4. Set the Transmit / Receive Mode Switch on
the Atlas II to Rx (receive mode).
5. Turn on the camera and Phottix Atlas II
transceiver.
6. Consult your camera manual for speci c
settings for remote use.
7. Using a second Phottix Atlas II transceiver
set in Tx (transmit mode) will allow for remote
wireless shutter release functions. The Atlas II
test button will work as shutter button – a
half-press will autofocus, a full press will take a
photo.
*On compatible cameras
Using the Atlas II as a wired remote*
1. Turn o the camera and the Phottix Atlas II
transceiver.
10
2. Attach the correct Phottix Accessory Cable
for your camera make and model to the
Shutter Release Port on the transceiver.
3. Attach the other end of the cable to the
camera's remote port.
4. Turn on the camera and Phottix Atlas II
transceiver.
5. Consult your camera manual for speci c
settings for remote use.
6. The attached Phottix Atlas II transceiver will
allow for wired shutter release functions. The
Atlas II test button will work as shutter button
– a half-press will autofocus, a full press will
take a photo.
7. The Atlas II will function as a wired remote
when used with or without batteries and the
power switch set to on or o .
