Simplex 4100U Wiring Diagrams page 3

Drawing Index
LT0432 Issue 1.04
Sheet Title
Number
Bases
101 2W Detector Bases - Conventional Detectors
102
TrueAlarm Addressable Detector Bases
Zone Modules
200 8 Zone Module Motherboard (4100-5004)
201
MapNet Monitor ZAM (2190-9156)
202
IDNet Zone Addressable Module (ZAM) (4090-
9101)
203 IDNet Module (4100-3101)
204 VESDA High Level Interface
205 4090-9101 ZAM & "Ex" Detectors
Inputs
300 Addressable Call Point (4099-9032)
301 Supervised IAM (4090-9001, 4090-9051)
302 4-20mA Analog Monitor ZAM (4090-9050)
Outputs
400 IDNet 6 Point I/O Module (4090-9120)
401 MapNet2 Relay Module with Supervised Input
(2190-9173)
402
IDNet Relay IAMs with Inputs (4090-9118, 4090-
9119)
403 MapNet2 Signal ZAM (2190-9162) and
Control ZAM (2190-9164)
404 IDNet Relay ZAM (4090-9002)
405
8 Point Auxiliary Relay Card (4100-3003)
406
6 Point Signal Card (4100-4321)
407
SPS NAC Outputs (4100-9848AU)
408 SPS NAC connection to T-GEN50 tone generator
409 SPS NAC connection to Mini-Gen tone generator
410 SPS NAC connection to Strobe Driver
411 SPS Brigade Relays (4100-6033)
412
IDNet Relay IAMs as Fan Controls
413
24 Point I/O Card (002-124+4100-0302)
414 8 Point Relay Card (4100-3206)
415 4 Point Relay Card (4100-3204)
416 Signal IAM (4090-9007)
Isolators
500 IDNet Addressable Loop Isolator (4090-9116)
501 IDNet Addressable Power Isolator (4090-9117AU)
Communications
600 Transponder Interface Card (4100-0620)
601 Network Interface Card (Wired Media) (4100-6014)
602 Network Interface Card (Fibreoptic) (4100-6014)
603 Fibreoptic Modem - RUI (4100-6063/6064)
604 Fibreoptic Modem - Network (4100-6063/6064)
605
Dual RS232 Card (4100-6038)
606
LCD Annunciator (4604-9201)
Power
700 SPS Power Outputs
701
1948 2A PSU Outputs (ME0417)
703 Remote DC Powered RTU – Loop Power Feed
704 Remote DC Powered RTU – Linear Power Feed
Nyp = not yet published
13 October 2009
Rev.
A
B
A
A
A
B
Nyp
A
nyp
A
nyp
A
A
B
A
A
A
A
A
nyp
A
A
A
B
B
nyp
nyp
nyp
B
A
B
A
nyp
nyp
nyp
nyp
A
B
A
A
A
Page iii
