Aztech na8300 Easy Start

Cable/dsl wireless broadband 4-port router
Hide thumbs

Advertisement

Quick Links

Download this manual
Cable/DSL Wireless Broadband
4-Port Router
Easy Start
Version 0.1
•
Product warranty does not apply to damage caused by lightning, power surges or wrong voltage usage.
Contents
Introduction ....................................................... 3
Minimum System Requirements ........................... 3
CABLE/DSL Router Package ................................. 4
CABLE/DSL Router Overview ............................... 4
Typical CABLE/DSL Router Connection .................. 6
Step 1: Connecting the CABLE/DSL Router to Your
Computer/Notebook ............................................ 7
Step 4: Accessing to the Router .......................... 13

Advertisement

loading
Need help?

Need help?

Do you have a question about the na8300 and is the answer not in the manual?

Questions and answers

Related Manuals for Aztech na8300

Summary of Contents for Aztech na8300

  • Page 1: Table Of Contents

    Cable/DSL Wireless Broadband 4-Port Router Easy Start Version 0.1 Contents Introduction ............3 Minimum System Requirements ......3 CABLE/DSL Router Package ......... 4 CABLE/DSL Router Overview ....... 4 Typical CABLE/DSL Router Connection ....6 Step 1: Connecting the CABLE/DSL Router to Your Computer/Notebook ..........
  • Page 2 Part 15 FCC Compliance Statement (FCC ID: I38-NA8300-001) This device complies with Part 15 of FCC Rules. Operation is subject to the following two conditions: This device may not cause harmful interference, and This device must accept any interference received, including interference that may cause undesired operation.

  • Page 3: Introduction

    Easy Start Easy Start Easy Start Easy Start Easy Start Introduction Thank you on your purchase of the Wireless Broadband 4-Port Router! The Wireless 4- Port Router allows you to share high-speed broadband connection with multiple PC using a single device wired or wireless. The Wireless Broadband 4-Port Router can be connected to any computer/notebook with a 10/100 Base-T Ethernet card for wired connection or a IEEE 802.11g Wireless adapter.
  • Page 4 Easy Start Easy Start Easy Start Easy Start Easy Start CABLE/DSL Wireless Router Overview Front Indicators POWER Lights up when power is supplied to the CABLE/DSL Wireless Router. WLAN Lights up when the Wireless LAN connection is established. Lights up when the PPP connection is established. Lights up when the WAN connection is established.
  • Page 5 Easy Start Easy Start Easy Start Easy Start Easy Start Back Indicators POWER SWITCH To power on or off the modem. I - indicates ON position O - indicates OFF position. DC IN To connect to the Power Adapter that comes with your package. RESET To reset your CABLE/DSL Wireless Router to factory default settings.(All customised settings that you have saved will be lost!)Please refer to the below footer...
  • Page 6 Easy Start Easy Start Easy Start Easy Start Easy Start Typical CABLE/DSL Wireless Router Connections Up to 4 PCs Connections Computers or Notebooks with Ethernet Network Cards Computers or Notebooks with Cable/DSL Cable/DSL Wireless PC Cards Wireless modem or USB Client Router With the Auto MDI/MDIX feature, both cross and straight UTP cable can be utilized.

  • Page 7: Cable/Dsl Router Package

    Easy Start Easy Start Easy Start Easy Start Easy Start Step 1: Connecting the CABLE/DSL Wireless Router to Your Computer/Notebook Power off your Computer/Notebook or/and any connected devices before connecting to the ADSL Router! Connecting to the Ethernet Connect your computer(s)/notebook(s) to the CABLE/DSL Wireless Router as illustrated. The following illustration shows the connection of a single computer.

  • Page 8: Computer/Notebook

    Easy Start Easy Start Easy Start Easy Start Easy Start Connecting to the Modem Connect your Modem to the Cable/DSL 4 Port Router as illustrated. Back view of the Back view of the Modem CABLE/DSL Wireless Router Ethernet Network cable Checking Your Connections Please check your connections before proceeding.
  • Page 9 Easy Start Easy Start Easy Start Easy Start Easy Start Connecting to the Power Outlet Back view of the CABLE/DSL Wireless Router Connect the other end of the Power Adapter to the Power Outlet. Powering On Power on the Power Outlet that is connected to your CABLE/DSL Wireless Router. Power on your Computer(s)/Notebook(s).

  • Page 10: Step 2: Configuring Your Ethernet Network Card

    Easy Start Easy Start Easy Start Easy Start Easy Start Step 2: Configuring Your Ethernet Network Card Configuring Your Ethernet Network Card The following illustrated screen shots serve only as examples. For any dissimilarities, please follow closely the instructions prompted on your Computer.
  • Page 11 Easy Start Easy Start Easy Start Easy Start Easy Start For Windows 2000 / Windows ® ® Windows® 2000: From your Windows desktop, right-click on the icon My Network Places select Properties. At the Network and Dial-up Connections window, right-click on the Local Area Connection icon and select Properties.

  • Page 12: Step 3: Configuring Your Internet Browser

    Easy Start Easy Start Easy Start Easy Start Easy Start Step 3: Configuring Your Internet Browser Microsoft® Internet Explorer™ (based on IE 5.5) From your Windows desktop, double-click on your Internet Explorer icon launch your Browser. From the Menu, click Tools and select Internet Options...

  • Page 13: Step 4: Accessing To The Router

    Easy Start Easy Start Easy Start Easy Start Easy Start Step 4: Accessing To The Router From your Internet Browser, key in http://10.0.0.1 at the address bar and hit <Enter>. © Copyright Oct 2003. All Rights Reserved. P/N: 040-511xxx-101 (Ref:NA8300)
