2 Operating procedures

2.1 Starting the system

The system computer is configured with a Windows policy restricting access to
the operating system for the normal user. When starting the system computer
the user will automatically be logged on to Windows and then the software
logon window will be displayed.
Start the system as follows:
1. Switch on the slide scanning unit.
2. Switch on the system computer.
3. Wait until the status lamp on the slide scanning unit is flashing or
continuously lit (see picture in 1.5 Components and mechanical operation).
4. In the Log On dialog, type username, password and select the desired
database. The following icons indicate available database types:
5. Click OK.
For more information on database types and how to create and manage
databases, see 9.1 Database settings.

2.2 System control view

The System Control view shows the ongoing slide processing, gives an
overview of the preclassification and presents a log of processed slide holders.
The layout of the System Control view depends on the type of application.
User's Manual
CellaVision
Processing database
Export database
Scan database
Click System Control view in the toolbar.
