Fisher FIELDVUE DVC2000 Instruction Manual Supplement page 26

DVC2000 Digital Valve Controller
September 2017
ADDITIONAL_STATUS_1
Bit 7
Bit 6
Bit 5
Bit 4
Bit 3
Bit 2
Bit 1
Bit 0
ADDITIONAL_STATUS_2
Bit 7
Bit 6
Bit 5
Bit 4
Bit 3
Bit 2
Bit 1
Bit 0
ADDITIONAL_STATUS_3
Bit 7
Bit 6
Bit 5
Bit 4
Bit 3
Bit 2
Bit 1
Bit 0
26
According to Command 48:
Alert Record Not Empty Alert
Auto Tune in Progress
Calibration in Progress Alert
Diagnostics in Progress Alert
Pressure Fallback Active Alert
Reserved
Reserved
Auto Cal in Progress Alert
According to Command 48:
Reserved
Reserved
Cycle Counter Alert
Travel Accumulator High Alert
Instrument Time is Invalid Alert
Alert Record Full Alert
Offline / Failed Alert
Reserved
According to Command 48:
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Integrator Saturated High Alert
Integrator Saturated Low Alert
Instruction Manual Supplement
As defined in the Gateway:
ALERT_RECORD_HAS_ENTRIES
AUTO_TUNER_IN_PROGRESS
CALIBRATION_IN_PROGRESS
DIAGNOSTIC_IN_PROGRESS
PRESSURE_CONTROL_IS_ACTIVE
AUTO_TRAVEL_CALIBRATION_IN_PROGRESS
As defined in the Gateway:
CYCLE_COUNT_ALERT
TRAVEL_ACCUMULATOR_ALERT
INSTRUMENT_TIME_IS_INVALID
ALERT_RECORD_IS_FULL
OFFLINE_FAILED_ALERT
As defined in the Gateway:
INTEGRATOR_SATURATED_HIGH
INTEGRATOR_SATURATED_LOW
D103783X012
