Summary of Contents for AAXA Technologies P5

  • Page 1 aaxa TECHNOLOGIES User Guide...
  • Page 2 Caution! WARNING: Please use this product as instructed. Misuse may cause injury or death. DO NOT use while driving Caution for Battery Use • Do not pierce or puncture the battery DO NOT expose to water or wet with sharp objects surfaces.

  • Page 3: Table Of Contents

    Table of Contents Connecting a Micro SD Card Chapter 1: P5 at a Glance Connecting a USB Stick P5 Introduction Chapter 3: Menu Screens Remote & Keypad Main menu Accessories Video Player Menu Chapter 2: Getting Started Photo Viewer Menu...

  • Page 4: Chapter 1: P5 At A Glance

    Chapter 1 P5 at a Glance Main Unit Front/Back Power Button Power Switch Micro SD Card Focus Adjustment HDMI VGA Port AV Port Headphone Out USB Port...

  • Page 5: Remote & Keypad

    Both the keypad and remote can be used to navigate through the menus. The Main Menu Navigation on the remote functions exactly the same as the directional pad on the P5 unit. NOTICE: Pressing power on the remote will only put the projector in STANDBY mode.

  • Page 6: Accessories

    Accessories Tripod Remote VGA Cable Power Adapter A/V Cable *Under various circumstances, the actual accessories may be different from those shown in the pictures above.

  • Page 7: Chapter 2: Getting Started

    Getting Started Powering ON the projector Connect the power cord to the P5. Connect the other end of the power cord into the wall power source. Toggle the On / Off switch on the side of the projector to the “ON” position --the projector should automatically turn on.

  • Page 8: Swappable Battery

    This battery pack is designed to be interchangeable with spare battery packs and can be removed and replaced as needed. This battery pack can only be charged by connecting to the P5 projector while the power supply is plugged in. This battery pack does NOT charge while the projec- tor is in operation.

  • Page 9: Battery Installation

    Battery Installation Removing Battery Locate the battery locking mechanisms underneath the projector Slide the two locking mechanisms outwards Gently slide the Battery Pack out by pushing the battery pack away from the projec- Installing the Battery Reverse the removal instructions and ensure the battery is properly connected to the guide clips...

  • Page 10: Focus Adjustment / Throw Distance

    Focus Adjusment / Throw Distance Focus Adjustment • Spin the focus wheel up or down until the image becomes clear. Throw Distance Chart Throw Distance Diagonal Size Units: Inches Units: Inches 16:9 Aspect Ratio Throw Ratio 1.47 Projection Angle: 100% Offset *minimum throw distance: 10 inches...

  • Page 11: External Input/Outputs

    External Inputs and Outputs USB Stick Composite Cable MicroSD Headphones/speakers HDMI...

  • Page 12: Connecting To A Computer Vga

    Connect one end of the VGA Cable to your computer’s VGA Adapter. Step 2: Connect the other end of the VGA Cord to your P5’s VGA port. Step 3: In the Main Menu Select the “Inputs” icon and then the “VGA” Icon. Select “INPUT” icon...
  • Page 13 Connecting to a Computer Cont. Step 4: Enabling VGA or HDMI output on your Computer – To enable VGA or HDMI output on your com- puter most computers require “turning on” the video output feature. Each computer is different. Please consult your owner’s manual for instructions to enable VGA or HDMI output. Below are standard instructions for a Windows 7 computer –...

  • Page 14: Connecting To A Computer Hdmi

    Connect one end of the HDMI Cable to your computer’s HDMI Adapter. Step 2: Connect the other end of the HDMI Cord to your P5’s HDMI port. Step 3: In the Main Menu Select the “Inputs” icon and then the “HDMI” Icon. Select “HDMI” icon...
  • Page 15 Connecting to a Computer Cont. Step 4: Enabling VGA or HDMI output on your Computer – To enable VGA or HDMI output on your com- puter most computers require “turning on” the video output feature. Each computer is different. Please consult your owner’s manual for instructions to enable VGA or HDMI output. Below are standard instructions for a Windows 7 computer –...

  • Page 16: Connecting To Composite Video

    Connecting to Composite Video Step 1: Connect the 3.5mm Composite A/V Cable to the back of the P5. Step 2: Connect the composite end of the AV Cable (Red, White,Yellow) to your device.
  • Page 17 The P5 can connect to many media devices including: iPod, iPhone, iPad, VHS players, DVD players, smart phones, cameras, video game consoles and other peripherals with ease. *Some smart phones require video out capabilities to be displayed with the P5. Check with your phone manufacturer.

  • Page 18: Connecting To Hdmi Video

    Connecting to HDMI Video Step 1: Connect one end of the HDMI to your P5’s HDMI Adapter Step 2: Connect the opposite end of the HDMI cable to your device. Note: Apple devices require a specialized HDMI adapter (Sold separately by...
  • Page 19 The P5 can connect to many media devices including: iPod, iPhone, iPad, VHS players, DVD players, smart phones, cameras, video game consoles and other peripherals with ease. *Some smart phones require video out capabilities to be displayed with the P5. Check with your phone manufacturer.

  • Page 20: Headphones

    Connecting Speakers / Headphones Step 1: Connect your speakers/headphones to the projector’s audio port. Step 2: Ensure that the projector and/or the headphones are powered on. Step 3: Place the headphones on and enjoy! *CAUTION Prolonged use of headphones at a high volume may impair hearing.

  • Page 21: Connecting A Micro Sd Card

    Micro SD Card How to insert your Micro SD Card • Slide in your SD card into the SD card slot on the side of the P5. (Facing down as shown in picture) • Gently slide the SD card until it clicks into place.
  • Page 22 Micro SD Card Cont. File Menu System • The P5 will show all folders and files you have on your SD Card in the C: drive. Media Player menu • Use the directional buttons to navigate • In the main menu select the type of file to different folders or files.

  • Page 23: Connecting A Usb Stick

    USB Drive How to insert your USB Drive • Slide your USB Drive into the USB port. (as shown in picture) • Gently slide the drive until it cannot go in any further. How to access your USB Drive • Insert your USB Drive into the projector.
  • Page 24 USB Drive Cont. File Menu System • The P5 will show all folders and files you have on your USB Drive. • Use the directional buttons to navigate Media Player menu to different folders or files. • In the main menu select the type of file you wish to play.

  • Page 25: Chapter 3: Menu Screens

    Chapter 3 Menu Screens Main Menu The P5 features a built in PMP (Portable Media Player) function. This function allows the projector to play videos, pictures, music files, and text directly from your connected devices. Direction Pad Input On / Off Exit/Back •...

  • Page 26: Video Player Menu

    • Choose which file you wish to play. Fig. 3.1 Fig. 3.2 The P5 will show all folders and files you have on your USB or MicroSD drive. Use the navigation buttons to select folders or files. Previewing Files: •...
  • Page 27 Video Player Menu While Playing Videos While playing videos the volume and keystone is adjustable. Further controls are available in the video player submenu - which is accessed through the “ok” button. Volume Up Positive Keystone Adjustment Volume Down Negative Keystone Adjustment Enter Video Player Submenu •...
  • Page 28 Video Player Sub-Menu Playing Videos The Video Player Sub-Menu can be accessed by pressing “OK” during video playback. To exit the Video Player Sub-Menu press the “Back” button or wait 5 seconds. To navigate the playback menu use the directional buttons on the navigation pad or remote to highlight the option you wish to choose (Fig 3.3).

  • Page 29: Video Playback Faq

    Video Playback FAQ How do I loop a video? How do I preview a video? Choose the “video” option from the 1. Choose either USB or SD Card main menu for playback Navigate using either remote or onboard buttons to the file you wish to preview.

  • Page 30: Photo Viewer Menu

    • Choose which file you wish to play. Fig 3.4 Fig 3.5 The P5 will show all folders and files you have on your USB or MicroSD drive. Use the navigation buttons to select folders or files. Previewing Files: •...
  • Page 31 Photo Menu While Viewing Pictures While viewing pictures the keystone is adjustable. Further controls are available in the Photo Submenu - which is accessed through the “OK” button. Previous Picture Positive Keystone Adjustment Next Picture Negative Keystone Adjustment Enter Photo Player Submenu •...

  • Page 32: Viewing Pictures

    Photo Sub-Menu Viewing Pictures: The Photo Sub-Menu can be accessed by pressing “OK” during picture slide- show playback.To exit the Photo Sub-Menu press the “Back” button or wait 5 seconds. To navigate the playback menu use the directional buttons on the navigation pad or remote to highlight the option you wish to choose (Fig 3.6).
  • Page 33 Photo Slideshow FAQ How do I play a slideshow? How do I manually control the slideshow? 1. Choose either USB or SD Card for playback After selecting the photo you wish to be displayed, you can press “play” to start the slideshow (as outlined in the previous FAQ).

  • Page 34: Music Player Menu

    • Choose which file you wish to play. Fig. 3.7 Fig. 3.8 The P5 will show all folders and files you have on your USB or MicroSD drive. Use the navigation buttons to select folders or files. Previewing Files: •...
  • Page 35 Music Player Menu Listening To Audio: To adjust the volume use the left and right button on the projector or the volumes keys on the remote. To navigate the playback menu, push the “OK” button to open the menu and use the directional buttons on the navigation pad or remote highlight the option you wish to choose (Fig 3.9).
  • Page 36 Music Playback FAQ How do I loop a song? How do I create a song playlist? Insert your media device (either mi- 1. Choose either USB or SD Card croSD card or USB) into computer. for playback Make a new folder on media device (folder name will be the name of the playlist).

  • Page 37: Ebook Viewer Menu

    Use the navigation buttons to select folders or files. Viewing Text Files: The P5 Pico Projector allows you to view text files. Select the file you want to view in the file menu for the particular storage device on which the file is stored. You can press the left and right arrow buttons on the directional pad or remote to flip through the pages you have in the present folder.

  • Page 38: Chapter 4: Setup Menu

    • Auto Volume Within the settings menu there are • Surround Sound Time four more submenus that allow you • Clock to customize your P5 to the settings • Off Time you want. • On Time • Sleep Timer •...

  • Page 39: Picture Settings

    Picture Settings Picture Mode • Changes the picture mode to different settings depending on your usage. Color Temperature • Adjusts the color temperature from hot to cool (red to blue). Power Mode • Adjusts the brightness on the projector. (See Page 40) Slideshow Time •...

  • Page 40: Sound Settings

    Sound Settings Sound Mode • Changes the sound mode depend- ing on what is currently playing. Balance • Adjusts the balance of the sound, from left to right. Auto Volume • Sets the projector to auto-detect for the volume. The projector will auto detect the appropriate sound mode.

  • Page 41: Time Settings

    Time Settings Clock • Adjust the time/date. Off Time • Sets when to turn off. On Time • Sets when to turn on. Sleep Timer • Sets when projector goes to sleep. Auto Sleep • Sets auto sleep function.

  • Page 42: Option Settings

    Option Settings OSD Language • Changes the language of the device. Options include English, Spanish, Chinese, German, French Restore Factory Default • Restores the projector to factory settings. OSD Duration • Allows the projector to set a duration for the selected OSD language.

  • Page 43: Brightness Feature

    Brightness Feature There are 3 different power modes for the P5: Bright, Standard, and Eco. • Bright: The brightest mode. Only available while plugged in. • Standard: A normal mode while running on battery that’s slightly less bright and enables a 90 minute battery run time.

  • Page 44: Keystone

    Keystone Adjustments What is Keystoning? “Keystoning” occurs when a projector is aligned non-perpendicularly to a screen, or when the projection screen has an angled surface. The image that results from one of these misalignments will look trapezoidal rather than square. Digital Keystone Adjustments By adding a special, selectable algorithm to the scaling, some new projectors are able to alter the image before it reaches the projection lens.
  • Page 45 If the image looks trapezoidal with the base larger (as pictured right), press the bottom button on the di- rectional pad on the top of the P5 until the keystone effect corrects and the picture turns into a square projection.

  • Page 46: Chapter 5: Technical Details

    Be sure to setup the computer to enable a video signal output. On some laptops this is done by pressing and holding Function F5 key. If using the P5 as an external monitor on Windows based systems, this can be done by selecting “extend my desktop to this monitor”. The native resolution of the P5 projector is 1280x720.
  • Page 47 Technical Details Troubleshooting THE PROJECTOR DOES NOT TURN ON Possible Causes Solution There is no power Check to ensure the power outlet source is good. Check the power adapter to ensure a proper connection with the wall outlet as well as the projector.

  • Page 48: Specifications

    Specifications Brightness: 300 Lumens Native Resolution: 1280x720 Contrast Ratio: 1000:1 Aspect Ratio: 16:9 Projection Lens: Manual Focus Image Size: 10~120 inches Lamp: Triple RGB LEDs with Vibrant Color Technology Life 15,000hrs Video in: Composite A/V VGA(mini-VGA) HDMI Audio Output: 1.0 W stereo speakers 3.5 mm audio jack SD Card: MicroSD Card Slot...

  • Page 49: Notes

    Notes...
  • Page 50 Please direct all customer service inquiries to: AAXA Technologies, Inc. 1541 Parkway Loop Tustin, CA 92780 (714) 957-1999 info@aaxatech.com...
