4. Click OK.
The Enter Network Password dialog box closes, and the screen you were trying to access displays.

Logging On to a PPP Session

After you log on to the Administrative User Setup
screen, one of two screens will display.
1. If you have configured multiple PPP sessions,
the Login screen will display the available
connections. Click the connection you wish to
log on to.
- or -
If you have configured only one PPP session,
the PPP Login screen displays.
2. In the PPP Login screen, enter the user name and password.
3. To save the settings, select Save Settings on Connect.
4. To configure additional PPP options, click
Show Options.
The input box expands to display the PPP
Options section.
5. Enter the desired PPP options:
•
Access Concentrator
Enter the [optional] name of the
access concentrator as provided by
your ISP.
• Service Name
Enter the [optional] service name
provided by your ISP.
• Auto-Connect on Disconnect
If selected, modem will attempt to
login every time the DSL trains if you
selected Save Settings on Connect.
•
Idle Timeout (with time value)
Select to disconnect the PPP session if
the router has had no traffic for the
specified amount of time. Enter the
time in minutes. This cannot be used
with Autoconnect.
PPP offers the Connect on Demand feature
whereby the modem will attempt to log on to
a disconnected PPP session if there is requested traffic from the LAN side, and if there is a saved user
15
SpeedStream PPPoE Modem
