C
ONFIGURING THE
Parameter
ISP Parameters
Username
Password
DHCP Parameters
Function
Default Gateway
Subnet Mask
Name Server 1
Name Server 2
Start IP Address
Number of IP
If the parameters are correct, click "NEXT" to save these settings.
Your Barricade is now set up. Go to "Troubleshooting" on page A-1 if you
cannot make a connection to the Internet.
4-8
B
ARRICADE
Description
The ISP assigned user name.
The password (hidden).
Shows the DHCP function is enabled or disabled.
LAN IP address of the Barricade.
The network subnet mask.
Primary DNS server IP address.
Alternate DNS server IP address.
Start IP address of DHCP assigned IP addresses.
Number of IP addresses available for assignment by the
DHCP server.
