- Page 1 Sunny Mini Central SMC 5000A / 6000A Inverter for three-phase grid feeding PV plants Installation Guide Version 2.0 SMC50A_60A-IEN073320 IME-SMC50A_60A...
-
Page 3: Table Of Contents
Technologie AG Content Notes on this Manual..... . 7 Validity ....... . . 7 Target Group . - Page 4 Content 6.4.2 Connecting the AC Output ......41 6.4.3 The Line Circuit Breaker ......44 The Communication Interface.
- Page 5 Technical Data ......75 14.1 Sunny Mini Central SMC 5000A ....75 14.2 Sunny Mini Central SMC 6000A .
- Page 6 Content Technologie AG Page 6 SMC50A_60A-IEN073320 Installation Guide...
-
Page 7: Notes On This Manual
Technologie AG 1 Notes on this Manual 1.1 Validity This installation guide covers the correct installation and commissioning of type Sunny Mini Central SMC 5000A and SMC 6000A SMA inverters. 1.2 Target Group Only trained electricians approved by the responsible energy supply company may install and commission the inverters. -
Page 8: The Sunny Mini Central
The Sunny Mini Central 2 The Sunny Mini Central 2.1 Appropriate Usage The Sunny Mini Central is a photovoltaic inverter and serves to feed solar energy from solar modules converted using photovoltaics into a low voltage grid with a nominal voltage of 220 to 240 V and 50 Hz or 60 Hz. -
Page 9: Safety Instructions
Technologie AG 3 Safety Instructions 3.1 Handling of the Sunny Mini Central All work on and in the Sunny Mini Central must be carried out by a qualified electrician. The electrician must be approved by the local energy supplier. Open and close the Sunny Mini Central only as described in section 10 "Opening and Closing the Sunny Mini Central"... - Page 10 Safety Instructions Follow the instructions in the pictograms, signs and labels on each inverter and ensure that they are legible at all times. General safety rules for working on photovoltaic systems: Disconnecting the device Before you start to work on the unit, disconnect all wires which could carry voltage to the area you are working on! Protect against reenergizing To prevent the device from being reenergized ensure that you block...
-
Page 11: Installer's Responsibilities
Technologie AG 3.2 Installer's Responsibilities Each person working on an electrical device is responsible for the safety of all persons involved and for the safety of the device. Be sure to observe all standards and regulations applicable to the installation and site. This installation guide, the operating manual and the documentation of installed components must be kept in the immediate vicinity of the inverter and must be available to installation, operation, maintenance and service staff at all times. -
Page 12: Overview Of The Device
Overview of the Device 4 Overview of the Device 4.1 Identification You can identify the Sunny Mini Central with the aid of the name plate (see figure below). The name plate is found on the right-hand side of the housing (when viewed from the front). -
Page 13: Dimensions
Technologie AG Overview of the Device 4.2 Dimensions 242 mm 468 mm 613 mm Installation Guide SMC50A_60A-IEN073320 Page 13... - Page 14 Overview of the Device Wall bracket and rear panel 2,6 2,6 48,7 Page 14 SMC50A_60A-IEN073320 11,0 43,3 Holes for wall bracket Specifications in cm Holes optional single-use screws as anti-theft protection Technologie AG (4 x) Installation Guide...
-
Page 15: Electronic Solar Switch (Ess)
Technologie AG 4.3 Electronic Solar Switch (ESS) The Sunny Mini Central is equipped with the integrated electronic DC load- disconnecting switch ESS. This reliably prevents the arcing that usually occurs when disconnecting the inverter from the PV generator, which can cause personal injury and may damage the inverter connections. -
Page 16: Interior View
Overview of the Device 4.4 Interior View The following diagram gives a schematic overview of the various components and connection points inside the Sunny Mini Central SMC 5000A and SMC 6000A with the cover removed: Page 16 SMC50A_60A-IEN073320 Technologie AG... - Page 17 Technologie AG Varistors (Page 65) Connection terminals for communication (Page 48) Socket for communication Piggy-Back (RS232, RS485, radio) (Page 48) Jumper for communication (Page 48) Sunny Display (Page 54) Jumper for fan testing (Page 69) Operating status LEDs (Page 55) Connection terminals for mains cable (AC) (Page 41) Cable duct for mains cable (AC) (Page 41) Flat connection for grounding the cable shield for RS232 and RS485...
-
Page 18: Installation
Installation 5 Installation 5.1 Selecting an Installation Location Checkpoint Location installation method of installation is suitable for the weight of approximately 63 kg and the dimensions of 468 mm x 613 mm x 242 mm (width x height x depth) of the Sunny Mini Central. - Page 19 Technologie AG Checkpoint If several Sunny Mini Central units are installed in areas where high ambient temperatures are to be expected, the individual Sunny Mini Central units must be far enough apart to ensure that the individual Sunny Mini Central units do not intake the cooling air of the neighboring unit.
- Page 20 Installation Checkpoint Position The Sunny Mini Central is mounted vertically on a wall, or if it is absolutely necessary, tilted back to an angle of max. 45°. The Sunny Mini Central is installed so that it is not slanting forward. The Sunny Mini Central is not installed horizontally.
-
Page 21: Required Tools And Materials
Technologie AG 5.2 Required Tools and Materials Number Tool/material drill with a suitable drill bit 2 - 4 wall anchors with a diameter of 10 mm (for attachment to a concrete or stone wall, for example) 2 - 4 8 mm x 60 mm hexagon bolts to DIN 571 standard, stainless steel type (for attachment to a concrete or stone wall, for example) -
Page 22: Mounting The Sunny Mini Central
Installation 5.3 Mounting the Sunny Mini Central Only use the provided wall bracket for installation! When mounting the device, be sure to take into account the weight of the Sunny Mini Central of 63 kg! Step Instruction Mounting the Wall Bracket For mounting the wall bracket, use two to four of the six holes in the middle. - Page 23 Technologie AG Step Instruction Mounting the Sunny Mini Central When transporting and installing the Sunny Mini Central, use the ergonomic handles at the top and bottom at the sides of the Sunny Mini Central (A), or the housing opening, for example by inserting a steel bar (B) (diameter max.
- Page 24 Installation Step Instruction Close the recessed grips with the handle covers accessories kit. They are required to adequately prevent insects entering the unit! If required, new handle covers can be ordered from SMA (contact: see Page 92). Optional Anti-theft Protection To protect the Sunny Mini Central against theft, the rear face can be secured to the wall at the bottom using...
-
Page 25: Electrical Connection
Technologie AG 6 Electrical Connection 6.1 Required Tools and Materials Number Tool/material PV plug connectors multimeter with DC input voltage range up to at least 600 V hexagon (allen) key (5 mm) cable with external diameter between 11 and 25 mm stripping pliers flathead screwdriver, 1 x 6 mm Phillips screwdriver... -
Page 26: Connection Procedure
Electrical Connection 6.2 Connection Procedure When connecting the unit to the power supply, do not deviate from the sequence described here! The following figure shows the assignment of the individual housing ducts on the base of the Sunny Mini Central. -
Page 27: Connection Of The Dc Input
Technologie AG 6.3 Connection of the DC Input 6.3.1 Requirements For connecting the DC input, the following requirements must be satisfied: The connected strings must consist of modules of the same type and number and should have an identical orientation and tilt. The connecting wires of the solar modules must be equipped with plug connectors to allow the eight DC plug connectors of the Sunny Mini Central to be connected to it. -
Page 28: Connection Of Pv Strings
Electrical Connection 6.3.2 Connection of PV Strings NOTICE! The AC side of the Sunny Mini Central must be disconnected from the grid before you connect the PV strings to the Sunny Mini Central! To connect up the PV strings, follow these steps: Step Instruction Remove the Electronic Solar Switch on the... - Page 29 Technologie AG Step Instruction Connect up the faultless PV generator strings as indicated on the right. Close the unused DC input sockets with the caps included in the delivery. Reinsert the handle of the Electronic Solar Switch in the socket on the underside of the Sunny Mini Central.
-
Page 30: Reverse Current
Electrical Connection 6.3.3 Reverse Current Advice on Generator Configuration for PV Systems Using the Sunny Mini Central In contrast to the Sunny Boy string inverters, three and more strings are usually connected in parallel in the PV generator of a system using the Sunny Mini Central. This does not sound particularly spectacular but it has practical consequences because, in such large generators, certain faults which are totally uncritical in string systems must be allowed for. - Page 31 Technologie AG Electrical Connection Despite the fact that these faults are very unlikely, and extremely rare in practice, preventative measures must still be taken. After all, these types of faults carry a high potential for damage and danger, since all modules in the affected string may be damaged and the local heating may also cause secondary damage.
- Page 32 Electrical Connection Technologie AG How Can Reverse Current in the Modules be Prevented? First we must explain that bypass diodes which are the current state-of-the-art in module construction do not influence the reverse current in the module, but only reduce the effect of any shadowing which may occur.
-
Page 33: Design Notes
Technologie AG Design Notes Check the following points below: Step Test Do all the strings have the same number of series-connected modules? How high is the maximum reverse current in a defective string at nominal conditions? Example: generator with 4 strings of modules at 5 A short-circuit current The maximum reverse current is 3 x 5 A = 15 A. -
Page 34: Connecting The Ac Output
Electrical Connection 6.4 Connecting the AC Output 6.4.1 Requirements For connecting the AC output, the following requirements must be satisfied: Connection Requirements When connecting an inverter to the public grid, follow the connection requirements of the local grid operator! The Sunny Mini Central is designed for operation on 220 V - 240 V grids. Additionally, it is equipped with an automatic grid frequency identifier and can thus be connected to a 50 or 60 Hz system without further parameterization. - Page 35 Technologie AG Grid Impedance Due to a high grid impedance, a high line resistance or a high voltage at the feed- in point, a high AC voltage may result at the connection point of the Sunny Mini Central. In Germany, the 10-minute average of the output voltage (Uac) of the Sunny Mini Central is limited to 253 V according to DIN VDE 0126-1-1.
- Page 36 Electrical Connection The diagram shows the respective curves for a grid voltage without mains supply. A maximum possible feed-in power per phase (X axis) is obtained for the respective curves depending on the grid impedance (Y axis). With three-phase connection and symmetrical feeding, the maximum possible feed-in power per phase is approximately doubled.
- Page 37 Technologie AG Cable Connection The connection terminals in the Sunny Mini Central are suitable for wire cross-sections of up to 25 mm². The external diameter of the cable must therefore be between 11 mm and 25 mm. If you use a cable with a cross-section smaller than 14 mm (11 mm minimum), the rubber bushing in the screw fitting must be replaced by the one included with the inverter at delivery.
- Page 38 Electrical Connection Output losses of the Sunny Mini Central SMC 5000A Do not use cables where losses will exceed 1.0 % The following maximum cable lengths are possible for the different cable cross- sections: Cable cross-section Max. cable length With three-phase connection and symmetrical feeding, there is no load on the neutral conductor, and the line losses are halved.
- Page 39 Technologie AG Output losses of the Sunny Mini Central SMC 6000A Do not use cables where losses will exceed 1.0 % The following maximum cable lengths are possible for the different cable cross- sections: Cable cross-section Max. cable length With three-phase connection and symmetrical feeding, there is no load on the neutral conductor, and the line losses are halved.
- Page 40 Electrical Connection Line Circuit Breaker The selection of the correct line circuit breaker depends on various factors. For detailed information for the rating of a line circuit breaker, please refer to section 6.4.3 "The Line Circuit Breaker" (Page 44). No loads should be connected to this power circuit! A circuit breaker's load disconnecting properties can be utilized to disconnect the inverter from the grid under load.
-
Page 41: Connecting The Ac Output
Technologie AG 6.4.2 Connecting the AC Output To connect up the AC output, follow these steps: Step Instruction Check the grid voltage! For Germany, the following applies: If the grid voltage is constantly higher than 253 V, the Sunny Mini Central will not be fully operational. In this case, contact the local grid operator for assistance. - Page 42 Electrical Connection Step Instruction Connect the protective earth (PE) of the mains cable to the right terminal of the terminal block (see figure to the right). To do this, the PE wire must be 5 mm longer than the L and N wires! If a second protective earth connection is required, you can use the additional connection terminal directly on the Sunny Mini Central's housing for this purpose.
- Page 43 Technologie AG Step Instruction Secure the housing cover by evenly tightening the two middle screws first. Then tighten the four remaining screws as well and do not forget to also reattach the washers. The toothing of the washers must face toward the housing cover.
-
Page 44: The Line Circuit Breaker
Electrical Connection 6.4.3 The Line Circuit Breaker Factors that Determine the Selection Various factors should be taken into account when selecting line circuit breakers. These include, for example: • The type of cable used (conductor material and insulation) • Ambient temperatures affect the cables (higher temperatures result in a reduced maximum current load) •... - Page 45 We assume a PV system with 9 Sunny Mini Central inverters with three inverters per phase. Required technical data of the Sunny Mini Central SMC 5000A / SMC 6000A • Maximum output current = 26 A / 26 A •...
- Page 46 Electrical Connection Example for the thermal selection of a 32 A line circuit breaker with B sensitivity with no gap between the circuit breakers: When selecting line circuit breakers, a number of load factors need to be taken into account. These can be found in the respective manufacturer's data sheets. For example, one manufacturer's circuit breaker may be designed for an ambient temperature of 50 °C.
- Page 47 Technologie AG As well as the thermal rating of the circuit breakers, the applicable DIN VDE standards must also be taken into account. The main ones that apply here are: • DIN VDE 0100, part 410 • DIN VDE 0100, part 430 •...
-
Page 48: The Communication Interface
Whether jumpers need to be mounted, and if so, which jumpers • Whether the cable shield needs to be connected to the PE With the Sunny Mini Central SMC 5000A and SMC 6000A, communication via Powerline is not possible. Page 48... -
Page 49: Connecting Rs232, Rs485, Sunny Beam
Technologie AG 7.1 Connecting RS232, RS485, Sunny Beam Electrostatic discharges are an acute danger to the Sunny Mini Central and to the communications interface. Ground yourself by touching PE or a non-coated part of the housing before removing the communication interface from the packaging, and before touching any components within the Sunny Mini Central. -
Page 50: Jumper Functions
The Communication Interface Housing feed-throughs in the base of the Sunny Mini Central Cable route (gray surface) PE connector Screw terminals for connection of the communication wires Jumper slots Interface port 7.1.1 Jumper Functions RS232 RS485 termination Sunny Beam A detailed description of the jumper functions can be found in the communication device manual. -
Page 51: Commissioning The Sunny Mini Central
Technologie AG 8 Commissioning the Sunny Mini Central Proceed with commissioning the Sunny Mini Central only after: • the housing cover is securely screwed shut, • the DC cables (PV strings) are fully connected and the unused DC plug connectors on the bottom of the housing are closed using the protective caps, •... -
Page 52: Display
Commissioning the Sunny Mini Central 8.1 Display After a normal grid connection of the Sunny Mini Central, it takes approximately one minute until the following display messages are shown alternately. For this, the DC and AC connections must be wired correctly and the circuit breaker must be switched on. The display messages shown before that only have the purpose of indicating the initialization of the Sunny Mini Central and the process of controlling whether the power supply requirements are fulfilled. - Page 53 Technologie AG Display In case of failures E-today 0 Wh Mode Disturbance Disturbance Vac-Bfr 261V present: 245 V Please refer to the operating manual of the Sunny Mini Central to read the exact explanation of the error and status messages! Installation Guide Commissioning the Sunny Mini Central Description...
-
Page 54: Setting The Language Of The Sunny Display
Commissioning the Sunny Mini Central 8.1.1 Setting the Language of the Sunny Display You can set the language of the Sunny Display using the switches on the underside of the display assemblies inside the Sunny Mini Central. Proceed as follows: Open the Sunny Mini Central as described in section 10.2 "Opening of the Sunny Mini Central"... -
Page 55: Leds
The blink codes shown before that only have the purpose of indicating the initialization of the Sunny Mini Central and the process of controlling whether the power supply requirements are fulfilled. -
Page 56: Working Mode
Commissioning the Sunny Mini Central Working Mode In Case of Failures In case the Sunny Mini Central detects an error, this is indicated through a blink code of the yellow and red LEDs. For example, if the yellow LED glows for 5 seconds immediately after connection, then goes out for 3 seconds and then flashes briefly twice, there is a grid fault. -
Page 57: Hand-Over To The Operator
Technologie AG 9 Hand-over to the Operator After installing the Sunny Mini Central successfully, hand the system over to the operator. To do so, please use the following check list. Checkpoint What the operator should know: operating principles of the PV system switching the PV system on and off meaning of the LEDs and display messages maintenance and cleaning (handle covers, LEDs, display,...) -
Page 58: Opening And Closing The Sunny Mini Central
Opening and Closing the Sunny Mini Central 10 Opening and Closing the Sunny Mini Central 10.1 Safety Instructions Follow all safety instructions described in section 3 "Safety Instructions" (Page 9). High voltages are present in the device! Inappropriate opening or closing of the Sunny Mini Central can cause serious material damage or injury to persons which could be fatal. -
Page 59: Opening Of The Sunny Mini Central
Technologie AG 10.2 Opening of the Sunny Mini Central Follow the sequence described below and all safety instructions in section 10.1 "Safety Instructions" (Page 58)! Step Instruction Switch the line circuit breaker to its "off" position, make sure it cannot be switched back on, and test to make sure no voltage is present. -
Page 60: Closing Of The Sunny Mini Central
Opening and Closing the Sunny Mini Central 10.3 Closing of the Sunny Mini Central Follow the sequence described below and all safety instructions in section 10.1 "Safety Instructions" (Page 58)! Step Instruction Secure the housing cover by evenly tightening the two middle screws with the corresponding washers first. - Page 61 Technologie AG Step Instruction Reinsert the handle of the Electronic Solar Switch in the socket on the underside of the Sunny Mini Central. The Electronic Solar Switch can be damaged if it has not been attached properly. The handle must be firmly attached to the Electronic Solar Switch's socket, and rest against the housing.
-
Page 62: Troubleshooting / Problem Solving
Troubleshooting / Problem Solving 11 Troubleshooting / Problem Solving The Sunny Mini Central is a complex high-technology device. As a result, the possibilities for fixing faults on site are limited to just a few items. Should the Sunny Mini Central display other blink codes or display messages than those described in section 8 "Commissioning the Sunny Mini Central"... -
Page 63: The Red Led Is Continuously On
Technologie AG 11.2 The red LED is Continuously on 11.2.1 Ground Fault Testing If the red LED on the Sunny Mini Central is continuously illuminated, it should be checked whether there is a ground fault in the PV generator. Follow the safety instructions in section 10.1 "Safety Instructions" (Page 58) and proceed as follows: Step Instruction... - Page 64 Troubleshooting / Problem Solving Step Instruction Repeat points 3 and 4 for each string. Event You have found a ground fault. You have found no ground fault. Commission the Sunny Mini Central as described in section 10.3 "Closing of the Sunny Mini Central" (Page 60). Check whether the display or the LEDs on the Sunny Mini Central indicate that the device is functioning correctly (see section 8...
-
Page 65: Checking The Varistors
Technologie AG 11.2.2 Checking the Varistors Varistors are wearing parts. Their functioning diminishes with age or following repeated responses as a result of overvoltages. It is therefore possible that one of the thermally monitored varistors has lost its protective function. You can now check these varistors in the following way, paying attention to the safety instructions in section 10.1 "Safety Instructions"... - Page 66 Troubleshooting / Problem Solving Step Instruction Replace the varistor concerned with a new one as shown in the illustration to the right. Ensure the varistor is installed the right way round! If you do not receive a special tool for operating the terminal clamps together with your replacement varistors, please contact SMA.
-
Page 67: Maintenance And Cleaning
Technologie AG 12 Maintenance and Cleaning The Sunny Mini Central has been constructed so that maintenance is kept to a minimum. To guarantee safe operation, it is usually adequate to observe the following principles: • Check the Sunny Mini Central visually for damage approximately every two months. - Page 68 Maintenance and Cleaning Step Instruction Disconnect the Sunny Mini Central from both the DC and AC connections, paying attention to the safety instructions in section 3 "Safety Instructions" (Page 9). Wait for the fans to stop rotating. Push the two latches at the upper edge of the black plastic cover to one side and remove it carefully with the fan guards mounted behind.
-
Page 69: Checking The Fans
Technologie AG 12.1.2 Checking the Fans If necessary, there are two different ways to check the fans are functional: • Set the "Fan Test" parameter to "1" in the installer mode (using Sunny Data, Sunny Data Control, the Sunny Boy Control data logger or Sunny WebBox), or •... - Page 70 Maintenance and Cleaning Step Instruction Setting the Jumper Open the Sunny Mini Central as described in section 10.2 "Opening of the Sunny Mini Central" (Page 59). Place the jumper on the controller board socket, as laid out below. Close the Sunny Mini Central as described in section 10.3 "Closing of the Sunny Mini Central"...
-
Page 71: Cleaning The Handle Covers
Technologie AG 12.1.3 Cleaning the Handle Covers There are handle covers on either side of the Sunny Mini Central. The Sunny Mini Central sucks air in from underneath via the fan and blows it out again on the upper sides. For optimum heat dissipation within the device, you have to clean both handle covers. -
Page 72: Inspection Of The Electronic Solar Switch
Maintenance and Cleaning Technologie AG 12.2 Inspection of the Electronic Solar Switch Check the Electronic Solar Switch for wear before you attach it. To do this, check the metal tongues on the inside of the plug for brown discoloration. Metal tongues If one of the metal tongues is completely burned out (see figure below), then the Electronic Solar Switch can no longer safely disconnect the DC side. -
Page 73: Decommissioning
Technologie AG 13 Decommissioning 13.1 Disassembly You must follow the sequence described below and all safety instructions in sections 3 and 10.1! Step Instruction Open the Sunny Mini Central as described in section 10.2 "Opening of the Sunny Mini Central" (Page 59). Disconnect the AC cable. -
Page 74: Packaging
Decommissioning Step Instruction When transporting the Sunny Mini Central, use the ergonomic handles at the top and bottom at the sides of the Sunny Mini Central (A) or the housing opening, for example, by sliding a steel bar through it (B) (diameter max. -
Page 75: Technical Data
Technologie AG 14 Technical Data 14.1 Sunny Mini Central SMC 5000A Description PV Generator Connection Data Max. input open circuit voltage Input voltage, MPP range Max. input current Max. input power All-pole isolator on the DC input side Overvoltage protection... - Page 76 Technical Data Description Grid Connection Data Nominal output power Peak output power Nominal output current Max. output current Harmonic distortion of output current (at KUgrid < 2 %, PAC > 0.5 PACnom) Short-circuit proofing Nominal operational voltage Operating range, grid voltage (complying with DIN VDE 0126-1-1) Voltage range...
- Page 77 Technologie AG Description Efficiency Max. efficiency CEC rebate efficiency Weight Weight The Sunny Mini Central can temporarily feed power into the grid with a maximum output voltage of 260 V. However, DIN VDE 0126-1-1 stipulates that the average voltage over 10 minutes must not exceed 253 V. That means for example, if the grid voltage is constantly 254 V, the inverter disconnects itself from the grid.
-
Page 78: Sunny Mini Central Smc 6000A
Technical Data 14.2 Sunny Mini Central SMC 6000A Description PV Generator Connection Data Max. input open circuit voltage Input voltage, MPP range Max. input current Max. input power All-pole isolator on the DC input side Overvoltage protection Voltage ripple Personal protection Operating consumption Reverse polarity protection Page 78... - Page 79 Technologie AG Description Grid Connection Data Nominal output power Peak output power Nominal output current Max. output current Harmonic distortion of output current (at KUgrid < 2 %, PAC > 0.5 PACnom) Short-circuit proofing Nominal operational voltage Operating range, grid voltage (complying with DIN VDE 0126-1-1) Voltage range...
- Page 80 Technical Data Description Efficiency Max. efficiency CEC rebate efficiency Weight Weight The Sunny Mini Central can temporarily feed power into the grid with a maximum output voltage of 260 V. However, DIN VDE 0126-1-1 stipulates that the average voltage over 10 minutes must not exceed 253 V. That means for example, if the grid voltage is constantly 254 V, the inverter disconnects itself from the grid.
-
Page 81: General Data
Technologie AG 14.3 General Data General Data Protection rating in accordance with DIN EN 60529 Climatic conditions (DIN EN 50178:1998-04): Location of type C: Transport of type E: Max. operating altitude Fan connections Dimensions (W x H x D) External Interfaces Data transfer via separate data cable Wireless data transmission... -
Page 82: Sunny Mini Central Operating Parameters
Technical Data 14.4 Sunny Mini Central Operating Parameters Unauthorized changes to the operating parameters may result in: • injury or accidents as a result of changing the internal safety specifications of the Sunny Mini Central, • voiding the Sunny Mini Central operating approval certificate, •... - Page 83 Technologie AG Name Explanation Control Current regulation switching. If the operating parameter "Control" is set to "Auto", the inverter automatically chooses the optimal type of current regulation. If the operating parameter "Control" is set to "Grid", the inverter regulates on the grid side. If set to "Bridge", the inverter regulates on the bridge side.
- Page 84 Technical Data Name Explanation Fac-Pderating Frequency-dependent output limitation. Fac-Start delta For setting the frequency-dependent output derating in the operating mode "Off Grid". Further information on this topic can be found in the Sunny Island operating manual. Fac-Tavg Averaging time of grid frequency measurement. Fan-Test By setting the "Fan-Test"...
- Page 85 Technologie AG Name Explanation Ripple-Ctl-Frq The Ripple-Ctl-Frq, Ripple-Ctl-Lev, Ripple-Ctl-Rcvr parameters are intended to handle ripple control signals from the Sunny Mini Ripple-Ctl-Lev Centrals. These parameters are not available for all Sunny Mini Ripple-Ctl-Rcvr Centrals. These parameters may only be changed after prior agreement with SMA Technologie AG.
- Page 86 Technical Data Name Explanation Usoll-Konst PV desired voltage for constant operational voltage. These parameters are only important when the "Betriebsart" parameter is set to U-konst. Page 86 SMC50A_60A-IEN073320 Technologie AG Installation Guide...
-
Page 87: Parameter Settings For Germany
Technologie AG 14.4.2 Parameter Settings for Germany Grayed out parameters are only displayed in installer mode. The table below contains the parameters that are applicable in Germany. Name Short Value range descr. ACVtgRPro 230 ... 300 AntiIsland- 0 ... 10 Ampl * AntiIsland- 0.1 ... - Page 88 Technical Data Name Short Value range descr. LDVtgC 0 ... 50 Pmax 0 ... 6050 P-Wind-Mid 0 ... 6000 P-Wind-Ramp W/s 10 ... 2000 Ripple-Ctl-Frq 105 ... 1605 Ripple-Ctl-Lev % 0.5 ... 8 Ripple-Ctl-Rcvr disable, enable, auto Riso-min kOhm 0 ... 10000 Speicherfkt.
-
Page 89: Country-Specific Parameter Settings
You can see the default settings of the Sunny Mini Central on the name plate (see section 4.1 "Identification" (Page 12)). Sunny Mini Central SMC 5000A The parameters listed below represent country-specific settings and are only displayed in installer mode. All other parameters are international and can be viewed in the table in section 14.4.2. - Page 90 Technical Data Sunny Mini Central SMC 6000A The parameters listed below represent country-specific settings and are only displayed in installer mode. All other parameters are international and can be viewed in the table in section 14.4.2. Name Short descr. Germany ACVtgRPro Default VDE0126-1-1...
-
Page 91: Fixed Parameters
Technologie AG 14.4.4 Fixed Parameters Grayed out parameters are only displayed in installer mode. The following parameters are displayed in the parameter list but cannot be changed: Name Short descr. Fac-Pderating Fac-Tavg Hardware-BFS Plimit SMA-SN Software-BFR Software-SRR Uac-Tavg Installation Guide Default setting SMC 5000A 5500... -
Page 92: Contact
Contact 15 Contact If you have any questions or technical problems concerning the Sunny Mini Central, contact our hotline. Please have the following information available when you contact SMA: • Inverter type • Serial number of the Sunny Mini Central. •... - Page 93 Technologie AG Contact Installation Guide SMC50A_60A-IEN073320 Page 93...
-
Page 94: Exclusion Of Liability
Legal Restrictions Technologie AG The information contained in this document is the property of SMA Technologie AG. Publishing its content, either partially or in full, requires the written permision of SMA Technologie AG. Any internal company copying of the document for the purposes of evaluating the product or its correct implementation is allowed and does not require permission. - Page 96 Sales Solar Technology www.SMA.de SMA Technologie AG Hannoversche Strasse 1–5 34266 Niestetal, Germany Tel. : +49 561 9522 4000 Fax: +49 561 9522 4040 E-mail: sales@SMA.de Freecall: +800 SUNNYBOY Freecall: +800 7 8 6 6 9 2 6 9 Innovation in Systems Technology for the Success of Photovoltaics...
