Summary of Contents for Proxim QB-8100-EPA
- Page 1 IMPORTANT! http://support.proxim.com Visit for the latest safety and regulatory compliance information for this product. Tsunami QB-8100/MP-8100 Series Safety and Regulatory Compliance Guide Model QB-8100-EPA Model QB-8150-EPR Model MP-8100-BSU Model MP-8100-SUA Model MP-8150-SUR...
- Page 2 Copyright © 2009 Proxim Wireless Corporation. All rights reserved. Covered by one or more of the following U.S. patents: 5,231,634; 5,875,179; 6,006,090; 5,809,060; 6,075,812; 5,077,753. This user’s guide and the software described in it are copyrighted with all rights reserved. No part of this publication may be reproduced, transmitted, transcribed, stored in a retrieval system, or translated into any language in any form by any means without the written permission of Proxim Wireless Corporation.
-
Page 3: Products Covered In This Guide
1.1 Products covered in this guide This document contains important safety and regulatory compliance information for the following products: Product Family QuickBridge SKUs* Tsunami QB-8100 Outdoor Wireless QB-8150-EPR-US Point-to-Point System QB-8100-EPA-US QB-8150-EPR-WD QB-8100-EPA-WD Product Family MultiPoint SKUs* Tsunami MP-8100 Outdoor Wireless MP-8100-BSU-US... - Page 4 1.2 Safety Information (USA, Canada, & European Union) 1. These products have been evaluated to, and comply with, the U.S. and Canadian (Bi National) Standard for Safety of Information Technology Equipment, including IEC 60950, UL certificate, Standard: UL60950-1+Part 22, UL 60950-22(UL+cUL) Outdoor.
- Page 5 This device complies with the Low Voltage Directive 73/23/EEC and R&TTE Directive 1999/5/EC. Compliance with these directives implies conformity to harmonized European standards (European Norms) that are listed on the EU Declaration of Conformity that has been issued by Proxim Wireless Company for this device. Countries of Operation & Conditions of Use...
-
Page 6: Federal Communications Commission (Fcc) Compliance
1.4 Federal Communications Commission (FCC) Compliance These products operate at the following frequencies in compliance with Part 15 of the FCC rules: • Model QB-8100-EPA: 5 GHz • Model QB-8150-EPR: 5 GHz • Model MP-8100-BSU: 5 GHz • Model MP-8100-SUA: 5 GHz •... - Page 7 • Connect the equipment to an AC outlet on a circuit different from that to which the receiver is connected • Consult the dealer or an experienced radio/TV technician for help In some situations or environments, the use of wireless devices may be restricted by the proprietor of the building or responsible representatives of the organization.
- Page 8 Band EIRP Limit (dBm) USA and Canada 5.725 - 5.850 GHz 30 (Point-to-Multipoint) Operation is not allowed No limit (Point-to-Point) WARNING: You must add external attenuation pad if calculated EIRP is over the limit. 1.5.2 Antenna Types and Maximum Gain Professional installers should select only the antenna listed in the Tsunami QB-8100/MP-8100 Recommended Antennas Guide, with gain not exceeding the listed maximum gain for each type.
-
Page 9: Regulatory Compliance Certifications Summary
1.6 Regulatory Compliance Certifications Summary 1.6.1 Model QB-8100-EPA Country Certification/Reference No. FCC ID: HZB815058 Canada IC: 1856A-PROXMB82 1.6.2 Model QB-8150-EPR Country Certification/Reference No. FCC ID: HZB815058 Canada IC: 1856A-PROXMB82 1.6.3 Model MP-8100-BSU Country Certification/Reference No. FCC ID: HZB815058 Canada IC: 1856A-PROXMB82 1.6.4 Model MP-8100-SUA... - Page 10 1.6.5 Model MP-8150-SUR Country Certification/Reference No. FCC ID: HZB815058 Canada IC: 1856A-PROXMB82 1.7 Unit’s Hardware Description NOTE: In the connectorized version, if you use Single Polarization antenna, always use the antenna port A1. If you use Dual Polarization antenna, use the antenna port A1 and A3.
-
Page 11: Installation Procedure
1.8 Installation Procedure This section describes the procedures to install and mount the unit and to align the antenna. The installation procedure does not include information on the mounting and connection of external antennas. Assemble the Mounting Hardware Attach the mounting plate (A) using the provided screws and washers (Torque 9 N.m/75 in-lbs), such that the unit’s antenna will be vertically and horizontally polarized when mounted. -
Page 12: Connect The Antenna (Connectorized Version Only)
Units with integrated antennas must always be mounted in square position to achieve Horizontal and Vertical+45 degree and -45 degree polarization. Install Surge Protector Proxim recommends two approved lightning surge protectors to be installed, one near to the device (supplied with the product package) and the other near to the building ingress point. -
Page 13: Power On The Unit
Cut any extra ground wire length when finished connecting it to the single point earth ground. Avoid sharp bends and never loop or coil up the ground wire, always connect it straight to ground. A good earth ground impedance is less than 1.0 ohm. Measure ground impedance at the point where the protector ground wire is connected and not at the ground rod.
