Page 1: User Manual
M-Series HMI 12.1”/15”/17”/19”/ 21.5” P-CAP touchscreen Intel® Core ™ i5-5200U 2.70 GHz Multifunctional Design Model No.: R12IHWS-MHM2 R15IHWS-MHC3 R17IHWS-MHM1 R19IHWS-MHA1 W22IHWS-MHA3 User Manual Version 1.3 Document Part Number: 9152111I100O... - Page 2 PREFACE Copyright Notice No part of this document may be reproduced, copied, translated, or transmitted in any form or by any means, electronic or mechanical, for any purpose, without the prior written permission of the original manufacturer. Trademark Acknowledgement Brand and product names are trademarks or registered trademarks of their respective owners. Disclaimer We reserve the right to make changes, without notice, to any product, including circuits and/or software described or contained in this manual in order to improve design and/or performance.
-
Page 3: Customer Service
Customer Service We provide a service guide for any problem by the following steps: First, visit the website of our distributor to find the update information about the product. Second, contact with your distributor, sales representative, or our customer service center for technical support if you need additional assistance. - Page 4 Advisory Conventions Four types of advisories are used throughout the user manual to provide helpful information or to alert you to the potential for hardware damage or personal injury. These are Notes, Important, Cautions, and Warnings. The following is an example of each type of advisory. NOTE: A note is used to emphasize helpful information IMPORTANT:...
-
Page 5: Safety Information
Safety Information WARNING! / AVERTISSEMENT! Always completely disconnect the power cord from your chassis whenever you work with the hardware. Do not make connections while the power is on. Sensitive electronic components can be damaged by sudden power surges. Only experienced electronics personnel should open the PC chassis. Toujours débrancher le cordon d’alimentation du chassis lorsque vous travaillez sur celui-ci. -
Page 6: Safety Precautions
Safety Precautions For your safety carefully read all the safety instructions before using the device. Keep this user manual for future reference. Always disconnect this equipment from any AC outlet before cleaning. Do not use liquid or spray detergents for cleaning. Use a damp cloth. ... - Page 7 CAUTION/ATTENTION Use the recommended mounting apparatus to avoid risk of injury. Utiliser l’appareil de fixation recommandé pour éliminer le risque de blessure. WARNING! / AVERTISSEMENT! Only use the connection cords that come with the product. When in doubt, please contact the manufacturer. Utiliser seulement les cordons d’alimentation fournis avec le produit.
-
Page 8: Important Information
Important Information Countries/ Area Symbol This equipment complies with essential requirements European Union Electromagnetic Compatibility Directive (2014/30/EU) Low Voltage Directive (2014/35/EU) Restrictions of the use of certain hazardous substances (RoHS) Directive (2011/65/EU) FCC Part 15 Subpart B Regulations Class B Federal Communications Commission Radio Frequency Interface Statement This device complies with part 15 FCC rules. - Page 9 European Union This equipment is in conformity with the requirement of the following EU legislations and harmonized standards. Product also complies with the Council directions. Electromagnetic Compatibility Directive (2014/30/EU) EN55024: 2010/ A1: 2015 o IEC61000-4-2: 2009 o IEC61000-4-3: 2006+A1: 2007+A2: 2010 o IEC61000-4-4: 2012 o IEC61000-4-5: 2014 o IEC61000-4-6: 2014...
-
Page 10: About This User Manual
ABOUT THIS USER MANUAL This User Manual provides information about using the Winmate® M-Series HMI with Intel® Core ™ i5-5200U 2.70 GHz processor. The documentation set for the M -Series HMI provides information for specific user needs, and includes: M-Series HMI User Manual – contains detailed description on how to use the HMI, its components and features. -
Page 11: Table Of Contents
CONTENTS PREFACE ............................ii ABOUT THIS USER MANUAL ......................x CHAPTER 1: INTRODUCTION ......................1 1.1 Product Features ........................1 1.4 Package Contents ......................... 2 1.5 Product Overwiew ....................... 3 1.6 Dimensions ........................... 4 1.6.1 Dimensions 12.1” ...................... 4 1.6.2 Dimensions 15” ......................5 1.6.3 Dimensions 17”... - Page 12 6.3.1 VESA Mounting ....................... 82 CHAPTER 7: TECHNICAL SUPPORT ....................84 7.1 Software Developer Support ..................... 84 7.1.1 Winmate Download Center ..................84 7.1.2 Winmate File Share ....................84 7.2 Problem Report Form ......................85 APPENDIX A: PRODUCT SPECIFICATIONS ..................87...
- Page 13 USER MANUAL CHAPTER 1 INTRODUCTION INTRODUCTION This chapter gives you product overview, describes features and hardware specification. You will find all accessories that come with the HMI device in the packing list. Mechanical dimensions and drawings included in this chapter. M-SERIES HMI...
-
Page 14: Chapter 1: Introduction
CHAPTER 1 INTRODUCTION CHAPTER 1: INTRODUCTION Thank you for purchasing Winmate® M-Series HMI. M-Series HMI is designed to provide versatile and cost-effective solution for your industrial needs. P-cap multi-touch screen equipped with industrial motherboard offers various input/ output connectors. Intel®... -
Page 15: Package Contents
USER MANUAL CHAPTER 1 INTRODUCTION 1.4 Package Contents Carefully remove the box and unpack your HMI device. Please check if all the items listed below are inside your package. If any of these items are missing or damaged contact us immediately. -
Page 16: Product Overwiew
USER MANUAL CHAPTER 1 INTRODUCTION 1.5 Product Overwiew Description Description PCIe Slot cover for PCIe x 4 ① ⑨ COM2 ( 1 x Half-length PCIe card) ② 12-24V isolation DC in ⑩ COM1 ③ ⑪ 2.5” SSD Bay x 2 ④... -
Page 17: Dimensions
USER MANUAL CHAPTER 1 INTRODUCTION 1.6 Dimensions This section contains mechanical drawing of the HMI devices. Notice that this is a simplified drawing and some components are not marked in detail. 1.6.1 Dimensions 12.1” Unit: mm M-SERIES HMI... -
Page 18: Dimensions 15
USER MANUAL CHAPTER 1 INTRODUCTION 1.6.2 Dimensions 15” Unit: mm M-SERIES HMI... -
Page 19: Dimensions 17
USER MANUAL CHAPTER 1 INTRODUCTION 1.6.3 Dimensions 17” Unit: mm M-SERIES HMI... -
Page 20: Dimensions 19
USER MANUAL CHAPTER 1 INTRODUCTION 1.6.4 Dimensions 19” Unit: mm M-SERIES HMI... -
Page 21: Dimensions 21.5
USER MANUAL CHAPTER 1 INTRODUCTION 1.6.5 Dimensions 21.5” Unit: mm M-SERIES HMI... -
Page 22: Getting Started
USER MANUAL CHAPTER 2 GETTING STARTED GETTING STARTED This chapter tells you important information on power supply, adapter and precautions tips. Pay attention to power considerations. M-SERIES HMI... -
Page 23: Chapter 2: Getting Started
USER MANUAL CHAPTER 2 GETTING STARTED CHAPTER 2: GETTING STARTED This chapter provides information on how to connect the HMI device to the source of power, connector pinouts and the guideline to turn on/off the HMI device. 2.1 Powering On This section explains how to power on the HMI device. -
Page 24: Power Considerations
USER MANUAL CHAPTER 2 GETTING STARTED 2.1.2 Power Considerations HMI device operates on external DC power. Use the AC adapter included in the package. CAUTION/ATTENTION Use only the AC adapter included in your package (Rating: Output 12V/6.6A). Using other AC adapters may damage the device. Utiliser seulement le convertisseur AC inclu avec votre appareil (Puissance: Sortie 12V/6.6A). - Page 25 USER MANUAL CHAPTER 2 GETTING STARTED To connect the HMI to DC power source: 1. Insert the exposed wires of the DC Power Cable to the appropriate connectors on the terminal block plug. 2. Plug the terminal block plug firmly to the DC IN Jack. 3.
-
Page 26: Connector Description
USER MANUAL CHAPTER 2 GETTING STARTED 2.2 Connector Description 2.2.1 Isolated DC in Connector The M-Series HMI uses an isolated 3pin terminal block that accepts DC in 12~24V. Minimum Voltage 12V Maximum Voltage 24V Maximum Current 6.6A Voltage 2.2.2 Audio out/ Audio in Color Signal Blue... -
Page 27: Com2 Serial Port Connector
USER MANUAL CHAPTER 2 GETTING STARTED 2.2.4 COM2 Serial Port Connector The M-Series HMI uses D-SUB 9pin connector to connect serial interfaces. Pin № Signal Name Pin № Signal Name 2.2.5 Two USB 3.0 Connectors M-Series HMI has two USB3.0 connectors. Use USB3.0 connector to connect external devices such as mouse or keyboard to the HMI device. -
Page 28: Lan Connector
USER MANUAL CHAPTER 2 GETTING STARTED Pin № Signal Name Pin № Signal Name TMDS_DATA2+ TMDS_DATA2- TMDS_DATA1+ TMDS_DATA1- TMDS_DATA0+ TMDS_DATA0- TMDS_CLOCK+ TMDS_CLOCK- DDC_CLOCK DDC_DATA Hot Plug Detect 2.2.8 LAN Connector M-Series HMI supports one RJ45 10/100/1000 Mbps Ethernet interface for connecting to the internet. -
Page 29: Turning On And Off
USER MANUAL CHAPTER 2 GETTING STARTED 2.3 Turning On and Off The unit is configured to Power ON when the HMI device is connected to the power source. Press the Power button to restart the machine when the unit has been shut down. If the system hangs, press the Reset button (beside the power button) to restart the device. -
Page 30: Configuring Serial Port Settings
USER MANUAL CHAPTER 2 GETTING STARTED 2.4 Configuring Serial Port Settings Serial Port COM1 can be configured for RS-232, RS-422 or RS-485. Jumpers are located on the motherboard. You need to open the housing in order to access the jumpers. CAUTION/ ATTENTION It is recommended to use factory jumper settings. - Page 31 USER MANUAL CHAPTER 3 OPERATING THE DEVICE OPERATING THE DEVICE This chapter provides detailed information on how to operate the device. If you have been using touch-screen Panel PCs before, the interface may look familiar. Sections include system settings parameters. M-SERIES HMI...
-
Page 32: Chapter 3: Operating The Device
USER MANUAL CHAPTER 3 OPERATING THE DEVICE CHAPTER 3: OPERATING THE DEVICE In this chapter you will find instructions on how to use multi-touch on the Windows- based HMI device. 3.1 Operating System M-series HMI support several versions of Windows OS: Windows 10 IoT Enterprise, Windows Embedded 8 Standard, and Windows Embedded Standard 7 –... -
Page 33: Multi-Touch
USER MANUAL CHAPTER 3 OPERATING THE DEVICE 3.2 Multi-Touch The touchpad supports the core gestures for Windows. Gesture Windows Usage Gesture Action Action Tap/ Click / Double- Click or double-click Double-tap click Panning with Scrolling Drag one or two Inertia fingers up and down Selection/Drag Mouse-drag/... -
Page 34: Adjusting Display Brightness
USER MANUAL CHAPTER 3 OPERATING THE DEVICE 3.3 Adjusting Display Brightness Tap Start > Control Panel > Hardware and Sound > Power Options. Drag the brightness bar to adjust the brightness level according to your preference. M-SERIES HMI... -
Page 35: Driver Installation
USER MANUAL CHAPTER 4 DRIVER INSTALLATION DRIVER INSTALLATION This chapter describes how to install all necessary drivers. M-SERIES HMI... -
Page 36: Chapter 4: Driver Installation
USER MANUAL CHAPTER 4 DRIVER INSTALLATION CHAPTER 4: DRIVER INSTALLATION This chapter describes how to install all necessary drivers to M-Series HMI. 4.1 Chipset Driver The Intel Chipset Drivers should be installed first before the software drivers enable Plug & Play INF support for Intel chipset components. Follow the instructions below to complete the installation. - Page 37 USER MANUAL CHAPTER 4 DRIVER INSTALLATION Step 2 Click Next to start the installation. Step 3 Click Accept to agree with the license terms and continue the installation. M-SERIES HMI...
- Page 38 USER MANUAL CHAPTER 4 DRIVER INSTALLATION Step 4 Check ReadMe File information, and then click Install to continue. Step 5 Click Restart Now to finish the installation and restart the computer. M-SERIES HMI...
-
Page 39: Graphics Driver
USER MANUAL CHAPTER 4 DRIVER INSTALLATION 4.2 Graphics Driver The HMI device comes with Intel mobile Core i5 Dual Core CPU and integrated graphic controller. You need to install the Graphic driver to enable the function. Intel Graphic supports versatile display options and 32-bit 3D graphics engine. Triple independent display, enhanced display modes for widescreen flat panels for extend, twin, and clone display mode. - Page 40 USER MANUAL CHAPTER 4 DRIVER INSTALLATION Step 2 Click Next to continue. Step 3 Click Yes to agree with the license terms and continue the installation. M-SERIES HMI...
- Page 41 USER MANUAL CHAPTER 4 DRIVER INSTALLATION Step 4 Check ReadMe File Information and then click Next to install the driver. Step 5 Wait while the following operations are performed: M-SERIES HMI...
- Page 42 USER MANUAL CHAPTER 4 DRIVER INSTALLATION And then click Next to continue. Step 6 Select “Yes, I want to restart this computer now”, and click Finish to complete the installation. M-SERIES HMI...
-
Page 43: Audio Driver
USER MANUAL CHAPTER 4 DRIVER INSTALLATION 4.3 Audio Driver The ALC886 series are high-performance 7.1+2 Channel High Definition Audio Codecs providing ten DAC channels that simultaneously support 7.1 sound playbacks, plus 2 channels of independent stereo sound output (multiple streaming) through the front panel stereo outputs. - Page 44 USER MANUAL CHAPTER 4 DRIVER INSTALLATION Step 2 Wait while the InstallShield Wizard extracts the files needed to install Realtek HD Audio on your computer, and then click Next to continue the installation. Step 3 Click Next to continue the installation. M-SERIES HMI...
- Page 45 USER MANUAL CHAPTER 4 DRIVER INSTALLATION Step 4 Select “Yes, I want to restart my computer now”, and then click Finish to complete the installation. M-SERIES HMI...
-
Page 46: Ethernet Driver
USER MANUAL CHAPTER 4 DRIVER INSTALLATION 4.4 Ethernet Driver Users must confirm which operating system is used on the device before installing the Ethernet drivers. Follow the steps below to complete the installation of the Intel® I210IT Gigabit-LAN Controller + I218LM Gigabit-LAN drivers. You will quickly complete the installation. - Page 47 USER MANUAL CHAPTER 4 DRIVER INSTALLATION Step 3 Click Next to continue. Step 4 Click Yes to agree with the license terms and continue the installation. M-SERIES HMI...
- Page 48 USER MANUAL CHAPTER 4 DRIVER INSTALLATION Step 5 Select the program features you want to install, and then click Next to continue. Step 6 Click Install to continue the installation. M-SERIES HMI...
- Page 49 USER MANUAL CHAPTER 4 DRIVER INSTALLATION Step 7 Please wait while the install wizard installs Intel ® Network Connections, and then click Next to continue. Step 8 Click Finish to complete the installation. M-SERIES HMI...
-
Page 50: Fintek Com Port Driver
USER MANUAL CHAPTER 4 DRIVER INSTALLATION 4.5 Fintek COM Port Driver Step 1 If your system is WIN7, please first close UAC (refer to the following “Disabling User Account”) Control (UAC) in Windows 7” Step 2 Extract the Patch_0408.zip to a folder. Step 3 Double-click batch file (patch.bat) to install the driver. - Page 51 USER MANUAL CHAPTER 4 DRIVER INSTALLATION Step 5 Restart the computer to complete driver installation. Type in this command from the Run menu: C:\Windows\System32\UserAccountControlSettings.exe or UAC To turn off UAC move the slider to the Never notify position, and then click OK. If you're prompted for an administrator password or confirmation, type the password or provide confirmation.
-
Page 52: Intel® Management Engine Software
USER MANUAL CHAPTER 4 DRIVER INSTALLATION 4.6 Intel® Management Engine Software This installation program installs the Intel® ME software components required for the platform on which you are installing, and installs only those components that match your platform’s capabilities. Step 1 Insert the driver CD and select the “Intel ME 9.0” folder and click “Setup.exe” Step 2 Click “Next”... - Page 53 USER MANUAL CHAPTER 4 DRIVER INSTALLATION Step 3 Click “Yes” to agree with the License terms. Step 4 Choose “I accept the terms of the license agreement”, and click “Next” to continue. M-SERIES HMI...
- Page 54 USER MANUAL CHAPTER 4 DRIVER INSTALLATION Step 5 Click “Finish” to complete the software installation. M-SERIES HMI...
-
Page 55: Usb 3.0 Driver Installation (Windows 7)
USER MANUAL CHAPTER 4 DRIVER INSTALLATION 4.7 USB 3.0 Driver Installation (Windows 7) NOTE: If the operating system of the device is Windows 10 IoT or Windows Embedded 8 Standard, please skip this installation. Step 1 Locate the hard drive directory where the driver files are stored with the browser or the explore feature of Windows*. - Page 56 USER MANUAL CHAPTER 4 DRIVER INSTALLATION Step 2 Click Next to continue Step 3 Read the License Agreement and click Yes to proceed. M-SERIES HMI...
- Page 57 USER MANUAL CHAPTER 4 DRIVER INSTALLATION Step 5 Review Readme File Information and click Next to proceed. Step 6 When the Setup Progress is complete click Next to proceed. M-SERIES HMI...
- Page 58 USER MANUAL CHAPTER 4 DRIVER INSTALLATION Step 7 Click “Yes, I want to restart this computer now” to finish and then restart your computer. M-SERIES HMI...
- Page 59 AMI UEFI BIOS Setup BIOS Setup Utility is a program for configuration basic Input / Output system settings of the HMI for optimum use. This chapter provides information on how to use BIOS setup, its functions and menu. M-SERIES HMI...
-
Page 60: Chapter 5: Ami Uefi Bios Setup
USER MANUAL CHAPTER 5 AMI UEFI BIOS SETUP CHAPTER 5: AMI UEFI BIOS SETUP BIOS Setup Utility is a program for configuration basic Input / Output system settings of the HMI for optimum use. This chapter provides information on how to use BIOS setup, its functions and menu. -
Page 61: Main Menu
USER MANUAL CHAPTER 5 AMI UEFI BIOS SETUP The following Keys can be used after entering the BIOS Setup. Function General Help Previous Values Optimized Defaults Save & Exit Exit Change Opt. Enter Select or execute command Cursor ↑ Moves to the previous item Cursor ↓... - Page 62 USER MANUAL CHAPTER 5 AMI UEFI BIOS SETUP BIOS Setting Description Setting Option Effect System Language Displays the system Adjustment of the Set the language in language. [English] language other language. The is set up by default. language in this device is English.
-
Page 63: Advanced Menu
USER MANUAL CHAPTER 5 AMI UEFI BIOS SETUP 5.2.2 Advanced Menu The advanced menu also uses to set configuration of the CPU and other system devices. There are sub menus on the left frame of the screen. IMPORTANT: Handle advanced BIOS settings page with caution. Any changes can affect the operation of your computer. - Page 64 USER MANUAL CHAPTER 5 AMI UEFI BIOS SETUP BIOS Setting Description Setting Option Effect Configures CPU CPU Configuration Enter Opens submenu settings Configures Trusted Trusted Computing Enter Opens submenu Computing settings Configures ACPI ACPI Settings Enter Opens submenu Settings F81866 Super IO Configures F81866 Enter Opens submenu...
- Page 65 USER MANUAL CHAPTER 5 AMI UEFI BIOS SETUP 5.2.2.1 CPU Configuration CPU Configuration allows you to change CPU settings. Use key arrows to navigate through the menu. BIOS Setting Description Setting Option Effect Hyper-threading is a function in processors Enables or Enable/ Hyper-threading that speeds up...
- Page 66 USER MANUAL CHAPTER 5 AMI UEFI BIOS SETUP Technology as if you have several Disable this function independent computers, in order to enable several operating systems to run at the same time on the same machine. Auto Auto mode Allows processor cores to run at the Standard frequency...
- Page 67 USER MANUAL CHAPTER 5 AMI UEFI BIOS SETUP BIOS Setting Description Setting Option Effect Enable or disable Security Device Enable or disable BIOS support for Enabled/ Disabled Support this function. security device. Trusted Platform Enable or disable TPM State Module (TPM) Enabled/ Disabled this function.
- Page 68 USER MANUAL CHAPTER 5 AMI UEFI BIOS SETUP 5.2.2.3 ACPI Settings BIOS Setting Description Setting Option Effect Enable or disable Enable ACPI Auto Enable or disable BIOS ACPI Auto Enabled/ Disabled Configuration this function Configuration To enable or Enable or disable Enable Hibernation Enabled/ Disabled disable hibernation...
- Page 69 USER MANUAL CHAPTER 5 AMI UEFI BIOS SETUP BIOS Setting Description Setting Option Effect Set Parameters of Serial Ports. User can Enabled/ Enable or Serial Port 1,2 Enable/Disable the serial Disabled disable Serial Configuration port and select optimal Port (COM) settings for the super IO Default: Enable Device.
- Page 70 USER MANUAL CHAPTER 5 AMI UEFI BIOS SETUP 5.2.2.6 RTC Wake Settings BIOS Setting Description Setting Option Effect Enable or disable Configure wake this function. from full When enabled, Wake system from Enabled/ shutdown and the system will Disabled boot mode (S5) wake on full system setting shutdown and...
- Page 71 USER MANUAL CHAPTER 5 AMI UEFI BIOS SETUP 5.2.2.7 SATA Configuration BIOS Setting Description Setting Option Effect Allows users to enable or disable Enable or disable SATA Controller(s) Enabled/ Disabled the SATA this function controller(s). Allows users to Work in AHCI mode SATA Mode select mode of AHCI...
- Page 72 USER MANUAL CHAPTER 5 AMI UEFI BIOS SETUP 5.2.2.8 CSM Configuration Compatability Support Module Configuration. BIOS Setting Description Setting Effect Option CSM Support The Compatibility Support Enabled/ Enable or disable Module (CSM) is a Disabled the Compatibility component of the UEFI Support Module firmware that provides legacy BIOS compatibility...
- Page 73 USER MANUAL CHAPTER 5 AMI UEFI BIOS SETUP 5.2.2.9 USB Configuration BIOS Setting Description Setting Option Effect Auto Disable legacy support if no USB devices are connected Legacy USB User can enable or Disable Will keep USB Support disable USB port. devices available only for EFI applications.
- Page 74 USER MANUAL CHAPTER 5 AMI UEFI BIOS SETUP hand‐ off support. function The EHCI ownership change should be claimed by EHCI driver. USB Mass Storage User can Enable or Disable Disables this Driver Support disable USB mass function storage driver Enable Enables this support.
-
Page 75: Chipset Menu
USER MANUAL CHAPTER 5 AMI UEFI BIOS SETUP 5.2.3 Chipset Menu BIOS Setting Description Setting Option Effect System Agent (SA) System Agent (SA) Enter Opens submenu Configuration Parameters PCH-IO PCH Parameters Enter Opens submenu Configuration M-SERIES HMI... - Page 76 USER MANUAL CHAPTER 5 AMI UEFI BIOS SETUP 5.2.3.1 System Agent (SA) Configuration BIOS Setting Description Setting Option Effect VT-d can help end users improve security and reliability of the systems and also Enables or disables VT-d Enable/Disable improve this function performance of I/O devices in virtualized...
- Page 77 USER MANUAL CHAPTER 5 AMI UEFI BIOS SETUP 5.2.3.1.1 Graphics Configuration BIOS Setting Description Setting Option Effect Graphics turbo Set up the value of Graphics Turbo IMON current 14~31 Graphics turbo IMON Current values supported IMON current 14~31 Configures Internal Set up internal Internal Graphics Graphics...
- Page 78 USER MANUAL CHAPTER 5 AMI UEFI BIOS SETUP 5.2.3.2 PCI Configuration BIOS Setting Description Setting Option Effect PCI Express Configures PCI Enter Opens submenu Configuration Express parameters Configures USB USB Configuration Enter Opens submenu parameters Configures PCH Enables or disables PCH LAN Controller LAN Controller Enable/Disable...
- Page 79 USER MANUAL CHAPTER 5 AMI UEFI BIOS SETUP 5.2.3.2.1 PCI Express Configuration BIOS Setting Description Setting Option Effect The control of Active State Power DMI Link ASPM Management on Enable/ Enables or disables Control both NB side and Disable this function SB side of the DMI Link.
- Page 80 USER MANUAL CHAPTER 5 AMI UEFI BIOS SETUP PCI Express Root BIOS Setting Description Setting Option Effect PCI Express Root The control of PCI Enable/ Enables or disables Port 1 Express Root Port Disable this function Configures ASPM Enable/ Enables or disables ASPM Support Support Disable...
- Page 81 USER MANUAL CHAPTER 5 AMI UEFI BIOS SETUP parameters Configures Prefetchable Prefetchable Setting up the Set the value Memory Memory value parameters Configures Setting up the Reserved IO Reserved IO Set the value value parameters Configures PCI LTR Enable/ Enables or disables PCI LTR parameters Disable...
- Page 82 USER MANUAL CHAPTER 5 AMI UEFI BIOS SETUP BIOS Setting Description Setting Option Effect Allows user to Enable/ Enables or disables USB Precondition enable or disable Disable this function USB Precondition Allows user to Smart Auto/ Enables or disables XHCI Mode enable or disable Enable/ this function...
-
Page 83: Security Menu
USER MANUAL CHAPTER 5 AMI UEFI BIOS SETUP 5.2.4 Security Menu This section allows you to configure and improve your system and allows you to set up some system features according to your preference. BIOS Setting Description Setting Option Effect Administrator Displays whether Enter... - Page 84 USER MANUAL CHAPTER 5 AMI UEFI BIOS SETUP 5.2.4.1 Security Boot Menu BIOS Setting Description Setting Option Effect Secure Boot Secure Boot is a Enable/ Enables or disables feature designed Disable this function to prevent malicious software and unauthorized media from loading during the boot process.
-
Page 85: Boot Menu
USER MANUAL CHAPTER 5 AMI UEFI BIOS SETUP Key Management 5.2.5 Boot Menu M-SERIES HMI... - Page 86 USER MANUAL CHAPTER 5 AMI UEFI BIOS SETUP BIOS Setting Description Setting Option Effect Setup Prompt Allows user to Enter Set the prompt Timeout configure the timeout number of seconds to stay in BIOS setup prompt screen. Boot NumLock Enables or disables Remains On State NumLock feature...
-
Page 87: Save&Exit
USER MANUAL CHAPTER 5 AMI UEFI BIOS SETUP 5.2.6 Save&Exit M-SERIES HMI... - Page 88 USER MANUAL CHAPTER 5 AMI UEFI BIOS SETUP BIOS Setting Description Setting Option Effect Save Changes and This saves the changes <YES> Save changes Exit to the CMOS and exits the BIOS Setup program. Discard Changes This exits the BIOS Setup <YES>...
-
Page 89: Using Recovery Wizard To Restore Computer
USER MANUAL CHAPTER 5 AMI UEFI BIOS SETUP 5.3 Using Recovery Wizard to Restore Computer Note: Before starting the recovery process, make sure to backup all user data. The data will be lost after the recovery process. To enable quick one-key recovery procedure: ... - Page 90 USER MANUAL CHAPTER 5 AMI UEFI BIOS SETUP A warning message about data loss will show up. Make sure the data is backed up before recovery, and click Yes to continue. Wait the recovery process to complete. During the recovery process, a command prompt will show up to indicate the percent of recovery process complete.
-
Page 91: Mounting Options
USER MANUAL CHAPTER 6 MOUNTING MOUNTING This chapter provides step-by-step mounting guide for all available mounting options. M-SERIES HMI... -
Page 92: Chapter 6: Mounting
USER MANUAL CHAPTER 6 MOUNTING CHAPTER 6: MOUNTING This chapter provides mounting guide for all available mounting options. Pay attention to cautions and warning to avoid any damages. WARNING! / AVERTISSEMENT! Follow mounting instructions and use recommended mounting hardware to avoid the risk of injury. Suivez les instructions de montage et d'utilisation recommandé... -
Page 93: Safety Precautions
USER MANUAL CHAPTER 6 MOUNTING 6.2 Safety Precautions Observe the following common safety precautions before installing the HMI device: • Use separate, non-intersecting paths to route power and networking wires. If power wiring and device wiring paths must be crossed make sure the wires are perpendicular at the intersection point. -
Page 94: Panel Mounting
USER MANUAL CHAPTER 6 MOUNTING 6.3.2 Panel Mounting Panel Mounting solution allows installing the HMI device onto the wall. Cutout dimension ( W x D in mm) 12.1” 15” 17” 19” 21.5” 301 x 237 342 x 261 373 x 311 412 x 338 504 x 304 Mounting Clips... -
Page 95: Vesa Mounting
CHAPTER 6 MOUNTING 6.3.1 VESA Mounting M-Series HMI comes with VESA mount holes on the rear side. Follow instructions below to mount the unit with VESA Mount bracket (not supplied by Winmate). VESA Plate Dimensions Screw Hole Diameter Compatibility 100 x 100 mm... -
Page 96: Technical Support
USER MANUAL CHAPTER 7 TECHNICAL SUPPORT Technical Support This chapter includes directory to technical support. M-SERIES HMI... -
Page 97: Chapter 7: Technical Support
Watchdog SDK and AP You can find SDK in the driver CD that comes in the package with the HMI device. Also, you can download SDK and Drivers from Winmate Download Center or Winmate File Share. 7.1.1 Winmate Download Center http://www.winmate.com.tw/>... -
Page 98: Problem Report Form
USER MANUAL CHAPTER 7 TECHNICAL SUPPORT 7.2 Problem Report Form M-Series HMI (Multifunctional Design) Customer name: Company: Tel.: Fax: E-mail: Date: Product Serial Number: ___________________________________________________ Problem Description: Please describe the problem as clearly as possible. Detailed description of the occurred problem will allow us to find the best solution to solve the problem as soon as possible. -
Page 99: Product Specifications
USER MANUAL APPENDIX A PRODUCT SPECIFICATIONS PRODUCT SPECIFICATIONS This section includes product specifications. Appendix M-Series HMI... -
Page 100: Appendix A: Product Specifications
USER MANUAL APPENDIX A PRODUCT SPECIFICATIONS APPENDIX A: PRODUCT SPECIFICATIONS Model Name R12IHWS- R15IHWS- R17IHWS- R19IHWS- W22IHWS- MHM2 MHC3 MHM1 MHA1 MHA3 Display 12” Size 15” 17” 19” 21.5” Active Display 245.76 x 376.32 x 476.64 x 304.1 x 228.1 337.9 x 270.3 Area (H x V) 184.32... - Page 101 USER MANUAL APPENDIX A PRODUCT SPECIFICATIONS Mechanical Specification Cooling System Fanless design Mounting Wall mount/ VESA mount Environmental Consideration Operating 0 to +50°C Temperature Operating 30%~95% at 40°C (non-condensing, RH) Humidity Front: IP65 IP Rating Full: IP20 Power Specifications Power Input 12-24V DC with isolation Power Adapter 110-240 AC to 12V DC out 80W...
- Page 102 Winmate Inc. 9F, No.111-6, Shing-De Rd., San-Chung District, New Taipei City 24158, Taiwan, R.O.C Tel: 886-2-8511-0288 Fax: 886-2-8511-0211 Email: sales@winmate.com.tw Official website: www.winmate.com...
