Typical CABLE/DSL Wireless Router Connections
Up to 4 PCs Connections
With the Auto MDI/MDIX feature, both cross and straight UTP cable can be
utilized.
For More than 4 PCs Connections
To connect to more than 4 computers/notebooks, you may further expand one of the Ethernet
Ports via an Ethernet Hub/Switch. For details on how to connect to the Ethernet Switch/
Hub, please refer to the documentation that comes with the unit.
With the Auto MDI/MDIX feature, both cross and straight UTP cable can be
utilized.
6
Cable/DSL
Cable/DSL
Wireless
modem
Router
Cable/DSL
Cable/DSL
modem
Wireless
Router
Computers or
Notebooks with
Ethernet Network
Cards
Computers or
Notebooks with
Wireless PC Cards
or USB Client
Computers or
Notebooks with
Ethernet Network
Cards, Ethernet
Switches or Hubs
Computers or
Notebooks with
Wireless PC
Cards or USB
Client
