DVC2000 Digital Valve Controller

September 2017

Annex B DVC2000 Parameters as part of a Rosemount 1410 /

1420 WirelessHART Gateway

A FIELDVUE DVC2000 can join a wireless network through the addition of a Rosemount 775 THUM WirelessHART

adapter. The wireless adapter acts both as a HART modem for communications coming to the DVC2000 from

application software and as an independent master issuing commands periodically to the wired device pertaining to

the device's status. This independently gathered status information is relayed back to the Rosemount 1410 or 1420

Wireless Gateway and is made available to the user either through viewing the HTML interface or via mapping as

"Published Data" parameters via the Gateway's MODBUS or OPC outputs.

For HART 5 devices the PV, SV, TV, and QV variables can be mapped.

Configure the THUM as follows:

Navigate to Configure > Manual Setup

Under the Wired Device tab select Configure HART Polling

Select Yes if changes are required

Wired Device tab

Instruction Manual Supplement

FOR PRIMARY DEVICE INFORMATION:

Select PV, SV, TV, and QV

FOR SECONDARY DEVICE INFORMATION:

Select Device Status

D103783X012
