Motorized microscope
The motorized microscope is an upright light microscope with a LED
illumination system. It has one 10x objective and one 100x objective and
intermediate optics switching between 1.0x and 0.5x magnification which
combined yields images with 5x, 10x, 50x, or 100x magnification.
Digital color camera
The camera is a high-quality progressive-scan CCD color camera, for
maximum image quality and high speed image acquisition.
Immersion oil unit
The unit automatically applies drops of immersion oil to a slide. An optical
drop counter controls the procedure.
Robot gripper unit
The robot gripper unit enables fully automated focusing and positioning of the
slide during slide processing. It also transports the slide from the magazine and
back again after the slide has been processed.
Barcode reader
The barcode reader scans the barcode of both the slide and the magazine. For
more information on barcodes, see A.3.5 Barcodes.
Control unit
The control unit controls motors, sensors, oil applying and illumination. It
functions as a subordinate computer to the system computer via an unshared
Ethernet connection.
Casing
The casing comprises a metal cabinet and the main hood.
User's Manual
CellaVision
Warning!
Never tamper with sensors or other safety devices. These make sure that
the system can operate without any risk of personal injury.
