Phottix Atlas II Instructions Manual page 2

Parts
1. Power Switch
2. Transmit / Receive Mode Switch
3. DC Power Port
4. Channel Selector Switch
5. Test / Shutter Button
6. Flash Hot Shoe Connection
7. Camera Hot Shoe Connection
8. Locking Ring
9. Flash in/out Port
10. Flash out Port
11. Shutter Release Port
12. Antennae
13. Tripod Lug
14. Battery Cover
15. Battery Compartment
16. Status LED
2
16
4
3
12
6
2
1
5
8
7
13
14
15
9
10 11
