Page 1
Cuchen IH Electric Pressure Rice Cooker – User Manual Read this manual carefully before use to ensure the proper use of your Cuchen electric pressure rice cooker. Once you have finished reading it, keep the manual at a place where other people would be able to find it easily.
Page 2
Thank you for purchasing a Cuchen electric pressure rice cooker. To ensure proper use and maintenance of the product, please read this manual carefully. Also, refer to this document if you experience issues or problems while using the product. Keep the document properly.
Contents Before Use Safety Precautions ……………………… 4 Name and Features of Each Part ……… 8 Care and Maintenance ……………… 10 Operating Suggestions ………………………… 14 Instructions Setting the Clock …………………… 15 Taste Control ………………………… 16 Cooking Rice ………………………… 18 Preset ………………………………… 20 Cooking/Preset for STEAM and SLOW …………………...
Safety Precautions ※ Information contained in this section serve to protect the user’s safety and prevent damage to property. ※ Carefully read and follow all safety precautions. Danger Risk of severe injury or even death is assumed if the instructions are not followed. Warning Risk of serious injury or property damage is assumed if the instructions are not followed.
Page 5
Before Use Installation Avoid exposure to direct sunlight and heat- Do not use or store combustible gases or inflam- radiating appliances. mable materials in the product’s vicinity. Danger There is risk of fire, There is risk of fire. deformation, and discoloration.
Page 6
Safety Precautions During Use Do not place a stainless steel plate, a Do not disassemble, repair, or modify Do not clog the product’s inlets planch, a Korean cushion, an electric the product on your own. or other openings with debris. If blanket, a steel plate, tinfoil, a copper clogged, unplug the power cord Danger...
Page 7
Before Use Contact the service center if the Do not overfill the inner pot. Do not place magnetic objects inner pot’s coating has been dam- on top of the lid or use the The rice may aged or peeled. cooker in the vicinity of highly not cook Caution magnetic objects.
Name and Features of Each Part Front / Inside Auto Pressure Regulator Pressure Cap (Steam Vent) Regulates the cooker’s internal pressure. Since this device is equipped with the steam discharging device, the former automatically discharges Lid Lock Handle steam from the inner pot. Cooking will not commence until the Lid Steam Cap Lock is in the "Lock"...
Page 9
Before Use Controls/Display STEAM WARM/ Status Display LED PRESSURE/QUICK Button REHEAT Button ※ Displays the current operation status simply. 1. Used to start cooking in each of Displays the status in the color of the LED. the menus. Used to enter Warm or ※...
Care and Maintenance Cleaning the Clean Cover After washing the clean cover, make sure to dry it completely before attaching it back on. y Not keeping the clean cover clean is one of the causes of rice taking on a smell while being kept warm. (Pull out the power cord first and allow the cooker to cool before cleaning.) y Clean the main unit and the lid, in particular, the inner packing of the clean cover using a wrung out kitchen towel.
Page 11
Operating Instructions Caution: If the pressure packing or inner packing is not properly Proper Assembly attached, it may cause steam to leak. Text Shown Right Side Up <Rear View of the Clean Cover> <Front View of the Clean Cover> The texts are shown in the opposite order. The texts should be shown properly, and the bumps of ※ Do not insert screws or any other foreign object into the hole.
Page 12
Care and Maintenance Cleaning Unplug the power cord before cleaning. Do not spray water directly on the product and do not use benzene or thinner to clean. Failure to keep the cooker clean is one of the causes of rice taking on a smell while being kept warm. Inner Pot Inner Pot Lid and Pressure Packing Do not use a rough or metallic scrubber, a rough...
Page 13
Operating Instructions Cleaning the Pressure Nozzle If the pressure regulation nozzle’s Pressure Cap/ packing is out of place as shown in Pressure Regulation the figure on the left, steam will be Nozzle allowed to seep through. Ensure that the packing is properly seated in place.
Suggestions Cooking flavorful rice starts from using the right amount of water. - 4 Servings of PLAIN - Type of Rice Water Level Cooking Old Rice or to Cooking Fresh/Soaked Rice Get Fluffy Rice or to Get Hard-Boiled Rice Old Rice Slightly above the scale Fresh Rice Slightly below the scale...
X Lithium Ion Battery Cuchen electric pressure rice cookers feature a lithium ion battery that powers the power outage compensation and clock features. The battery’s lifecycle may vary depending on the product’s specifi cations.
X Melanoizing Cooking rice with a Cuchen electric pressure rice cooker leaves rice at the bottom of the pot slightly brown in color. This is known as "melanoizing" and adds savory flavor and aroma to the cooked rice.
Page 17
Operating Instructions Fine-Tuning ※ Fine-tuning is enabled in PLAIN, MIXED, BROWN, BARLEY, and NURUNGJI modes only. ※ Fine-tuning is disabled in the Preset option. Press the MENU/TASTE CONTROL button to Press and hold the MENU/TASTE CONTROL select the desired menu. button for three seconds under the desired menu to display the current Soak and Heat settings.
Cooking Rice Instructions Plug in the cooker, close the lid, and turn the Lid Use the MENU/TASTE CONTROL button to Lock to the Lock position. select the desired menu. y Ensure that the pressure packing is seated properly Whenever you press the MENU/TASTE CONTROL and that the pressure cap is on fl at.
Page 19
Operating Instructions Cooking Duration Menu PLAIN MINI MIXED MIXED COOK- BROWN GABA (HEALTH BARLEY STEAM SLOW QUICK RUNGJI MIXED) Cat- STICKY Misc. egory Servings 2 to 10 2 to 8 2 to 6 2 to 6 2 to 6 2 to 6 2 to 6 2 to 10 For detailed cooking...
Preset Cooking in Preset Mode (When current time is 8:00 PM and the cooker is preset to the PLAIN STICKY menu at 8:00 AM) Check to see if the clock setting is correct. For instructions for setting the current time, see p.15. If the current clock setting is incorrect, the preset time will not be accurate.
Cooking and Preset in STEAM and SLOW Modes Instructions for Cooking (For 40 minutes in STEAM mode) Press the MENU/TASTE CONTROL button. - Select "STEAM" or "SLOW." - Use the HOUR or MIN button to select cooking duration for "STEAM" or "SLOW" mode. STEAM SLOW Blink...
Keeping Warm ENERGY KEEP WARM (ENERGY KEEP WARM at 7:30 AM in PLAIN STICKY mode) Check to see if the clock setting is correct. Press the ENERGY KEEP WARM button and then the PRESET button for at least one second to enter Energy Keep Warm mode.
Page 23
Operating Instructions Adjusting Warming Temperature Settings Press the STEAM WARM/REHEAT button for at least fi ve seconds to enter warming temperature setting mode. Use the HOUR or MIN button to set the desired warming temperature. Blink y The default temperature is 74 °C. y The temperature can be changed to between 69 °C and 77 °C.
Language and Volume Control/AUTO CLEAN Language and Volume Control Press and hold the CANCEL button for at least three seconds. Press and hold the CANCEL button for at least 3 seconds in standby to enable the language and volume control feature. Blink Default Settings: Korean and Level 2 ※...
Key Backlight ※ This feature enables the key backlight to turn off when the rice cooker does not need to be used. ※ If you press a button when the backlight is turned off, the backlight of every key will turn on again. In this case, the pressed button will be disabled.
Recipes Create amazing dishes with a Cuchen product! Five-Grain Rice Cooking in MIXED Mode Ingredients : 2 cups of sticky rice, 1/2 cup of black beans, 1/2 cup of red beans, 1/2 tablespoon of salt, 1 cup of waxy sorghum+glutinous millet+glutinous Chinese millet (1 part each), and 3 cups of...
Page 27
Operating Instructions Jujube Tea Cooking in SLOW Mode Ingredients : 6~7 servings 180g of jujube, ginger, and a small amount of honey (sugar) 10 servings 200g of jujubes, ginger, and a small amount of honey (sugar) Directions 1. Thoroughly rinse and tear the jujubes, and slice the 6 to 7 Servings Scale for 6 Servings of Plain Rice ginger.
Troubleshooting before Contacting the Service Center Check the information below before contacting the service center: A fully functional cooker may appear to be malfunctioning if you are not familiar with the cooker’s usage or due to easily correctable causes. If you are experiencing a problem with the product’s use, troubleshoot by referencing the information below.
Page 29
Operating Instructions Problem Check Troubleshooting Automatically the preset time is adjusted Did you set the duration of the Preset op- to 13 hours, and Preset mode starts. tion to greater than 13 hours? is shown on Automatically the preset time is ad- the display.
Page 34
제품규격 제품명 IH 전기압력보온밥솥 BT10 Series 정격전압 및 주파수 AC 120V , 60Hz 정격 소비전력 1400W(취사시)/100W(보온시) 최대취사용량 1.8L (10인분) 조정장치 압력 / 안전장치 압력 88.3 Kpa / 166.7 Kpa 제품크기 411(길이)X300(폭)X282(높이) 중량 7.3 Kg ※ 제품의 성능 개선을 위하여 약간의 규격변동이 있을 수 있습니다. BEAUTY 10 .indd 2 2012-09-18 9:33:09...
Page 35
차 례 사용하기전에 안전을 위한 주의사항 ………………………04 각 부분의 이름 및 기능 ………………………08 제품손질 방법 ……………………………… 10 사용하기 맛있는 밥을 지으려면 ……………………… 14 현재시각 맞추는 방법 ……………………… 15 밥맛 조절 기능 ……………………………… 16 밥 짓는 방법 ………………………………… 18 예약취사 방법 ……………………………… 20 영양찜...
Page 41
스팀보온/재가열 버튼 상태 표시 알림 LED 표시부 압력취사/쾌속 버튼 보온 및 재가열 동작시 ※ 현재의 동작상태를 간단히 상태 표시 알림 . 각 메뉴의 취사 시작시 사용합니다. 사용합니다. LED의 색깔로 표시하여 줍니다. ※ 밥솥의 동작상태에 해당하는 상태 표시 알림색깔 2. 압력취사/쾌속취사 버튼을 - 녹색...
Page 47
압력취사/쾌속취사 버튼을 눌러 현재시각 설정을 완료해 주십시오. ※ 압력취사/쾌속취사 버튼을 누르지 않고 15초가 지나면 자동으로 설정됩니다. ※ 현재 시간 변경 후 15초 이내에 취소 버튼을 누르면 변경 전의 시각으로 복귀됩니다. ▶ 정전 보상 기능 쿠첸 전기압력밥솥은 정전이 일어날 때 정전 이전의 상태를 기억하는 기능이 있어 정전 후에 다시 전기가 들어오면...
Page 50
메뉴/밥맛조절 버튼을 누를 때 백미찰진밥 → 백미중간밥 → 백미일반밥 → 백미쾌속 → 잡곡 → 잡곡쾌속 → 미니취사 → 현미 → 활성현미 → 꽁보리밥 → 누룽지 → 영양찜 → 슬로우쿡 순으로 반복 선택됩니다. • 증기배출 전에 증기배출 음성멘트가 나간 후 증기가 자동 배출되므로 놀라거나 화상을...
Page 51
메 백미 뉴 미니 활성 잡곡 꽁보 슬로 잡곡밥 명 현미 누룽지 영양찜 취사 현미 쾌속 리밥 우쿡 (건강잡곡) 구 찰진밥 기타 분 취 2인분 2인분 2인분 2인분 2인분 2인분 2인분 2인분 사 2인분 10인분 8인분 6인분 6인분 6인분 6인분 6인분...
Page 52
예) 현재시각이 오후 8시이고 오전 8시에 밥을 드시고자 할 경우입니다. ① 현재시각이 오후 8시가 맞는지 확인하고 예약 버튼을 누릅니다. 예약시각이 표시되어 있으며 예약 키 백라이트와 취사 키 백라이트로 예약 진행중임을 표시합니다. 표시부에 초기 예약시간인 “오전 7: 3 0”이 표시 됩니다. ②...
Page 53
영양찜 및 슬로우쿡 취사/예약방법 (영양찜 40분 취사시) 메뉴/밥맛조절 버튼을 눌러 주십시오. -“영양찜”또는“슬로우쿡”을 선택하여 주십시오. - 시 또는 분 버튼을 눌러“영양찜”또는“슬로우쿡”의 시간설정을 해 주십시오. 영양찜 슬로우쿡 영양찜 또는 슬로우쿡 취사가 시작되면 남은 시간이 표시됩니다. (오후 4시 30분에 영양찜 취사시) 메뉴/밥맛조절 버튼을 눌러 주십시오. -“영양찜”또는“슬로우쿡”을 선택하여 주십시오. - 시...
Page 54
보온 버튼을 누른 후 예약 버튼을 1초 이상 누르면 절약 보온 설정 모드로 진입합니다. ※ 절약 보온 설정 시 키 백라이트 기능을 이용하여 절약 보온시 사용하는 버튼에만 불이 들어옵니다. 스팀보온/재가열 버튼을 누르시거나 버튼 입력 없이 7초가 지나면 자동으로 절약 보온을 시작합니다. ※...
Page 55
보온 온도 조절 방법 스팀보온/재가열 버튼을 5초 이상 누르면 보온온도 설정모드로 진입합니다. 스팀보온/재가열 버튼을 누르거나 버튼 입력없이 10초가 지나면 보온 온도가 설정됩니다. ※ 보온온도 설정 중 10초 이내에 취소 버튼을 누르면 변경 전의 설정 보온온도로 복귀됩니다. 보온중 스팀보온/재가열 버튼을 눌러 재가열을 시작 합니다.보온...
Page 56
언어, 음성조절 / 자동세척방법 언어, 음성 조절 기능 ※ 취사 중 취소 버튼을 누루면 밥물이 뿜어져 나올 있으므로 취사가 끝난 후 언어 및 음성 조절을 하십시오. ※ 언어 및 음성조절은 반드시 대기 상태에서만 설정 가능합니다. ※ 1 - 한국어, 2 - 영어 ※ 시 버튼을 입력할 때 마다 1 → 2 → 1로 한국어와 영어가 반복...
Page 57
키 백라이트 기능 ※ 본 기능은 평소 밥솥을 사용하고 있지 않을 때 키 부분의 백라이트를 꺼놓는 기능입니다. ※ 백라이트가 꺼진 상태에서 아무 버튼이나 누르게 되면 다시 모든 키의 백라이트가 켜집니다. 이때 누른 버튼의 동작은 하지 않습니다. ※ 예약 취사 및 절약보온 설정시 사용하는 버튼에만 백라이트가 켜져 사용 버튼을 안내해 줍니다. ※...
Page 58
매일 먹는 밥, 리홈으로 맛있게 짓기 오곡밥 잡곡모드에서 취사 ● 재료 : 찹쌀 2컵, 서리태(검정콩)·붉은 팥 ½컵씩, 소금 ½큰술, 차수수+차조+찰기장 합해 1컵, 물+팥 삶은 물 합해 3컵 ● 조리방법 1. 찹쌀, 차조, 찰기장 서리태는 각각 깨끗이 씻어 건진다. 2. 팥은 깨끗이 씻어 냄비에 담고 찬물을 부어 센불에 후루룩 삶아 첫물을 따라버리고 다시 찬물을...
Page 59
대추차 슬로우쿡모드에서 취사 ● 재료 : 6~7인용 대추 180g, 생강, 꿀(설탕) 약간 6~7인용 백미 6인분 눈금 10인용 대추 200g, 생강, 꿀(설탕) 약간 백미 8인분 눈금 10인용 ● 조리방법 1. 내솥에 잘 씻어 찢어놓은 대추와 썰은 생강 약간을 함께 넣고 물을 내솥에 표와 같이 채우고 메뉴를...
Page 60
활성현미 취사를 하지 않았습니까? 활성현미 취사시간은 약 2~3시간 정도 걸립니다. BEAUTY 10 .indd 28 2012-09-18 9:34:13...
