8.4"/ 10.4"
Ultra-Rugged Tablet
R08IWK8M-RTU1GP
R10IWK8M-RTT2GP
8th Gen. Intel® Core™ i5-8265U, 1.6 GHz (turbo up to 3.9 GHz)
Windows 10 IoT Enterprise
User Guide
Document Version 1.0
Document Part No. 91711110110H
Please read these instructions before operating the device and retain them for future reference.
Advertisement
Table of Contents
Related Manuals for Winmate R08IWK8M-RTU1GP
Summary of Contents for Winmate R08IWK8M-RTU1GP
- Page 1 8.4”/ 10.4” Ultra-Rugged Tablet R08IWK8M-RTU1GP R10IWK8M-RTT2GP 8th Gen. Intel® Core™ i5-8265U, 1.6 GHz (turbo up to 3.9 GHz) Windows 10 IoT Enterprise User Guide Document Version 1.0 Document Part No. 91711110110H Please read these instructions before operating the device and retain them for future reference.
-
Page 2: Table Of Contents
8.4"/ 10.4" Ultra-Rugged Tablet User Guide Contents CHAPTER 1: READ ME FIRST ............................3 1.1 A ............................3 DVISORY ONVENTIONS 1.2 S ...............................4 AFETY NFORMATION 1.3 H ...........................6 ANDLING AND AINTENANCE 1.4 D C) .........................7 ECLARATION OF ONFORMITY CHAPTER 2: GETTING STARTED ..........................8 2.1 O ................................8 VERVIEW... -
Page 3: Chapter 1: Read Me First
Chapter 1: Read Me First Chapter 1: Read Me First 1.1 Advisory Conventions Four types of advisories are used throughout the user manual to provide helpful information or to alert you to the potential for hardware damage or personal injury. These are Notes, Important, Cautions, and Warnings. -
Page 4: Safety Information
8.4"/ 10.4" Ultra-Rugged Tablet User Guide 1.2 Safety Information When the Battery Pack Has Deteriorated, Replace It with a New Battery. Continued use of a damaged battery pack may result in heat Precaution on Battery Pack generation, ignition or battery rupture. Précaution avec le bloc-pile [FR] Lorsque la pile est détériorée, la remplacer par une nouvelle pile. - Page 5 Chapter 1: Read Me First This product should not be used near water General Product Safety such as bathtubs, sinks, swimming pools, wet Sécurité générale des basement, etc. produits [FR] Ce produit ne dois pas être utilisé près de l'eau comme les baignoires, les éviers, les ...
-
Page 6: Handling And Maintenance
8.4"/ 10.4" Ultra-Rugged Tablet User Guide 1.3 Handling and Maintenance Gently wipe the display with a soft, lint-free cloth. Do not use alcohol or detergent on the product. General Guideline [FR] Essuyer délicatement l'écran avec un Guide Général chiffon doux non pelucheux. Ne pas utiliser d'alcool ou un détergent sur le produit. -
Page 7: Declaration Of Conformity (Doc)
Chapter 1: Read Me First 1.4 Declaration of Conformity (DoC) FCC Statement This device complies with part 15 FCC rules. Operation is subject to the following two conditions: This device may not cause harmful interference. This device must accept any interference received including interference ... -
Page 8: Chapter 2: Getting Started
8.4"/ 10.4" Ultra-Rugged Tablet User Guide Chapter 2: Getting Started 2.1 Overview This chapter tells you information about Winmate® Ultra-Rugged Tablet Computer, its highlighted features, and provides basic instructions for using the Ultra-Rugged Tablet Computer. • Introduction • Product Features •... -
Page 9: Unpacking
Chapter 2: Getting Started 2.4 Unpacking If any of the following items are missing or damaged, contact us. Standard packing list includes: • Tablet Computer • Standard Battery • Power Adapter • Power Cord and Plugs • Driver CD & User Manual Quick Start Guide •... -
Page 10: Description Of Parts
8.4"/ 10.4" Ultra-Rugged Tablet User Guide 2.5 Description of Parts 8.4”, R08IWK8M-RTU1GP Front: Right: Left: Item Description No Item Description Resistive Display acts as one of High speed USB port Touch Screen connects to USB the inputs for the 2 x USB 3.0... - Page 11 Chapter 2: Getting Started Rear: Top: Bottom: Item Description Item Description Stylus Stylus pen to optimize Docking Port to docking the touch performance Connector solutions such as Adjustable This adjustable vehicle docking to Kickstand kickstand allows user to provide power and adjust their viewing external antenna.
- Page 12 8.4"/ 10.4" Ultra-Rugged Tablet User Guide 10.4”, R10IWK8M-RTT2GP Left: ront: Right: Item Description No Item Description Resistive Display acts as one of Power Power On/Off the unit Touch Screen the inputs for the High speed USB port Tablet Computer connects to USB Speaker 2 x 1 Watt Speaker 2 x USB 3.0...
- Page 13 Chapter 2: Getting Started Rear: Top: Bottom: Item Description Item Description Stylus Stylus pen to optimize Docking Port to docking the touch performance Connector solutions such as Adjustable This adjustable vehicle docking to Kickstand kickstand allows user provide power and to adjust their viewing external antenna.
-
Page 14: Hotkey For Specific Functions
8.4"/ 10.4" Ultra-Rugged Tablet User Guide 2.6 HotKey for Specific Functions For the physical buttons on the Ultra-Rugged Tablet Computer, in addition to their dedicated functions detailed in the previous section, they can also be used to emulate commonly used keyboard keystrokes. -
Page 15: Led Indicators
Chapter 2: Getting Started 2.7 LED Indicators 10.4” Item Description Icon Green – Tablet is ON. Power Indicator No light – Tablet is OFF. Battery Status Orange – AC adapter is plugged in and charging. Red – Battery is Low and needs to be charged. Disk Green - Disk Activity. -
Page 16: Installing Micro Sd Card
8.4"/ 10.4" Ultra-Rugged Tablet User Guide Place the Tablet (back facing up) and insert the battery into the battery slot. To remove the battery pack: 1. Power off the Tablet Computer (or turn on sleep mode). Disconnect any cords connected to the Tablet Computer. 2. -
Page 17: Connecting To Power Supply
Chapter 2: Getting Started Before using the data connection program, please perform the following procedures to insert the SIM Card into your Tablet Computer: 1. Power off the Tablet Computer. 2. Open the I/O Cover. 3. Insert the SIM card in to the SIM Card slot. 2.12 Connecting to Power Supply The Tablet Computer operates either on external AC power or internal battery power. -
Page 18: Powering On And Off
8.4"/ 10.4" Ultra-Rugged Tablet User Guide When the AC Adapter is connected, the battery pack starts charging. The battery LED indicator on the Tablet Computer would show different states. Please refer to description of LED indicator on Description of Parts. 2.13 Powering On and Off Powering On Press and hold the power button for 3 seconds until the blue LED power indicator light up. -
Page 19: Chapter 3: First Time Operation
Chapter 3: First Time Operation Chapter 3: First Time Operation This section details how to different setup version of the Windows that may be installed on the Tablet for the first time. Note: Please note that BIOS varies by different Windows OS; for users to change OS, please contact our sales contact window for details. - Page 20 8.4"/ 10.4" Ultra-Rugged Tablet User Guide On the Here’s the legal stuff screen, read through the disclosures, then tap Accept. Windows will then try to connect to network. Tap Skip this step to continue without a wireless connection as you can then set up the network later. On the Get going fast screen, click Use Express settings for the fastest setup.
- Page 21 Chapter 3: First Time Operation To create a local account, type your User name, password, and Password hint in the fields provided, then tap Next. The initial setup screens are complete, and the desktop is displayed. Read any introductory screens describing features of your Computer, and tap Next upon completing each.
-
Page 22: Chapter 4: Quick Access With Win-Set
8.4"/ 10.4" Ultra-Rugged Tablet User Guide Chapter 4: Quick Access with Win-set 4.1 Win-set Introduction Win-set provides quick access to the Tablet’s functions and features, such as setting up shortcuts, using the camera, powering on/off built-in devices, programming function key, and changing power management. -
Page 23: System Information
Chapter 4: Quick Access with Win-set 4.2 System Information The System Information menu provides information about the Tablet Computer, including BIOS version, EC Version, Win-set Version, OS Version, Serial Number, Model Name, Battery Health, and Password. In this section, you can check for the updates, and set a new password. 4.3 Function Buttons Shows function button settings, and allows changing settings if required. - Page 24 8.4"/ 10.4" Ultra-Rugged Tablet User Guide 3. Enter the path to Dbgview application, select Dbgview and press Open. 4. F1 function button is set to Dbgview.
-
Page 25: Arrow Keys
Chapter 4: Quick Access with Win-set To delete the F1 function button setting to Dbgview, press DEL next to F1 button. 4.3.2 Arrow Keys Select Brightness or Volume of arrow keys functions. Brightness If arrow keys set to brightness you can control brightness with arrow keys. Select AutoBrightness for automatic brightness adjustment based on the ambient light conditions. - Page 26 8.4"/ 10.4" Ultra-Rugged Tablet User Guide Volume If arrow keys set to volume you can control volume with arrow keys. The menu is located on the bottom of the desktop screen.
-
Page 27: Device Control
Chapter 4: Quick Access with Win-set 4.3.3 Device Control The Device Control menu shows the status and allows changing settings of WiFi, WWAN, GPS, BT, and Barcode Scanner Wedge. Important: Notice that some functions are optional and may not be present in your device. -
Page 28: Chapter 5: Frequently Used Settings
Note: Winmate recommends the users set the scaling to this setting for optimal text and image viewing. Before proceeding to change the scaling option, make sure any opened document is saved and close, and all running applications are closed before proceeding to change the display scaling, because this procedure requires users to log out of their account to apply display scaling change. -
Page 29: Using Recovery Wizard To Restore Computer
Chapter 5: Frequently Used Settings 2. The following panel will open. Here you can adjust the size of text, apps, and other items and also change the orientation. To change the resolution settings, scroll down this window and click on Advanced Display Settings 5.3 Using Recovery Wizard to Restore Computer The tablet computer has a dedicate recovery partition stored on the hard drive of the Tablet to enable quick one-key recovery process. - Page 30 8.4"/ 10.4" Ultra-Rugged Tablet User Guide 4. A warning message about data loss will show up. Make sure data is backed up before recovery, and click on “Yes” to continue. 5. Wait the recovery process to complete. During the recovery process, a command prompt will show up to indicate the percentage of recovery process complete.
-
Page 31: Com Port Switch Rs232/ 422/ 485
Chapter 5: Frequently Used Settings 5.4 COM Port Switch RS232/ 422/ 485 Use BIOS setup utility setting to change COM port settings RS232/422/485. To change COM Port RS232 /422/ 485 setting: 1. To enter the BIOS setup, you need to connect an external USB keyboard to the Tablet Computer and press Del key when the prompt appears on the screen during start up. - Page 32 8.4"/ 10.4" Ultra-Rugged Tablet User Guide 3. Open Serial Port A UART Mode to select RS232/422/485.
-
Page 33: Chapter 6: Troubleshooting
Chapter 6: Troubleshooting Chapter 6: Troubleshooting 6.1 Basic Troubleshooting Problem Solution The removable battery is not charging • Make sure the AC adapter is properly connected, and that the removable battery is properly inserted. Nothing appears on the screen • The Tablet Computer may be in sleep mode. - Page 34 8.4"/ 10.4" Ultra-Rugged Tablet User Guide Problem Solution The GPS application cannot find my • Make sure that GPS is powered on in location Win-set. • Make sure that GPS receiver and the location sensor are enabled in Control Panel. •...
-
Page 35: Appendix A: Technical Specifications
Appendix A: Technical Specifications Appendix A: Technical Specifications Model Name R08IWK8M-RTU1GP R10IWK8M-RTT2GP Display Size 8.4" 10.4" Resolution 800 x 600 1024 x 768 Brightness 600 nits 700 nits Contrast Ratio 600:1 1000:1 Viewing Angles 75/75/60/70 88/88/88/88 Touch Resistive Touch Resistive Touch System Specifications Intel®... - Page 36 8.4"/ 10.4" Ultra-Rugged Tablet User Guide Model R08IWK8M-RTU1GP R10IWK8M-RTT2GP Mechanical and Environment MIL-STD-810G Method 514.6 Vibration MIL-STD-810G Method 514.6 Procedure I Procedure I MIL-STD-810G Method 516.6, MIL-STD-810G Method 516.6, 4ft Drop 4ft to concrete to concrete IP Rating Default IP54 (Optional IP65)
-
Page 37: Appendix B: Dimensions And Schematics
Appendix B: Dimensions and Schematics Appendix B: Dimensions and Schematics This is a simplified drawing and some components are not marked in detail. 8.4”, R08IWK8M-RTU1GP Default Configuration 8.4”, R08IWK8M-RTU1GPKS Optional Configuration... - Page 38 8.4"/ 10.4" Ultra-Rugged Tablet User Guide 10.4”, R10IWK8M-RTT2GP Default Configuration 10.4”, R10IWK8M-RTT2GPKS Optional Configuration...
- Page 39 Notes ______________________________________________________________________________________________ ______________________________________________________________________________________________ ______________________________________________________________________________________________ ______________________________________________________________________________________________ ______________________________________________________________________________________________ ______________________________________________________________________________________________ ______________________________________________________________________________________________ ______________________________________________________________________________________________ ______________________________________________________________________________________________ ______________________________________________________________________________________________ ______________________________________________________________________________________________ ______________________________________________________________________________________________ ______________________________________________________________________________________________ ______________________________________________________________________________________________ ______________________________________________________________________________________________ ______________________________________________________________________________________________ ______________________________________________________________________________________________ ______________________________________________________________________________________________ ______________________________________________________________________________________________ ______________________________________________________________________________________________ ______________________________________________________________________________________________ ______________________________________________________________________________________________ ______________________________________________________________________________________________ ______________________________________________________________________________________________ ______________________________________________________________________________________________ ______________________________________________________________________________________________ ______________________________________________________________________________________________ ______________________________________________________________________________________________ ______________________________________________________________________________________________ ______________________________________________________________________________________________ ______________________________________________________________________________________________ ______________________________________________________________________________________________...
- Page 40 Winmate Inc. 9F, No.111-6, Shing-De Rd., San-Chung District, New Taipei City 24158, Taiwan, R.O.C www.winmate.com Copyright © 2018 Winmate Inc. All rights reserved.
