Page 1 ® Tsunami 800 & 8000 Series (Point-to-point and Point-to-multipoint Products) Software Management Guide Products Covered ® --> Tsunami Multipoint - MP-820-BSU-100 - MP-8100-BSU - MP-8200-BSU; MP-8250-BS9; MP-8250-BS1 - MP-820-SUA-50 - MP-825-SUR-50 - MP-825-CPE-50 - MP-8100-SUA - MP-8150-SUR - MP-8150-SUR-100 - MP-8150-CPE - MP-8200-SUA - MP-8250-SUR - MP-8160-BSU and MP-8160-BS9...
Page 2 Disclaimer Proxim reserves the right to revise this publication and to make changes in content from time-to-time without obligation on the part of Proxim to provide notification of such revision or change. Proxim may make improvements or changes in the product(s) described in this guide at any time.
Page 3 ® Tsunami 800 & 8000 Series - Software Management Guide...
Page 4 ® Tsunami 800 & 8000 Series - Software Management Guide...
Page 5 ® Tsunami 800 & 8000 Series - Software Management Guide...
Page 6 ® Tsunami 800 & 8000 Series - Software Management Guide...
Page 7 ® Tsunami 800 & 8000 Series - Software Management Guide...
Page 8 ® Tsunami 800 & 8000 Series - Software Management Guide...
Page 9 ® Tsunami 800 & 8000 Series - Software Management Guide...
Page 10: About This Guide
Preface Preface This chapter contains information on the following: About this Guide ® This guide gives a jump-start working knowledge of the Tsunami 800 and 8000 products. It explains the step-by-step procedure to configure, manage and monitor the device by using Web Interface. Products Covered Given below are the products that are covered in this guide along with the latest software version supported by each of the device.
Page 11: Related Documents
Network Access Infrastructures and Client-Server Applications. Related Documents Please refer to the following related documents that are available on the Proxim’s support site at Quick Installation Guide (QIG) - A quick reference guide that provides essential information to install and configure the device.
Page 12: Documentation Conventions
Preface Documentation Conventions ScreenShots This guide uses screenshots to explain the method to configure, manage and monitor the device by using Web Interface. Based on your device the screenshots may vary. Hence, we request you to refer to the screenshots that are valid for your device.
Page 13 1.1 About Tsunami 800 and 8000 Products ® Proxim’s Tsunami 800 and 8000 product series, consists of point-to-point and point-to-multipoint devices that are designed to provide wireless networking solutions to enterprises and business markets. This product series consists of the following products:...
Page 14 Overview MP-8250-BS9 The MP-8250 Base Station unit comes with a high power 2x2 MIMO radio and 16 dBi integrated 90° sector antenna that operates in 4.900 – 5.925 GHz frequency band. MP-8250-BS1 The MP-8250 Base Station unit comes with a high power 2x2 MIMO radio and 23 dBi integrated 10°...
Page 15 Overview MP-825-CPE-50 The MP-825 Customer Premises Equipment comes with a 2x2 MIMO radio and 15 dBi integrated dual-polarized panel antenna that operates in 5.15 - 5.925 GHz frequency band with aggregate throughput of 50 Mbps. QB-8100-EPA The QB-8100-EPA QuickBridge operates in 2.3 – 2.5 and 4.9 – 6.0 GHz frequency band.
Page 16 Overview QB-8151-LNK A pair of QB-8151-EPR devices form a link. The QB-8151-EPR device comes with a 2x2 MIMO radio, 21 dBi integrated dual-polarized panel antenna that operates in 4.900 – 5.875 GHz frequency band. It provides a throughput of up to 300 Mbps (Uplink) and 300 Mbps (Downlink).
Page 17 Overview QB-825-LNK-50 A pair of QB-825-EPR-50 devices form a link. ® Tsunami 800 & 8000 Series - Software Management Guide...
Page 18 Internet. Given below are the deployment scenarios, where Proxim's point-to-multipoint devices are recommended. The Proxim devices used in the deployment images are commonly referred to as BSU (Base Station Unit) and SU (Subscriber Unit). The...
Page 19 Overview Last Mile Access: Competitive broadband service access alternative to Digital Subscriber Line (DSL) or cable for residences and T1 or Ethernet for businesses. Security and Surveillance: High definition IP-surveillance cameras for monitoring city streets, airports, bridges, seaports, transportation hubs, offices and warehouses. ®...
Page 20 Overview Metropolitan Area Network: Secure and reliable connectivity between city buildings. Enterprise Campus Connectivity: Extend the main network to remote offices, warehouses or other buildings without leased lines. ® Tsunami 800 & 8000 Series - Software Management Guide...
Page 21 Overview Wireless Intelligent Transport System (ITS): Increases the traffic efficiency and reduces the commuting time in cities and metropolitan areas. Roaming: A mobile device (SU) provides seamless network services. ® Tsunami 800 & 8000 Series - Software Management Guide...
Page 22: Point-To-Point Link
Overview Offshore Communications: Establishes connectivity between seashore and the ships that are nearing the port locations, or connectivity between off-shore oil rigs and sea shore and so on. 1.2.2 Point-to-Point Link A point-to-point link is a dedicated wireless link that connects only two stations. With a point-to-point link, you can set up a connection between two locations as an alternative to: Leased lines in building-to-building connections Wired Ethernet backbones between wireless access points in difficult-to-wire environments.
Page 23 Overview Given below are the deployment scenarios, where Proxim's point-to-point devices are recommended. The proxim devices used in the deployment images are commonly referred to as End Point A and End Point B. The combinations that are used for point-to-point devices are:...
Page 24 Overview Repeater: Extends distance or overcomes path blockage by adding point-to-point hops. High-bandwidth Last Mile Access: Delivers Transparent LAN Services (TLS) to corporate parks. High Availability and Link Aggregation: Achieves high availability and link aggregation in wireless medium by using two parallel links and additional Link Aggregation Control Protocol (LACP) capable switches. This is applicable only to QB-8100-EPA/LNK, QB-8150-EPR/LNK, QB-8150-LNK-100, QB-8151-EPR/LNK, QB-8200-EPA/LNK, and QB-8250-EPR/LNK devices.
Page 25: Multiple-Input-Multiple-Output (Mimo)
The underlying technology of Proxim’s product radio(s) are based on a combination of MIMO and OFDM (Orthogonal Frequency Division Multiplexing). MIMO-OFDM combination radios solve interference, fading and multipath problems On the receiver side, having multiple receivers increases the amount of received power and also reduces multipath problems by combining the received signals for each frequency component separately.
Page 26 Overview Quality of Service: WORP ensures that the most important data arrives with priority by differentiating between priorities of traffic as defined in the profiles for QoS (Quality of Service), similar to the 802.16 WiMAX QoS standard definition. Bandwidth Control: WORP allows service providers to control network bandwidth by throttling outgoing traffic in both base station and subscriber devices, thus protecting the network from excessive bandwidth use by any one station.
Page 27: Management And Monitoring Capabilities
Management and Monitoring Capabilities A Network administrator can use the following interfaces to configure, manage and monitor the device. 2.1 Web (HTTP/HTTPS) Interface The Web interface (HTTP) provides easy access to configuration settings and network statistics from any computer on the network.
Page 28: Secure Shell (Ssh)
Management and Monitoring Capabilities If using RS-232 cable, verify the following information in the HyperTerminal serial port setup: Port COM1 (default) Baud Rate 115200 Data 8-bit Parity None Stop 1-bit Flow Content None : When using Windows 7, use a Terminal Emulator program like Teraterm Pro for serial connection. 2.2.2 Telnet The device can be accessed through CLI by using Telnet.
Page 29 Microsoft Word, Notepad, or WordPad. 2.4 ProximVision NMS ProximVision NMS is the state-of-the-art network management system to administer Proxim’s devices on the network. ProximVision NMS offers the following network management and monitoring features: Network Management --> Network Discovery, Geographical and Logical Maps Fault Management -->...
Page 30: Device Initialization
SNMP Interface. : For installation procedure, please refer to the Hardware Installation Guide available on the Proxim’s support site at To access the device by using CLI commands, connect a serial RS-232 cable to the Serial port of the device.
Page 31 3. If there are more than one network adapter installed on the computer, then the user will be prompted to select the adapter for scanning Proxim devices. Use either an Ethernet or a Wireless Adapter. Select an adapter and click OK. The following Scan List screen appears, which displays all devices that are connected to the selected adapter.
Page 32 Device Initialization This screen contains the following device information: MAC Address System Name IP Address Uptime System Description: The system description comprises the following information: — Device Description: For example, MP-820-BSU-100-WD — Firmware Version: 2.X.Y; For example, version 2.6.2 — Serial Number : For example, SN-12PI06000034 —...
Page 33: Logging On To The Web Interface
Device Initialization Figure 3-4 Modifying Device’s IP Address (IPv6) 1. Select the IP Address Type as static/dynamic for IPv4 and as static/dynamic/auto for IPv6 Static: When set to static, the IP address of the device can be manually changed. Dynamic: When set to dynamic, the IP address is dynamically generated by the DHCP server. Auto: When set to auto, the IPv6 address is calculated by the device using the router advertisement messages.
Page 34 Device Initialization Figure 3-5 Login Screen Based on the access credentials, two types of users can access the device. They are, 1. Administrator User: The Administrator user administers the entire device. This user type has the write access to all the features of the device and also has the privilege to change his or her own password and that of the Monitor user (the other user type).
Page 35: Home Page
Device Initialization In the Internet Explorer, to get best results, click on Tools > Internet Options > General. Click Settings in the Browsing History and select “Every visit to the webpage”. 3.2.1 Home Page Upon successful logon, the device home page appears. Figure 3-6 Home Page The home page contains the following information: Device Description: The device description is displayed on the top-right corner of the home page.
Page 36 Device Initialization 3.2.2 COMMIT COMMIT operation is used to apply the configuration changes onto the device. When changes are made to the configuration parameters of the device, the changes will not take effect, until COMMIT is clicked. Some parameters may require system reboot for the changes to take effect.
Page 37: Factory Default Configuration
Device Initialization 3.2.3 REBOOT Reboot operation is required for any change in the key parameters to take effect. For example, settings such as configuring the Radio Mode, IP Address, Network Mode and so on, require device reboot for the changes to take effect. It is recommended that the device must be rebooted immediately after modifying a rebootable parameter.
Page 38 Device Initialization Parameter BSU Mode/ SU Mode/ End Point A End Point B Maximum Number of SUs (per BSU) MP-8100-BSU (rev 1 to rev 6) --> 100 Not Applicable MP-8100-BSU (rev 7 and above) --> 250 MP-8160-BSU --> 250 MP-8160-BS9 --> 250 MP-8200-BSU -->...
Page 39 Device Initialization Parameter BSU Mode/ SU Mode/ End Point A End Point B IGMP Snooping Disabled Disabled Disabled Disabled Disabled Disabled PPPoE Client Not Applicable Disabled in SU Mode Not Applicable in End Point B HTTP Management Interface Enabled Enabled Telnet Management Interface Enabled Enabled...
Page 40: Basic Configuration
Basic Configuration The BASIC CONFIGURATION tab provides a one-place access to a minimum set of configuration parameters to quickly set up a Point-to-point or Point-to-multipoint network. To configure basic parameters of the device, click BASIC CONFIGURATION tab. The following screen appears: Figure 4-1 Basic Configuration (BSU) ®...
Page 41 Basic Configuration Figure 4-2 Basic Configuration (SU) ® Tsunami 800 & 8000 Series - Software Management Guide...
Page 42 Basic Configuration Figure 4-3 Basic Configuration (End Point A) ® Tsunami 800 & 8000 Series - Software Management Guide...
Page 43 Basic Configuration Figure 4-4 Basic Configuration (End Point B) Below is the table which explains basic parameters and the method to configure the configurable parameter(s): : Recommended characters for the name field are A-Z a-z 0-9 - _ =: . @ $ & and space. Parameter Description System Name...
Page 44 Basic Configuration Parameter Description Frequency Domain This parameter specifies the country of operation, permitted frequency bands and regulatory rules for a particular country or domain. When the frequency domain is selected, the Dynamic Frequency Selection (DFS) and Automatic Transmit Power Control (ATPC) features are enabled automatically if the selected country and band has a regulatory domain that requires it.
Page 45 Basic Configuration Parameter Description Auto Channel Enables a device to select the best channel for data transmission on the wireless medium, Selection (ACS) with less interference. By default, ACS is disabled on a BSU/End Point A and enabled on an SU/End Point B device.
Page 46 Basic Configuration Parameter Description Legacy Mode By default, this parameter is disabled. When enabled, the MP 800 & 8000 BSU and SU ® devices can interoperate with the legacy products of the Tsunami MP.11 family. The MP 800 & 8000 devices that provide legacy support are, MP-8100-BSU MP-8100-SUA MP-8150-SUR...
Page 47: Advanced Configuration
Advanced Configuration The ADVANCED CONFIGURATION tab provides a means to configure the following advanced features of the device: : Recommended characters for the name field are A-Z a-z 0-9 - _ = : . @ $ & and space. ® Tsunami 800 &...
Page 48 Advanced Configuration 5.1 System The System tab enables to configure system specific information. To configure system specific parameters, navigate to ADVANCED CONFIGURATION > System. The System screen appears: Figure 5-1 System Configuration Given below is the table which explains System parameters and the method to configure the configurable parameter(s): Parameter Description Radio Mode...
Page 49 Advanced Configuration Parameter Description Active Network Mode A change in the network mode (either Bridge or Routing mode) is applied on the device only when the device is rebooted. So, when the network mode is changed and the device is not rebooted, this parameter displays the current operating network mode of the device.
Page 50 Advanced Configuration Parameter Description Maximum MTU Given below are the devices and their corresponding MTU configurable range: (Maximum Transmission Unit) Devices MTU Configurable Range MP-8150-CPE; MP-8160-CPE-A100 1500 to 2048 bytes MP-820-BSU-100; MP-820-SUA-50 MP-825-CPE-50; MP-825-SUR-50 QB-8150-LNK-12/50; QB-825-EPR/LNK-50 QB-825-EPR/LNK-50 MP-8100-BSU; MP-8100-SUA 1500 to 1514 bytes MP-8150-SUR;...
Page 51 Advanced Configuration Parameter Description LED Status The Received Signal Strength Indicator (RSSI) LEDs indicates that the unit is powered on, and LEDs will glow based on RSSI value indicating link status. By default, all 5 LEDs will blink at an interval of 1 sec. When the LED Status is disabled, all LEDs will be turned off. : 'RSSI LED' feature is applicable only to 82x MP and QB devices.
Page 52 Advanced Configuration : IPv6 address is supported only in bridge mode. 5.2.1.1 Bridge Mode 5.2.1.1.1 IP Configuration (IPv4 Only) To configure the IP parameters of the device when operating in Bridge mode, navigate to ADVANCED CONFIGURATION > Network > IP Configuration. The following IP Configuration screen appears: Figure 5-4 IPv4 Configuration (Bridge Mode) Given below is the table which explains the method to configure IP parameters in Bridge mode: Parameter...
Page 53 Advanced Configuration Parameter Description Address Type Specifies whether the Ethernet interface parameters are to be configured through Dynamic Host Configuration Protocol (DHCP) or to be assigned statically. By default, the address type is set to Static meaning which the user can manually configure the network parameters.
Page 54 Advanced Configuration Figure 5-5 IPv6 Configuration (Bridge Mode) Given below is the table which explains the method to configure IP parameters in Bridge mode: Parameter Description IP Mode Represents the IP Mode of the device. The IP Mode can be set to either IPv4 Only or Dual (IPv4 and IPv6).
Page 55 Advanced Configuration Parameter Description Address Type Specifies whether the Ethernet interface parameters are to be configured through Dynamic Host Configuration Protocol (DHCP) or Stateless Auto Configuration or to be assigned statically. Select Auto (default address type) to configure the device automatically. If Auto is selected, device obtains the IPv6 address, using the prefix obtained from the router advertisement.
Page 56 Advanced Configuration Figure 5-6 DNS Configuration (Bridge Mode) Parameter Description Primary and Represents the IP address of the Primary and Secondary DNS Server. Secondary IP Address Primary and Secondary IP Address can be configured manually irrespective of the IP mode. The DNS address obtained from the DHCP server (Dynamic mode) or from the router advertisement (Auto Mode) is given preference over the manually configured IP Addresses.
Page 57 Advanced Configuration Figure 5-7 IP Configuration (Routing Mode) Given below is the table which explains the method to configure IP parameters in Routing mode: Parameter Description Ethernet (Please note that the number of Ethernet interfaces depend on your device.) IP Address Represents the IP address of the Ethernet interface.
Page 58 Advanced Configuration Parameter Description Subnet Mask Represents the subnet mask of the wireless interface. By default, the static subnet mask is set to 255.255.255.0. You can manually change the subnet mask. Default Gateway IP Address IP Address Represents the gateway IP address of the device. By default, the Gateway IP address is set to 169.254.128.132.
Page 59 Advanced Configuration Parameter Description Primary IP Address Represents the IP Address of the Primary DNS Server. Secondary IP Address Represents the IP Address of the Secondary DNS Server. : In routing mode, the Primary and Secondary IP Address cannot be configured as IPv6 addresses. After configuring the required parameters, click OK, COMMIT and then REBOOT.
Page 60 Advanced Configuration Figure 5-9 IP Configuration (Routing Mode with PPPoE Client Enabled) Given below is the table which explains the method to configure IP parameters in Routing mode with PPPoE client enabled: Parameter Description Ethernet (Please note that the number of Ethernet interfaces depend on your device.) IP Address Represents the IP address of the Ethernet interface.
Page 61 Advanced Configuration Parameter Description Wireless (PPPoE) Address Type This parameter specifies whether the wireless interface parameters are to be configured through PPPoE server or to be assigned statically. By default, the address type is set to PPPoE-ipcp meaning which the PPPoE client obtains the IP parameters from a network PPPoE server automatically during the bootup.
Page 62 Advanced Configuration Parameter Description Default Gateway IP Address IP Address Represents the gateway IP address of the device. When the address type is set to PPPoE-ipcp, this parameter is read-only and displays the PPPoE client’s gateway IP address (which is nothing but the IP address of the PPPoE server). If it cannot obtain the IP address from a PPPoE server, then there will be no gateway for the device.
Page 63: Static Route Table
Advanced Configuration Parameter Description Primary and Represents the IP address of the Primary and Secondary DNS Server. Secondary IP Address Primary and Secondary IP address can be configured manually. The DNS address obtained from the PPPoE-ipcp is given preference over manually configured IP addresses. After configuring the required parameters, click OK, COMMIT and then REBOOT.
Page 64: Network Address Translation (Nat)
Advanced Configuration 5.2.2.1 Adding Static Route Entries Click Add in the Static Route Table screen.The following Static Route Table Add Row screen appears: Figure 5-12 Static Route Table Add Row Add the route entries and click Add and then COMMIT. You can add a maximum of 256 routes to the static route table.
Page 65 Advanced Configuration When NAT is enabled, the network on the wireless side of the device is considered public and the network on the Ethernet side is considered private. When NAT functionality is enabled, the DHCP Relay and RIP features are not supported. The DHCP Relay Agent and RIP must be disabled before enabling NAT.
Page 66 Advanced Configuration To enable Dynamic NAT, set the NAT Status to Enable. To enable Static NAT, set the NAT Status to Enable and the Port Forwarding Status to Enable. NAT uses the IP address of the wireless interface as the Public IP address. To add entries in the NAT Port Bind Table, navigate to ADVANCED CONFIGURATION >...
Page 67 Advanced Configuration 5.2.3.1 Supported Session Protocols Certain applications require an Application Level Gateway (ALG) to provide the required transparency for an application running on a host in a private network to connect to its counterpart running on a host in the public network. An ALG may interact with NAT to set up state information, use NAT state information, modify application-specific payload, and perform the tasks necessary to get the application running across address realms.
Page 68 Advanced Configuration Figure 5-15 RIP By default, RIP is not enabled on the device. To enabled, select Enable and click OK. The RIP screen is updated with the following tabulated parameters:. Parameter Description Name Displays the interface type as either Ethernet 1, Ethernet 2, or Wireless. Status Enables you to either enable or disable RIP for a particular network interface.
Page 69 PPP frames over Ethernet. This feature is commonly used by Internet Service Providers (ISPs) to establish a Digital Subscriber Line (DSL) Internet service connection with clients. The Proxim’s SU devices support PPPoE only when they are configured in Routing Mode with NAT enabled. Also, the BSU should always operate in Bridge Mode.
Page 70 Advanced Configuration Echo Interval and Echo Failure to detect server unavailability MPPE with stateful and stateless mode aligned with 40/56/128 bit encryption To configure PPPoE feature, 1. Navigate to ADVANCED CONFIGURATION > Network > PPPoE > PPPoE Client. The following PPPoE Client screen appears: Figure 5-17 PPPoE Client Status 2.
Page 71 Advanced Configuration 5. Given below is the table which explains PPPoE client parameters and the method to configure the configurable parameter(s): Parameter Description Authentication PPPoE supports the following types of user authentication protocols that provide Protocol varying levels of security: None: Represents that no authentication is required for transferring PPP frames over Ethernet between PPPoE client and server.
Page 72 Advanced Configuration Parameter Description LCP Echo Failure This parameter indicates the maximum number of consecutive failures to receive the LCP echo-reply to consider the connection to be down. To configure LCP Echo Failure value, enter a a value ranging from 1 to 25. By default, the echo failure is set to 5.
Page 73 Advanced Configuration Parameter Description MPPE Status : MPPE Status parameter is applicable only when the Authentication Protocol is configured as “MSCHAP v2”. Microsoft Point-to-Point Encryption (MPPE) is a protocol for transferring encrypted data over point-to-point links. The PPPoE client negotiates on the encryption parameters based on the MPPE Status configured.
Page 74 5.2.6 IP over IP Tunneling : Applicable only in Routing Mode. Proxim’s point-to-multipoint and point-to-point devices support IP Tunneling, which serves as a communication channel between two disjoint IP networks that do not have a native routing path to communicate with each other.
Page 75 Advanced Configuration The following figure shows an IP tunnel configuration using two end points. Figure 5-19 An Example: Tunnel Configuration Lets say that the Computer with an IP address: 10.0.0.1 wants to communicate with the Computer with an IPA address: 192.168.9.101.
Page 76 Advanced Configuration By following the steps below, the tunnel is automatically established. 1. Create a tunnel (Refer to To create a tunnel as given in , do the following: SU1 Configuration — Virtual IP Address = 50.0.0.1 — Local IP Address = 20.0.0.132 —...
Page 77 Advanced Configuration 5. Click Add, to create a new tunnel interface. The following Tunneling Table Add Row screen appears: Figure 5-22 Adding a new Tunnel Interface 6. Given below is the table which explains the parameters for creating a new tunnel: Parameter Description Name...
Page 78: Basic Ethernet Configuration
Advanced Configuration You can create a maximum of 16 tunnels. The Maximum Transmission Unit (MTU) of the tunnel interface depends on the underlying interface. It is advised that both PPPoE and the IP Tunneling feature do not function simultaneously on the device. IP configuration of Ethernet and Wireless interface should NOT be in the same subnet of virtual IP addresses of tunnels.
Page 79 Advanced Configuration Given below is the table which explains Basic Ethernet parameters and the method to configure the configurable parameter(s): Parameter Description MAC Address Displays the MAC address of the Ethernet interface. Operational Speed Displays the current operational speed of the Ethernet interface. Given below is the maximum operational speed of the Ethernet interface product wise: Product (s) Maximum Speed...
Page 80 Advanced Configuration Parameter Description Operational Tx Mode Displays the current operational transmission mode of the Ethernet interface. It supports two types of transmission modes: Half Duplex: Allows one-way data transmission at a time. Full Duplex: Allows two-way transmission simultaneously. Speed And TxMode Enables the user to select the speed and transmission mode of the Ethernet interface.
Page 81 Advanced Configuration Figure 5-25 Advanced Ethernet Configuration Given below is the table which explains Advanced Ethernet parameters and the method to configure the configurable parameter(s): Parameter Description Auto Shutdown This parameter facilitates LACP capable Ethernet switches to use two or more QuickBridge links to achieve higher throughput and redundancy.
Page 82 Advanced Configuration 5.4.1 Link Profiles The Link Profiles feature enables you to create wireless profiles on a per link basis. These link profiles help to determine the wireless transmission properties (Tx data rate, TPC, Tx antenna ports) of a WORP link. On an SU, it determines the transmission properties of all the transmitted packets.
Page 83 Advanced Configuration The default profile can be modified to suit the network requirements. However, it is possible that one profile may not be able to satisfy the requirements of all the WORP links (due to different operating conditions, link distance etc). In such a case, additional link profiles can be defined and associated with respective links appropriately (refer on how to associate profile to a link).
Page 84 Advanced Configuration Figure 5-28 Edit a Link Profile (Basic) 5.4.1.2.1 Basic Under Basic screen, you can configure and view the following parameters. Parameter Description Profile Name Represents the link profile name whose wireless parameters are edited. Enter a new name, if you wish to edit the existing profile name.
Page 85 Advanced Configuration Parameter Description Data Streams Select the data stream as either Auto, Single or Dual. Dual Stream: Select Dual, for higher throughput. Single Stream: Select Single, for reliability and longer range. Auto Stream: When configured to Auto, DDRS decides the stream modes based on the environment conditions.
Page 86 Advanced Configuration Parameter Description This parameter enables you to manually set the Transmit Power Control (TPC) value when ATPC is disabled. You can manually set TPC ranging from 0 to 25 dBm. : In case of 82x devices, you can manually set TPC ranging from 0 to 15 dBm. With TPC, you can adjust the output power of the device to a lower level.
Page 87 Advanced Configuration Figure 5-29 Edit a Link Profile (Advanced) Parameter Description DDRS Min Data Rate Represents the minimum and maximum data rate for DDRS to dynamically select the transmission data rate. These will vary depending on the configured data stream. DDRS Max Data Rate DDRS Lower SNR Represents the margin value to be added to the minimum required SNR, for the purpose...
Page 88 Advanced Configuration Parameter Description DDRS Rate Incr RTX Represents a threshold for the percentage of retransmissions, below which the rate can be Threshold increased. By default, it is set to 25%. : If the percentage of retransmissions is between “Rate Increment RTX Threshold” and “Rate Decrement RTX Threshold”...
Page 89 Advanced Configuration Parameter Description ATPC Upper Margin SNR Upper Limit = Maximum Optimal SNR and Lower Margin SNR Initial = SNR Upper Limit – ATPC Upper Margin SNR Lower Limit = SNR Initial – ATPC Lower Margin ATPC Algorithm, after reducing the power to honor the Maximum EIPR limit, adjusts the power based on Maximum Optimal SNR, ATPC Upper Margin and ATPC Lower Margin.
Page 90 After configuring the required parameters, click OK and then COMMIT. 5.4.2 Wireless Outdoor Router Protocol (WORP) WORP is protocol, designed by Proxim that protects the network from packet collisions and solves the hidden node problem to transmit the data in an optimal way.
Page 91 Advanced Configuration Figure 5-32 WORP Configuration (SU) Given below is the table which explains WORP parameters and the method to configure the configurable parameter(s): Parameter Description Mode Represents the device type (BSU, SU, End Point A or End Point B). Primary BSU Name Applicable only to an SU.
Page 92 Advanced Configuration Parameter Description Secondary BSU Name This parameter serves as a Secondary / Redundant BSU for the SU and helps in reducing the network outage in the case of Primary BSU failure. This feature can help in reducing the network outage in case of the Primary BSU failure. This feature enables the SU to keep track of the Primary and the Secondary BSU availability through a proprietary protocol.
Page 93 Advanced Configuration Parameter Description Max SUs Represents the maximum number of SUs that can register with a BSU. Given below are the base stations and the maximum number of subscribers supported by each of them: Base Station Maximum Number of Subscribers MP-8100-BSU (rev 1 to rev 6) MP-8100-BSU (rev 7 and above) MP-8160-BSU...
Page 94 Advanced Configuration Parameter Description Multi Frame Bursting To achieve higher throughput, WORP protocol allows the transmitter or receiver to send multiple data frames in sequence without waiting for acknowledgment for every data frame and treats it as a single burst. During the burst transmission, the receiver is not allowed to interrupt the transmitter.
Page 95 Advanced Configuration Parameter Description Security Profile Name The Security Profile Name represents the encryption method used to encrypt the data over the wireless medium. The default configured Security Profile Name is WORP Security. See Radius Profile Name The Radius Profile Name, containing the IP address of the RADIUS server, is used to authenticate an SU or an End Point B.
Page 96: Wireless Interface Properties
Advanced Configuration Modifying any of the WORP parameters result in temporary loss of connectivity between the transmitter and receiver. MAC ACL Status and RADIUS MAC ACL Status parameters cannot be enabled simultaneously. 5.4.3 Wireless Interface Properties To configure the wireless interface properties, navigate to ADVANCED CONFIGURATION > Wireless > Interface 1 > Properties.
Page 97 Advanced Configuration Figure 5-34 Wireless Interface Properties (SU) The Wireless Interface Properties screen is classified under two categories: Properties and MIMO. 5.4.3.0.1 Properties Under Properties screen, you can configure and view the following parameters. Parameter Descriptions Channel Bandwidth By default, the channel bandwidth is set to 20 MHz. 40 MHz can be selected for higher throughputs depending on the distance and signal quality.
Page 98 Advanced Configuration Parameter Descriptions Channel Offset : Applicable only to MP-8160-BSU; MP-8160-BS9; MP-8160-SUA; MP-8150-CPE; MP-8160-CPE-A100; MP-825-CPE-50; MP-820-BSU-100; MP-820-SUA-50 MP-825-SUR-50 ; QB-825-EPR/LNK-50 ; QB-825-EPR/LNK-50; QB-8150-LNK-12/50 devices. The Channel Offset parameter helps to change the operating channel center frequency. If the predefined center frequencies are not desirable, user can shift the center frequency to suit the requirement by configuring the Channel Offset.
Page 99 Advanced Configuration Parameter Descriptions Satellite Density Satellite Density setting helps to achieve maximum bandwidth in a wireless network. It influences the receive sensitivity of the radio interface and improves operation in environments with high noise level. Reducing the sensitivity of the device enables unwanted “noise”...
Page 100 Advanced Configuration Parameter Descriptions Max EIRP The maximum effective power that a radio antenna is allowed to radiate as per the regulatory standard. By default, the maximum EIRP is set as per the regulatory requirements for each frequency domain. Given below are the default maximum EIRP values that are set according to regulatory domain: Regulatory Frequency...
Page 101 Advanced Configuration Parameter Descriptions Regulatory Frequency Max EIRP (dBm) Domain (MHz) PTP Mode PTMP Mode India 5825 – 5875 Brazil 5470 – 5725 5725 – 5850 Unlimited (100) 32 + 2/3(antenna gain) Australia 5470 – 5600 30 (20 and 40 MHz) 30 (20 and 40 MHz) 27 (10 MHz) 27 (10 MHz)
Page 102 Advanced Configuration Parameter Descriptions Antenna Gain When using external antenna, the professional installer should ensure to configure proper antenna gain so that the radio does not exceed the EIRP allowed per regulatory domain. Calculate the antenna gain as follows: Antenna Gain to be configured = Antenna Gain of the antenna used - Cable Loss Example: Consider an example where the device is operating in United States 5.3 GHz with the EIRP 30 dBm.
Page 103 Advanced Configuration Parameter Descriptions Improper configuration of Antenna Gain will affect the sensitivity of the radio card. As the radar detection threshold is fixed by ETSI, the FCC and IC, any change in sensitivity of the radio card will result in false radar detections or actual radar signal not being detected. If the configured antenna gain is higher than the actual antenna gain, Radar signals may go undetected.
Page 104 Advanced Configuration Parameter Descriptions Legacy Mode By default, Legacy Mode is disabled. When enabled, the MP 800 & 8000 BSU and SU ® devices can interoperate with the legacy products of the Tsunami MP.11 family. The MP 800 & 8000 devices that provide legacy support are, MP-8100-BSU MP-8100-SUA MP-8150-SUR...
Page 105 Advanced Configuration Figure 5-35 MIMO Parameter Description Frequency Extension Frequency Extension is applicable only when the Channel Bandwidth is set to 40 MHz. While choosing 40MHz bandwidth, you can select either 40 PLUS (Upper Extension Channel) or 40 MINUS (Lower Extension Channel). 40 PLUS means the center frequency calculation is done for 20MHz and add another 20MHz to the top edge of 20MHz.
Page 106 Advanced Configuration 5.4.4 Dynamic Frequency Selection (DFS) / Dynamic Channel Selection (DCS) 5.4.4.1 Dynamic Frequency Selection (DFS): ® The Tsunami products support Dynamic Frequency Selection (DFS) for FCC, IC, and ETSI regulatory domains per FCC Part 15 Rules for U-NII devices, IC RSS-210, and ETSI EN 301-893 regulations, respectively. These rules and regulations require that the devices operating in the 5 GHz band must use DFS to prevent interference with RADAR systems.
Page 107 Advanced Configuration 5.4.4.1.2 DFS in SU or End Point B Mode Explained below is the DFS functionality and the way it operates on an SU or a End Point B. 1. When SU/End Point B has no WORP link, it scans continuously all the channels in the configured Frequency Domain for the presence of BSU/End Point A.
Page 108 Advanced Configuration — If the link quality is bad, the channel is blacklisted for 30 minutes. ACS will scan all the non-blacklisted channels and selects the channel with good link quality (least interference). — If the link quality is above the threshold, the device continues to operate in the same channel. Periodically, the device monitors the current operating channel for link quality.
Page 109 Advanced Configuration Figure 5-36 DFS Configuration (BSU Mode) ® Tsunami 800 & 8000 Series - Software Management Guide...
Page 110 Advanced Configuration Figure 5-37 DFS Configuration (SU/End Point B Mode) Given below is the table which explains DFS parameters and the method to configure the configurable parameter(s): Parameter Description Dynamic Frequency Selection Channel Wait Time Once the device selects the best channel, it scans that channel for the presence of RADAR for a period of set Channel Wait Time.
Page 111 Advanced Configuration Parameter Description Retransmission This parameter enables to configure the retransmission threshold percentage on the Threshold device. The device computes percentage of retransmission for each link and compares with the configured threshold. If the retransmission percentage is greater than the user configured retransmission threshold, the link is considered as bad link.
Page 112 Advanced Configuration 5.4.4.4 Manual Blacklist This tab enables you to manually blacklist a channel. However, there are few conditions to be followed while blacklisting channels: When ACS is disabled, the preferred channel and its sub-channels that are part of the current channel bandwidth cannot be manually blacklisted.
Page 113 Advanced Configuration : Roaming feature is applicable only to the point-to-multipoint devices but not applicable in legacy mode. 5.4.5.1 Definition(s) Roaming Preferred Channels: A list of channels maintained by a BSU where its neighbour BSUs are operating. Roaming Channel List (RCL): A list of channels that are learnt from the associated BSU (known as Roaming Preferred Channels), and are not blacklisted locally on the SU.
Page 114 Advanced Configuration 5.4.5.3 Configurable Parameters on a BSU To configure the roaming parameters on a BSU, navigate to ADVANCED CONFIGURATION > Wireless > Interface 1 > Roaming. The Roaming Configuration screen appears: Figure 5-39 BSU Roaming Configuration Below is the table which explains roaming parameters for a BSU, and the method to configure the configurable parameter(s): Parameter Description Roaming Status...
Page 115 Advanced Configuration Parameter Description Roaming Link Profile This parameter enables you to configure a roaming link profile for the roaming enabled SUs. When roaming is enabled on the BSU, select a profile from the configured link profiles, which serves as the roaming profile. The Default profile serves as the roaming profile when no profile is selected.
Page 116 Advanced Configuration Parameter Description Roaming Preferred Each BSU on the network, maintains a list of channels where its neighbour BSUs are operating. Channels When roaming is enabled, SU learns this list from the current BSU and uses it as Roaming Channel List (RCL), to reduce scanning time while searching for a BSU with better Rx SNR.
Page 117 Advanced Configuration 5.4.5.4 Configurable Parameters on an SU To configure the roaming parameters on an SU, navigate to ADVANCED CONFIGURATION > Wireless > Interface 1 > Roaming. The Roaming Configuration screen appears: Figure 5-42 SU Roaming Configuration Below is the table which explains roaming parameters for an SU, and the method to configure the configurable parameter(s): Parameter Description Roaming Status...
Page 118 Advanced Configuration Parameter Description Roaming Link Profile This parameter enables you to configure a roaming link profile for the roaming enabled BSU. When roaming is enabled on the SU, select a profile from the configured link profiles, which serves as the roaming profile. The Default profile serves as the roaming profile when no profile is selected.
Page 119 Advanced Configuration The roaming time for an SU increases when the RADIUS based authentication is enabled on the BSU. When an SU registers with a new BSU, it will transfer all the data, buffered during transition, to the new BSU. 5.4.6 BSU / SU Profiles In the BSU / SU Profiles tab, you can explicitly map a link profile to the peer device (See ).
Page 120 Advanced Configuration Figure 5-45 SU Profiles Entry Added Consider a case where a device is currently connected to its peer and no link profile is explicitly mapped. Then in such a scenario, the default link profile is assigned and displayed in the SU Profiles screen along with a Save option, as shown below: Figure 5-46 Save an SU Profile For such entries, user has the option to click Save button and configure this mapping in the profiles table.
Page 121 Advanced Configuration Figure 5-48 SU Profile Added The newly configured link profile will not be the Active Link Profile until you commit the changes. That is the reason, in the above screen, you are still able to see Default as the Active Link Profile for index 2, even though Profile1 is configured. When you commit the changes, the Active Link Profile will change to Profile1, as shown in the following figure.
Page 122: Wireless Security
Advanced Configuration Figure 5-50 Edit a Mapped Profile Make the necessary edits, and click OK followed by COMMIT. : When the radio mode is changed (say BSU to SU, or SU to BSU), the link profiles and the peer profile mapping list is retained.
Page 123 Advanced Configuration Given below is the table which explains Wireless Security parameters: Parameter Description Profile Name Specifies the security profile name. By default, it is WORP Security. Entry status Enables a user to either Enable or Disable the security profile on the device. By default, it is enabled.
Page 124 Advanced Configuration Parameter Description Encryption Type Select encryption type as either None, WEP, TKIP or AES-CCM. 1. None - If the encryption type is selected as None, then there exist no security to the data frames transmitted over the wireless medium. 2.
Page 125 Advanced Configuration 5.5.1.1.1 Sample Security Profile Configuration End Point A End Point B Profile Name WORP Security WORP Security Encryption Type AES-CCM AES-CCM 1234567890abcdef1234567890abcdef 1234567890abcdef1234567890abcdef (32 Hexadecimal digits) (32 Hexadecimal digits) publicpublic1234 publicpublic1234 (16 ASCII Characters) (16 ASCII Characters) Entry Status Enable Enable Network Secret...
Page 126 Advanced Configuration A RADIUS server profile consists of a Primary and a Secondary RADIUS server that can act as Authentication servers. Configuration of Secondary Authentication Server is optional. The RADIUS server is applicable only when it is enabled in the WORP Configuration page (See To configure the RADIUS Server profile, navigate to ADVANCED CONFIGURATION >...
Page 127: Mac Acl
Advanced Configuration Parameter Description IP Address Represents the IPv4 / IPv6 address of the primary and secondary RADIUS servers. : IPv6 address should be the global IP address and not the link local IP address. Server Port Specifies the port number that is used by the BSU/End Point A and the RADIUS server to communicate.
Page 128 Advanced Configuration Select the Operation Type as either Allow or Deny. Allow: Allows only the SUs/End Point Bs configured in the MAC Access Control Table to access the wireless network. Deny: Does not allow the SUs/End Point B devices configured in the MAC Access Control Table to access the wireless network.
Page 129: Quality Of Service (Qos)
Advanced Configuration 5.6 Quality of Service (QoS) The Quality of Service (QoS) feature is based on the 802.16 standard and defines the classes, service flows, and packet identification rules for specific types of traffic. QoS guarantees a reliable and adequate transmission quality for all types of traffic under conditions of high congestion and bandwidth over-subscription.
Page 130 Advanced Configuration A good example is provided by the 18 predefined PIRs. Note that these rules help identify specific traffic types: 1. All – No classification fields, all traffic matches 2. L2 Multicast a. Ethernet Destination (dest = 0x010000000000, mask = 0x010000000000) 3.
Page 131 Advanced Configuration : Two different VoIP rule names have been defined for each direction of traffic, Uplink (UL) and Downlink (DL), (index numbers 4 to 7). This has been done to distinguish the proprietary nature of the Cisco VoIP implementation as opposed to the more standard Session Initiation Protocol (SIP) signaling found, for example, in the Vonage-type VoIP service.
Page 132 Advanced Configuration Committed Information Rate Scheduling Type Traffic Priority Absolute Priority (CIR) RtPS RtPS RtPS RtPS RtPS RtPS RtPS RtPS > 0 (<= MIR) > 0 (<= MIR) > 0 (<= MIR) > 0 (<= MIR) > 0 (<= MIR) >...
Page 133 Advanced Configuration It is important to note that for each SFC with CIR > 0, there are effectively two absolute traffic priorities alloted (total 16 priorities for the 8 SFC entries). The higher priority is used as long as the throughput of the traffic being sent through SFC is below or equal to the CIR, and the lower priority is used for the rest of the traffic, taking MIR configuration as the second priority.
Page 134 Advanced Configuration e. Minimum Reserved Traffic Rate = 2 Mbps Maximum Latency = 20 milliseconds g. Traffic Priority = 1 Note that two different VoIP Service Flow classes for each direction of traffic have been defined (index numbers 4 to 7) which follow the ITU-T standard nomenclatures: G.711 refers to a type of audio companding and encoding that produces a 64 Kbps bitstream, suitable for all types of audio signals.
Page 135: Qos Configuration
Advanced Configuration b. SF class: DL-G729 20 ms VoIP rtPS – PIR: Vonage VoIP DL; PIR Priority: 1 – PIR: Cisco VoIP DL; PIR Priority: 1 5. 2Mbps Video a. SF class: DL-2Mbps Video – PIR: Streaming Video (IP/TV); PIR Priority: 1 5.6.2 QoS Configuration There are several pre-defined QoS classes, SFCs, and PIRs available that cover the most common types of traffic.
Page 136 Advanced Configuration Figure 5-58 QoS PIR MAC Address Add Entry c. Provide the MAC Address, Mask, Comment, Entry Status details and click Add. Comment field can be used to identify when this particular entry is referred in PIR Rule/QoS Class. The bit that is enabled in the “MAC Mask”...
Page 137 Advanced Configuration Figure 5-59 QoS PIR IP Address Entries To Add a New PIR IP Address Entry, a. Navigate to ADVANCED CONFIGURATION > QoS > PIR List > IP Address Entries. The QoS PIR IP Address Entries screen appears b. Click Add on the QoS PIR IP Address Entries screen to add a new entry. The following screen appears for configuring the IP Address Entry Details.
Page 138 Advanced Configuration Figure 5-61 QoS PIR TCP/UDP Port Entries To Add a New PIR TCP/UDP Port Entry, a. Navigate to ADVANCED CONFIGURATION > QoS > PIR List > TCP/UDP Port Entries. The QoS PIR TCP/UDP Port Entries screen appears. b. Click Add on the QoS PIR TCP/UDP Port Entries screen to add a new entry. The following screen appears for configuring the IP Address entry details.
Page 139 Advanced Configuration Figure 5-63 QoS PIR Entries To Add a New PIR Rule, a. Navigate to ADVANCED CONFIGURATION > QoS > PIR List. The QoS PIR Entries screen appears. b. Click Add on the QoS PIR Entries screen to add a new entry. The following screen appears for configuring the New PIR Entry.
Page 140 Advanced Configuration Figure 5-64 QoS PIR Add Entry c. Provide the PIR Name, Entry Status details and click Add. 5.6.2.1.1 PIR Rule Clarification Details 1. Navigate to ADVANCED CONFIGURATION > QoS > PIR List and click Details for editing a particular PIR Rule. ®...
Page 141 Advanced Configuration Figure 5-65 QoS PIR Edit Entry ® Tsunami 800 & 8000 Series - Software Management Guide...
Page 142 Advanced Configuration Parameter Description Rule Name This parameter specifies the Name of the Packet Identification Rule (PIR) and can have a length of 1-32 characters. ToS Rule This parameter is used to enable or disable a TOS rule. When ToS rule is enabled, configure the values for the following to specify the ToS-related configuration: ToS Low ToS High...
Page 143 Advanced Configuration Parameter Description 3. To prioritize DSCP packets based on IP-Precedence/DSCP value/ToS value, configure “ToS Mask”. a. IP Precedence: To prioritize based on only IP precedence, set all the 3 IP Precedence bits in the ToS Mask parameter to “1” and set rest of the bits in the ToS Mask parameter to ‘0”...
Page 144 Advanced Configuration Figure 5-67 QoS PIR Protocol ID c. Enter the details and click Add. For deleting an entry, click Delete for the corresponding entry in PIR Details screen. 5.6.2.1.3 Adding TCP/UDP Source Port Add Entry a. Navigate to ADVANCED CONFIGURATION > QoS > PIR List. Click Details. The QoS PIR Edit Entry screen appears.
Page 145 Advanced Configuration Figure 5-69 QoS PIR TCP/UDP Destination Port Add Entry c. All the entries present in the PIR TCP/UDP Port Entries are displayed in the TCP/UDP Port Entry Table. Select the appropriate radio button and click Add. When an entry is added for a specific PIR, it gets displayed in the existing TCP/UDP Port Entries table.
Page 146 Advanced Configuration 5.6.2.1.5.2 Adding Destination IP Address a. Navigate to ADVANCED CONFIGURATION > QoS > PIR List. Click Details. The QoS PIR Edit Entry screen appears. b. Navigate to Destination IP Address Entries tab and then click Add to add a new entry. The following screen appears.
Page 147 Advanced Configuration In this example, all bits in the IP Mask are enabled, so incoming traffic’s multicast IP address should exactly match with specified configured multicast IP Address (i.e, 224.0.0.9). Other traffic is considered as non-matching traffic. 6. Creating Matching Profile for range of Multicast IP Address (224.0.0.0 to 224.0.0.255) IP Address: 224.0.0.9 IP Mask: 255.255.255.255 5.6.2.1.6 Adding Source MAC Address...
Page 148 Advanced Configuration b. All the entries present in the PIR MAC Address Entries are displayed in the MAC Address Entry Table. Select the appropriate radio button and click Add. After adding the entry for this specific PIR, it is displayed in the Existing MAC Address Entries table.
Page 149 Advanced Configuration Figure 5-75 QoS Service Flow Add Entry 2. Specify details for the Service Flow Name, Scheduler Type, Traffic Direction, MIR, CIR, Max Latency, Tolerable Jitter, Traffic Priority, Max Messages in Burst and Entry Status. 3. Click Add. Parameter Description Service Flow Name Specifies the Name of the Service Flow.
Page 150 Advanced Configuration Parameter Description Max Messages in Specifies the maximum number of messages that can be sent in a burst. This value ranges Burst from 1 to 16. : Reducing the number of messages impacts the throughput. Entry Status Specifies the Service Flow status. 5.6.2.3 QoS Class Configuration 1.
Page 151 Advanced Configuration Figure 5-77 QoS Class Add Entry b. Specify the QoS Class Name, Service Flow Name PIR Rule Name Priority and Entry Status and click Add. Parameter Description Class Name Specifies the Name of the QoS Class. This name length can range from 1 to 32 characters. Service Flow Name Specifies the Service Flow to be associated with the QoS Class.
Page 152 Advanced Configuration Figure 5-78 QoS Class Service Flow Details 3. Click Add. The following screen appears for association of the new SFC in this QoS Class. Figure 5-79 QoS Class Service Flow Add Entry 4. Specify the Service Flow Name, PIR Rule Name, Priority and Entry Status and click Add to add a new entry. 5.6.2.3.2 Adding PIR in QoS Class 1.
Page 153 Advanced Configuration Figure 5-80 QoS Class PIR Details 3. Click Add. The following screen appears for association of the new PIR rule in an SFC already associated in an QoS Class. Figure 5-81 QoS Class PIR Add Entry 4. Specify the PIR Rule Name, Priority and Entry Status and click Add to add a new entry. : When you change the entry status of an existing QoS Class, the status changes immediately.
Page 154: Qos Configuration For A Management Station
Advanced Configuration Figure 5-82 QoS SU or End Point B List 2. If an SU or End Point B is not in the list and is associated, the default QoS class configuration is applied. 5.6.2.4.1 Adding a New SU or End Point B 1.
Page 155 Advanced Configuration The following configuration instructions explain how to configure the system so that configuration parameters can always be changed, and ping requests and responses get higher priority in order to show the actual connectivity of the pinged node. The configuration suggested here assumes that the whole network is managed from a single work station, called the management station.
Page 156 Advanced Configuration c. Click Add that corresponds to Source IP Address Entries. This displays a screen for referring the Management Station’s IP Address. New Entry Table displays all the IP Address Entries of the PIR List. Select the option button corresponding to the Management Station and then click Add.
Page 157 Advanced Configuration Max Messages in Burst: 16 Entry Status: Enable d. Click Add. The UL-Management SF is added to the QoS SFC List. : The input and output bandwidth limits set on the End Point A or BSU or on the End Point B or SU are used for limiting aggregate bandwidth used by the SU or End Point B.
Page 158 Advanced Configuration 5.7 RADIUS Based SU QoS Configuration RADIUS based QoS configuration enables you to configure QoS parameters on an SU through RADIUS Server. This way of configuring QoS parameters, reduces the task of manually configuring QoS parameters on each SU available on the network. Explained below is the process followed to configure QoS parameters on an SU from a RADIUS Server.
Page 159 Advanced Configuration 5.8 VLAN (Bridge Mode Only) The Virtual Local Area Network (VLAN) feature helps in logical grouping of network host on different physical LAN segments, which can communicate with each other as if they are all on the same physical LAN segment. With VLANs, you can conveniently, efficiently, and easily manage your network in the following ways: Define groups Limits the broadcast and multicast traffic to a specific VLAN group...
Page 160 Advanced Configuration Figure 5-86 System-Level VLAN Configuration (SU/End Point A/End Point B) 1. VLAN Status: This parameter is used to either enable or disable VLAN feature on the device. By default, this parameter is disabled. To enable VLAN, select the VLAN Status box. If VLAN status is enabled, it indicates that locally configured VLAN parameters will be applied on the device.
Page 161 Advanced Configuration : When Double VLAN is enabled on the device, the Service VLAN ID should not be set to -1. 7. Service VLAN Priority: This parameter is used to set IEEE 802.1p priority in outer/service VLAN tag for the data frames.
Page 162 Advanced Configuration : Wireless Interface of the device will always be in transparent mode. There is no support provided to edit the VLAN parameters of the wireless interface. 5.8.2.2 Access Mode Access Mode can be configured in an SU, End Point A and End Point B. This mode is used to connect VLAN aware networks with VLAN unaware networks.
Page 163 Advanced Configuration Parameter Description Access VLAN Priority This parameter is used to set IEEE 802.1p priority for the data frames. By default, the priority is set to 0. To set the Access VLAN priority, enter a value ranging from 0 to 7. Allow Untagged When enabled, the Management Access is allowed using untagged packets.
Page 164 Advanced Configuration Figure 5-90 Trunk Mode (SU/End Point A/End Point B) Given below is the table which explains the method to configure the device in Trunk Mode: Parameter Description Interface Displays the name of the Ethernet interface. VLAN Mode Select the VLAN Mode as Trunk. Allow Untagged Select Enable or Disable.
Page 165 Advanced Configuration Parameter Description Port VLAN ID Enter the Port VLAN ID in the Port VLAN ID box. The untagged data frames received at the Ethernet interface are tagged with this port VLAN Id and then forwarded to the destination interface. By default, the Port VLAN Id is set to -1 which indicates no tag is added to the data frame.
Page 166 Advanced Configuration : You can configure a maximum of 256 trunk VLAN Ids in a BSU and End Point A device, and 16 trunk VLAN Ids in an SU and End Point B device. 5.9 RADIUS Based SU VLAN Configuration RADIUS based VLAN configuration enables you to configure VLAN parameters on an SU through RADIUS Server.
Page 167 Advanced Configuration Name of the attribute Vendor Attribute Attribute Value Assigned Format Attribute Number Management Attribute VLAN ID Decimal 1 – 4095 Management VLAN Priority Decimal 0 – 7 VLAN Ethernet 1 Trunk IDs 1 to 16 10 … 25 Decimal 1 –...
Page 168 Advanced Configuration An MP.11 SU should locally configure VLAN parameters when connected to a MP 82x/8000 BSU in legacy mode as the BSU will not assign any VLAN parameters based on RADIUS authentication. An MP 82x/8000 SU should locally configure VLAN in legacy mode when connected to a MP.11 BSU, should locally configure VLAN parameters as the BSU shall not assign VLAN parameters based on RADIUS authentication.
Page 169: Protocol Filter
Advanced Configuration Parameter Description STP/LACP Frames This parameter allows you to either Block or Passthru STP/LACP frames on the network. Passthru: By allowing the STP/LACP frames, any loops that occurs within a network can be avoided. If configured to Passthru, the STP/LACP frames in the system are bridged.
Page 170 Advanced Configuration Figure 5-94 Protocol Filter ® Tsunami 800 & 8000 Series - Software Management Guide...
