloth. Do not use alcohol or detergent on the General Guideline product. [FR] Essuyer délicatement l'écran avec un Guide Général chiffon doux non pelucheux. Ne pas utiliser d'alcool ou un détergent sur le produit. -
Page 7: Declaration Of Conformity (Doc)
Chapter 1: Read Me First 1.4 Declaration of Conformity (DoC) FCC Statement This device complies with part 15 FCC rules. Operation is subject to the following two conditions: This device may not cause harmful interference. This device must accept any interference received including ... -
Page 8: Chapter 2: Getting Started
Ultra-Rugged Tablet User Guide Chapter 2: Getting Started 2.1 Overview This chapter tells you information about Winmate® Ultra-Rugged Tablet Computer, its highlighted features, and provides basic instructions for using the Ultra-Rugged Tablet Computer. Introduction Product Features Unpacking... -
Page 9: Unpacking
Chapter 2: Getting Started 2.4 Unpacking If any of the following items are missing or damaged, contact us. Standard packing list includes: Tablet Computer Standard Battery Power Adapter Power Cord and Plugs Driver CD User Manual ... -
Page 10: Description Of Parts
Ultra-Rugged Tablet User Guide 2.5 Description of Parts 8.4”, R08IH8M-RTU1GP Front: Right: Left: Item Description No Item Description Power Mode Resistive Display acts as one of Touch Screen the inputs for the Tablet Battery Status Computer Menu Menu function to show Storage Status brightness, volume, battery status and... - Page 11 Chapter 2: Getting Started Rear: Bottom: Top: Item Description Item Description Stylus Stylus pen to optimize Docking Port to docking the touch performance Connector solutions such as Adjustable This adjustable vehicle docking to Kickstand kickstand allows user provide power and to adjust their viewing external antenna.
- Page 12 Ultra-Rugged Tablet User Guide 10.4”, R10IH8M-RTT2GP Left: Front: Right: Item Description No Item Description Power Mode Resistive Display acts as one of Touch Screen the inputs for the Tablet Battery Status Computer Speaker 2 x 1 Watt Speaker Storage Status...
- Page 13 Chapter 2: Getting Started Rear: Bottom: Top: Item Description Item Description Stylus Stylus pen to optimize Docking Port to docking the touch performance Connector solutions such as Adjustable This adjustable vehicle docking to Kickstand kickstand allows user provide power and to adjust their viewing external antenna.
-
Page 14: Hotkey For Specific Functions
Ultra-Rugged Tablet User Guide 2.6 HotKey for Specific Functions For the physical buttons on the Ultra-Rugged Tablet Computer, in addition to their dedicated functions detailed in the previous section, they can also be used to emulate commonly used keyboard key strokes. Under different scenario, a single physical button or a combination of physical buttons provide different keyboard key strokes, which are specified below: POST (before windows boot up): Windows:... -
Page 15: First-Time Operation
Chapter 2: Getting Started 2.7 First-time Operation To start using the tablet computer for the first time: Install the battery pack. Install battery. Charge the tablet computer. Power on the tablet computer. Configure the settings of the tablet computer Inserting Battery Pack To insert the standard battery pack into the tablet computer: 1. -
Page 16: Connecting To Power Supply
Ultra-Rugged Tablet User Guide 2.8 Connecting to Power Supply The Tablet Computer operates either on external AC power or internal battery power. It is recommended to use AC power when you start up the Tablet Computer for the first time. Caution Use only the AC adapter included with your Tablet Computer. -
Page 17: Powering On And Off
Chapter 2: Getting Started 2.9 Powering On and Off Powering On Press and hold the power button for 3 seconds until the blue LED power indicator light up. Note: • Do not press the power button repeatedly. • Do not perform the following operations until the Disk Activity Indicator off •... -
Page 18: Chapter 3: First Time Operation
Ultra-Rugged Tablet User Guide Chapter 3: First Time Operation This section details how to setup different version of the Windows that may be installed on the tablet for the first time. Note: Please notice that BIOS varies by different Windows OS; for users going to change OS, please contact our sales contact window for details. -
Page 19: Choosing Your Computer's Network
Chapter 3: First Time Operation You have three choices: 1. Use recommended settings (automatically downloads and installs all updates provided by Microsoft) 2. Install important updates only (only downloads and installs critical updates) 3. Ask me later. Click the option you wish to use. Reviewing your time and date settings The next screen contains options for changing the date and time settings. -
Page 20: Completing Windows 7 Setup
Ultra-Rugged Tablet User Guide Public network: Select this location if you do not recognize all the computers on the network. (For example, you are in a coffee shop or airport, or you have mobile broadband.) This is a public network and is not trusted. 4. -
Page 21: Setting Up Windows 7 Ultimate/Professional
Chapter 3: First Time Operation 3.2 Setting Up Windows 7 Ultimate/Professional Follow the steps below to complete the setup process. 1. Press the power button to power on the computer. 2. First select your region and language information, and then tap Next 3. - Page 22 Ultra-Rugged Tablet User Guide 4. Type in a password for your account and tap Next 5. Now enter the product key that came with the computer and tap Next. For this version of the Windows, a product key entry is required when setting up the computer for the first time.
- Page 23 Chapter 3: First Time Operation 6. On the license terms screen, click on the I accept the license terms and tap Next 7. For the update option, choose Use recommended settings for Windows to install updates. If you do not wish Windows to do so, choose the other options accordingly.
- Page 24 Ultra-Rugged Tablet User Guide 8. Next, review the date and time settings on the computer 9. Select the computer current location for network privacy setting. Choose the location below to your actual usage accordingly. 10. Allow time for windows to setup your desktop for the first time. 11.
-
Page 25: Setting Up Windows Embedded 8.1 Industry Pro
Chapter 3: First Time Operation 3.3 Setting Up Windows Embedded 8.1 Industry Pro Follow the steps below to complete the setup process. 1. Press the power button to power on the computer. 2. Check I accept the license terms for using Windows to accept the terms, and then click or tap "I Accept."... - Page 26 Ultra-Rugged Tablet User Guide 3. On the Personalize screen, choose a color you like – you can always change this later from the Start screen. 4. In the PC name field, type a name for your computer, and then click or tap Next.
- Page 27 Chapter 3: First Time Operation 5. On the Settings page screen, choose Use express settings for the fastest setup. 6. Windows will then try to connect to network. Ignore attempt to connect to internet as you do not need internet connection to finish setup your pc.
- Page 28 Ultra-Rugged Tablet User Guide 7. On Your account screen, type your username and password to create a local account, and then click or tap Finish. 8. Windows may take some time to finalize your settings.
- Page 29 Chapter 3: First Time Operation 9. On the Windows Sign-in screen, enter the user name and password that you set up earlier, and then press Enter. 10. Once Windows finishes login, you are now ready to use the PC...
-
Page 30: Setting Up Windows 10 Iot Enterprise
Ultra-Rugged Tablet User Guide 3.4 Setting Up Windows 10 IoT Enterprise This section details how to setup different version of the Windows that may be installed on the tablet for the first time. 3.1 Setting up Windows 10 IoT Enterprise Follow the steps below to complete the setup process. - Page 31 Chapter 3: First Time Operation Windows will then try to connect to network. Tap Skip this step to continue without a wireless connection as you can then set up the network later. On the Get going fast screen, click Use Express settings for the fastest setup. If you would like more information, tap Learn more, or if you would like to select your own options, click Customize settings.
-
Page 32: Chapter 4: Quick Access With Hottab
Ultra-Rugged Tablet User Guide Chapter 4: Quick Access with Hottab 4.1 Hottab Introduction Hottab provides quick access to the Tablet’s functions and features, such as setting up shortcuts, using camera, powering on/off built-in devices, programming function key, and changing power management. As Windows starts up, Hottab opens and runs in the background. -
Page 33: Shortcuts
Chapter 4: Quick Access with Hottab 4.2 Shortcuts Set up On-screen Software Shortcuts Hottab Shortcuts Menu provides user-friendly interface to configure on-screen software short cuts and allow users to quickly access programs with a few tabs. The Shortcuts menu offers 8 empty slots to store user’s desired quick access. Shortcuts can be mapped to any of the executable files (.exe) installed on the tablet. -
Page 34: Description Of Camera User Interface Buttons
Ultra-Rugged Tablet User Guide 4.3.2 Description of Camera User Interface Buttons: Item Description 1 Camera Switch Switch between front camera or rear camera. 2 Settings Brings up Camera settings page. Available Settings: Picture Save: modify/inspect saved location for pictures. ... -
Page 35: Device On / Off
Chapter 4: Quick Access with Hottab 4.4 Device On / Off This section provides a quick access to set-up built-in devices, including turning on/off RF modules, setting up barcode reader, RFID reader, and expansion modules. 4.5 Using the Wireless LAN (Wi-Fi) To use the wireless LAN (Wi-Fi) feature to connect to the network, perform the following procedure: 1. -
Page 36: Using The Wireless Wan (3G/Lte)
Ultra-Rugged Tablet User Guide 4.6 Using the Wireless WAN (3G/LTE) 4.6.1 Insert SIM card (For 3G/LTE Equipped Devices) Notice that 3G/LTE feature is optional. The Tablet Computer supports data connection with 3G/LTE Modules and fits Micro-SIM card. Caution Power off the tablet before installing the 3G/LTE module and micro SIM card, or the Tablet Computer might be damaged by the incorrect installation behaviors Before using the data connection program, please perform the following procedures to insert the SIM Card into your Tablet... -
Page 37: Using The Gps
Chapter 4: Quick Access with Hottab 4. If the WWAN feature is disabled (white), tap on the WWAN icon to enable it (orange). 5. You can check the wireless WAN connection status through the wireless network connection status icon in the Windows notification area. The more bars encompassed, the better the signal is. -
Page 38: Settings
Ultra-Rugged Tablet User Guide 6. To add a device, tap on Add a Bluetooth Device. Windows will search any Bluetooth device automatically 7. Choose the Bluetooth device that user wants to connect and follow onscreen prompt to continue the pair procedure and use the Bluetooth device. 4.9 Settings This Hottab menu option provides users information such as PC Information, Battery status, and also device settings such as power management setting, and function key mappings. - Page 39 Chapter 4: Quick Access with Hottab To configure function key mapping, perform the following: 1. Launching the Hottab Utility application. 2. Tap on the Setting button. 3. Tap on function key icon for the corresponding key that you want to change. 4.
-
Page 40: Chapter 5: Frequently Used Settings
Note: Winmate recommends the users set the scaling to this setting for optimal text and image viewing. Before proceeding to change the scaling option, make sure any opened document is saved and close, and all running applications are closed before proceeding to change the display scaling, because this procedure requires users to log out of their account to apply display scaling change. -
Page 41: Using Recovery Wizard To Restore Computer
Chapter 5: Frequently Used Settings 2. The following panel will open. Here you can adjust the size of text, apps, and other items and also change the orientation. To change the resolution settings, scroll down this window and click on Advanced Display Settings 5.3 Using Recovery Wizard to Restore Computer The tablet computer has a dedicate recovery partition stored on the hard drive of the tablet to enable quick one-key recovery process. - Page 42 Ultra-Rugged Tablet User Guide 4. A warning message about data loss will show up. Make sure data is backed up before recovery, and click on “Yes” to continue. 5. Wait till the recovery process to complete. During the recovery process, a command prompt will show up to indicate the percent of recovery process.
-
Page 43: Chapter 6: Troubleshooting
Chapter 6: Troubleshooting Chapter 6: Troubleshooting 6.1 Basic Troubleshooting Problem Solution Make sure the AC adapter is properly The removable battery is not charging. connected, and that the removable battery is properly inserted. The tablet computer may be in sleep Nothing appears on the screen. - Page 44 Problem Solution Make sure that GPS is powered on in The GPS application cannot find my location. Hottab. Make sure that GPS receiver and the location sensor are enabled in Control Panel. The tablet computer may be out of coverage area.
-
Page 45: Appendix A: Technical Specifications
Appendix A: Technical Specifications Model Name R08IH8M-RTU1GP R10IH8M-RTT2GP Display Size 8.4" 10.4" Resolution 800 x 600 1024 x 768 Brightness 800 nits 700 nits Touch Resistive Resistive Mechanical Dimensions 266 x 220 x 50.5 mm 266 x 220 x 50.5 mm Weight 2.39 kg... -
Page 46: Appendix B: Dimensions And Schematics
Appendix B: Dimensions and Schematics 8.4”, R08IH8M-RTU1GP Default Configuration... - Page 47 10.4”, R10IH8M-RTT2GP Default Configuration...
- Page 48 Winmate Inc. 9F, No.111-6, Shing-De Rd., San-Chung District, New Taipei City 24158, Taiwan, R.O.C www.winmate.com Copyright © 2018 Winmate Inc. All rights reserved.
