11.3.3 Changing the Color of a Leader Line

To change the color of a Leader Line, do the following:
1.
2.
3.
Figure 11-10 Mold Picture View Screen in Edit Mode
1. Change View Settings Button 2. Choose Heat Zone Button 3. Leader Line Color Button
4. Mold Picture View Graphic 5. Leader Line 6. Zone Information Panel 7. Delete Button
8. Accept Button
4.
5.

11.3.4 Deleting a Leader Line

To delete a Leader Line, do the following:
1.
2.
150
v 2.3 — September 2015
Make sure Mold Picture View is in Edit mode.
Touch the Zone Information Panel associated with the Leader Line to be changed.
Touch the Leader Line Color button.
1
2
3
4
5
6
Touch the desired color.
Touch the Accept button.
Make sure Mold Picture View is in Edit mode.
Touch and drag the Leader Line to be deleted onto the associated Zone Information
Panel or off the mold picture view graphic.
Altanium Delta3
Changing the Color of a Leader Line
